Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705600118 | RH Caliper INCLUDES ITEMS 1 TO 9 | ||
| 1 | 705600004 | Brake Pad Kit | 1 |
| 1 | 705600078 | Piston Set | 1 |
| 1 | 705600079 | Spring | 1 |
| 1 | 705600080 | Bleeding Screw | 1 |
| 1 | 705600081 | Pin Set (2) | 1 |
| 1 | 705600082 | Compression Boot | 1 |
| 1 | 705600083 | Compression Boot | 1 |
| 705600149 | Lining Support | ||
| 705600119 | LH Caliper INCLUDES ITEMS 10 TO 18 | ||
| 1 | 705600014 | Brake Pad Kit | 1 |
| 705600120 | FRONT MASTER CYLINDER INCLUDES ITEMS 19 TO 27 | ||
| 705600164 | LEVER ARM | ||
| 1 | 705600152 | PISTON KIT | 1 |
| 1 | 705600084 | Cap Set | 1 |
| 1 | 705600085 | BOLT KIT | 1 |
| 1 | 705600148 | SWITCH KIT | 1 |
| 705600087 | BRACKET KIT | ||
| 705600088 | CIRCLIP | ||
| 1 | 705600089 | COMPRESSION BOOT | 1 |
| 1 | 705600290 | Brake Hose | 1 |
| 219704405 | TRIM 30000MM LONG | ||
| 3 | 210261680 | Hex. Flange Screw M6 X 16 | 3 |
| 4 | 705600056 | Banjo Bolt | 4 |
| 10 | 414920600 | Washer | 10 |
| 4 | 250000057 | Hex. Screw M10 X 20, Scotch Grip | 4 |
| 705600291 | Rear Brake Flexible Hose XT | ||
| 705600291 | Rear Brake Flexible Hose STD | ||
| 2 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip | 2 |
| 705600154 | REAR MASTER CYLINDER ASS'Y INCLUDES ITEMS 36 TO 42 | ||
| 705600063 | Piston Set | ||
| 1 | 705600064 | PUSHER BRACKET, HOSE CONNECTOR | 1 |
| 705600068 | Circlip | ||
| 705600090 | Compression Boot | ||
| 1 | 705600067 | Oil Tank | 1 |
| 1 | 705600169 | OIL HOUSING HOSE | 1 |
| XXXX | Not Available As Spare Part - GREASE, THERMA LUBE, 2 G | ||
| 1 | 250400007 | Pin | 1 |
| 705600100 | Yoke | ||
| 1 | 232081414 | Hex. Nut M8 | 1 |
| 710000099 | BRAKE SWITCH | ||
| 705600092 | BANJO BOLT | ||
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 705600122 | REAR CALIPER INCLUDES ITEMS 50 TO 58 | ||
| 1 | 705600150 | Brake Pad Kit | 1 |
| 2 | 250000163 | Hex. Screw M10 X 14, Scotch Grip | 2 |
| 705600011 | Brake Handle INCLUDES ITEMS 60 TO 65 | ||
| 250000030 | Cable Screw | ||
| 1 | 705600184 | CLAMP KIT INCLUDES ITEM 66 | 1 |
| 1 | 705600186 | LEVER | 1 |
| 705600187 | Pivot Kit | ||
| 705600188 | Lever Lock Kit NOT SHOWN | ||
| 205351646 | SOCKET HEAD SCREW M5 X 16 | ||
| 1 | 705600387 | LOCK LEVER | 1 |
| 1 | 705600225 | SPRING | 1 |
| 208032291 | Screw M3 X 22 | ||
| 1 | 232531423 | Elastic Stop Nut M3 | 1 |
| 293600041 | CABLE LUBRICANT, 400 G | ||
| 705600099 | REAR BRAKE CABLE | ||
| 1 | 705600144 | SPRING | 1 |
| 1 | 705600145 | FLAT WASHER | 1 |
| 1 | 705600146 | CABLE BARREL | 1 |
| 1 | 705600388 | NUT | 1 |
| 1 | 705600125 | BRAKE PEDAL, BLACK | 1 |
| 1 | 705600107 | BRAKE PEDAL SPRING | 1 |
| 1 | 503107800 | WASHER | 1 |
| 1 | 293370012 | CIRCLIP | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 2 | 293300053 | O-RING | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 293600063 | BRAKE FLUID, SRF, DOT 4 | ||
| 293600062 | BRAKE FLUID, GTLMA, DOT 4, 12 X 354 ML |
