Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 1 | 12361-300-000 | CAP, VALVE ADJ. | 1 |
| 1 | 12361-371-980 | CAP, VALVE ADJ. | 1 |
| 41310-HA7-770 | GEAR SET, FINAL | ||
| 41400-HA7-770 | GEAR ASSY., FR. FINAL | ||
| 41401-HA7-770 | CASE, FR. FINAL GEAR | ||
| 1 | 41405-HA7-670 | RING, STOPPER | 1 |
| 41411-HA0-000 | JOINT, PINION | ||
| 41453-HA0-000 | SHIM C, PINION GEAR (1.94) | ||
| 1 | 41454-HA0-000 | SHIM D, PINION GEAR (2.00) | 1 |
| 41455-HA0-000 | SHIM E, PINION GEAR (2.06) | ||
| 41456-HA0-000 | SHIM F, PINION GEAR (2.12) | ||
| 41457-HA0-000 | SHIM G, PINION GEAR (2.18) | ||
| 41631-HA7-670 | SHIM A, L. DIFFERENTIAL CASE (0.70) | ||
| 41632-HA7-670 | SHIM B, L. DIFFERENTIAL CASE (0.75) | ||
| 41633-HA7-670 | SHIM C, L. DIFFERENTIAL CASE (0.80) | ||
| 41634-HA7-670 | SHIM D, L. DIFFERENTIAL CASE (0.85) | ||
| 41635-HA7-670 | SHIM E, L. DIFFERENTIAL CASE (0.90) | ||
| 41636-HA7-670 | SHIM F, L. DIFFERENTIAL CASE (0.95) | ||
| 41637-HA7-670 | SHIM G, L. DIFFERENTIAL CASE (1.00) | ||
| 41638-HA7-670 | SHIM H, L. DIFFERENTIAL CASE (1.05) | ||
| 41639-HA7-670 | SHIM I, L. DIFFERENTIAL CASE (1.10) | ||
| 41640-HA7-670 | SHIM J, L. DIFFERENTIAL CASE (1.15) | ||
| 41641-HA7-670 | SHIM K, L. DIFFERENTIAL CASE (1.20) | ||
| 41642-HA7-670 | SHIM L, L. DIFFERENTIAL CASE (1.25) | ||
| 41643-HA7-670 | SHIM M, L. DIFFERENTIAL CASE (1.30) | ||
| 42321-HA7-770 | COVER, FR. FINAL GEAR CASE | ||
| 42561-HA7-670 | SHIM A, R. DIFFERENTIAL CASE (0.90) | ||
| 1 | 42562-HA7-670 | SHIM B, R. DIFFERENTIAL CASE (0.95) | 1 |
| 42563-HA7-670 | SHIM C, R. DIFFERENTIAL CASE (1.00) | ||
| 42564-HA7-670 | SHIM D, R. DIFFERENTIAL CASE (1.05) | ||
| 42565-HA7-670 | SHIM E, R. DIFFERENTIAL CASE (1.10) | ||
| 1 | 42566-HA7-670 | SHIM F, R. DIFFERENTIAL CASE (1.15) | 1 |
| 1 | 42567-HA7-670 | SHIM G, R. DIFFERENTIAL CASE (1.20) | 1 |
| 1 | 42568-HA7-670 | SHIM H, R. DIFFERENTIAL CASE (1.25) | 1 |
| 42569-HA7-670 | SHIM I, R. DIFFERENTIAL CASE (1.30) | ||
| 42570-HA7-670 | SHIM J, R. DIFFERENTIAL CASE (1.35) | ||
| 6 | 90101-HA7-670 | BOLT, UBS (8X17) | 6 |
| 6 | 90101-HN2-680 | BOLT, UBS (8X17) | 6 |
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 6 | 90133-MB0-000 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HA0-000 | BOLT, FLANGE (10X35) | 2 |
| 90137-HA7-770 | BOLT, STUD (10X25) | ||
| 1 | 90244-HA0-000 | NUT, LOCK (60MM) | 1 |
| 1 | 90381-HA0-000 | NUT, HEX. (16MM) | 1 |
| 1 | 90471-580-000 | GASKET (8MM) | 1 |
| 91002-HA7-671 | TUBE, FR. FINAL | ||
| 91052-HA7-671 | BEARING, RADIAL BALL (28X52X12) (TOYO) | ||
| 91052-HA7-672 | BEARING, RADIAL BALL (28X52X12) (KOYO) | ||
| 91053-HA7-771 | BEARING, NEEDLE (13X25.5X13) (TOYO) | ||
| 91053-HA7-772 | BEARING, NEEDLE (13X25.5X13) (KOYO) | ||
| 91053-HC5-003 | BEARING, NEEDLE (13X25.5X13) (TOYO) | ||
| 91061-ME4-004 | BEARING, RADIAL BALL (22X56X16) | ||
| 1 | 91062-HA7-671 | BEARING, RADIAL BALL (32X58X13) (TOYO) | 1 |
| 1 | 91062-HA7-672 | BEARING, RADIAL BALL (32X58X13) (KOYO) | 1 |
| 1 | 91251-HA0-003 | OIL SEAL (38X64X11) (ARAI) | 1 |
| 1 | 91251-HA0-013 | OIL SEAL (38X64X11) (ARAI) | 1 |
| 1 | 91251-HA0-014 | OIL SEAL (38X64X11) (NOK) | 1 |
| 1 | 91251-HC5-005 | OIL SEAL (38X64X11) (KOYO) | 1 |
| 91252-HA7-671 | OIL SEAL (22X40X9) (ARAI) | ||
| 91252-HA7-672 | OIL SEAL (22X40X9) | ||
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 1 | 95002-02070 | CLIP, TUBE (B7) | 1 |
