Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 710000435 | Harness Ass'y INCLUDES ITEMS 1 TO 579 | ||
| 278000996 | WIRE SEAL | ||
| 8 | 278000998 | Female Terminal | 8 |
| 8 | 278000999 | Wire Seal | 8 |
| 1 | 409010700 | Female Terminal | 1 |
| 3 | 409010300 | Female Terminal | 3 |
| 2 | 710000038 | Female Terminal | 2 |
| 1 | 278000230 | Male Terminal | 1 |
| 278000995 | FEMALE TERMINAL | ||
| 6 | 278000994 | FEMALE TERMINAL | 6 |
| 5 | 278001009 | Female Terminal | 5 |
| 278001062 | Male Terminal Housing, 26 Circuits INCLUDES WIRE SEAL 278001307 | ||
| 1 | 278001063 | MALE TERMINAL HOUSING, 26 CIRCUITS INCLUDES WIRE SEAL 278001307 | 1 |
| 1 | 278001392 | Open Barrel Terminal | 1 |
| 6 | 293000070 | SEALING CAP | 6 |
| 1 | 278001005 | Male Housing, 2 Circuits | 1 |
| 2 | 278000997 | Male Housing, 3 Circuits | 2 |
| 3 | 278000631 | Male Terminal | 3 |
| 3 | 278000632 | Female Terminal | 3 |
| 1 | 409207000 | Male Housing, 3 Circuits | 1 |
| 1 | 278000736 | Male Connector, 6 Circuits | 1 |
| 1 | 409207600 | Male Lock, 3 Circuits | 1 |
| 11 | 409014800 | MALE TERMINAL | 11 |
| 19 | 409015100 | FEMALE TERMINAL | 19 |
| 1 | 710000044 | MALE HOUSING, 3 CIRCUITS | 1 |
| 2 | 710000045 | MALE TERMINAL HOUSING, 4 CIRCUITS | 2 |
| 1 | 515175249 | FEMALE TERMINAL HOUSING, 3 CIRC. | 1 |
| 3 | 409015400 | FEMALE HOUSING, 6 CIRCUITS | 3 |
| 1 | 710000043 | MALE LOCK, 3 CIRCUITS | 1 |
| 2 | 710000046 | MALE LOCK, 4 CIRCUITS | 2 |
| 515175248 | Female Lock, 3 Circuits | ||
| 3 | 409014900 | FEMALE LOCK, 6 CIRCUITS | 3 |
| 2 | 515175303 | PLUG | 2 |
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 710000051 | Female Terminal | ||
| 710000032 | Female Terminal Housing, 4 Circ. | ||
| 3 | 710000050 | WIRE SEAL | 3 |
| 710000049 | Cap | ||
| 409204300 | Female Housing | ||
| 8 | 409004300 | Male Terminal | 8 |
| 1 | 409007300 | Female Terminal | 1 |
| 1 | 278000223 | Female Terminal | 1 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 278000219 | CONNECTOR_MALE 1 CAVITY | ||
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 8 | 278000218 | Wire Seal | 8 |
| 2 | 710000048 | Wire Seal | 2 |
| 710000028 | Female Lock, 2 Circuits | ||
| 710000027 | Female Terminal | ||
| 2 | 710000026 | FEMALE TERMINAL HOUSING, 2 CIRCUITS | 2 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704399 | Was 409901700 Tubing (9 mm) | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 1 | 219704398 | Was 409901600 Tubing 19mm | 1 |
| 1 | 219704402 | Tubing 25 MM 1000MM Long | 1 |
| 5 | 409012100 | Female Terminal | 5 |
| 1 | 710000078 | HOUSING-TAB | 1 |
| 5 | 409012300 | Seal | 5 |
| XXXX | Not Available As Spare Part - RESISTANCE | ||
| 1 | 278001008 | Insulated Sheath | 1 |
| 3 | 278000770 | Insulated Sheath | 3 |
| 2 | 278001007 | Insulated Sheath | 2 |
| 1 | 409012700 | Diode | 1 |
| 1 | 710000107 | MALE HOUSING, 5 CIRCUITS | 1 |
| 1 | 710000153 | Female Terminal Housing, 3 Circ. | 1 |
| 2 | 710000082 | Female Terminal | 2 |
| 219704446 | PROTECTOR TUBE, 4MM 1000MM LONG | ||
| 1 | 409009500 | FEMALE TERMINAL | 1 |
| 710000347 | Female Terminal Housing, 3 Circuits | ||
| 3 | 710000504 | Wire Seal | 3 |
