Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705200196 | WINCH LATCH, BLACK | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 705000585 | FRONT BUMPER, BLACK XT | ||
| 705000591 | Front Bumper, Black XT | ||
| 2 | 207682044 | Hex. Flange Screw M8 X 20 XT | 2 |
| 6 | 207682044 | Hex. Flange Screw M8 X 20 STD | 6 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 XT | 4 |
| 6 | 233281414 | Hex. Flange Elastic Nut M8 | 6 |
| 705000822 | RH Footboard, Slate Gray | ||
| 705000823 | LH Footboard, Slate Gray | ||
| 1 | 293730011 | Black, Dart | 1 |
| 4 | 293730011 | Black, Dart | 4 |
| 705001083 | Footrest, Black | ||
| 4 | 207662584 | Hex. Flange Screw M6 X 25 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 703500137 | Front Fender, Yellow YELLOW /INCLUDES ITEMS 14 TO 17 | ||
| 703500227 | Front Fender, Red VIPER RED / INCLUDES ITEMS 14 TO 17 | ||
| 703500315 | Front Fender, Green LAURENTIAN GREEN / INCLUDES ITEMS 14 TO 17 | ||
| 704900001 | Warning Decal, Death And Injuries ENGLISH | ||
| 704900002 | Warning Decal, Death And Injuries FRENCH | ||
| 1 | 704900011 | Warning Decal, Under 16 Years Old ENGLISH | 1 |
| 1 | 704900012 | Warning Decal, Under 16 Years Old FRENCH | 1 |
| 1 | 704900007 | Caution Decal, Transmission Selector ENGLISH | 1 |
| 704900008 | Caution Decal, Transmission Selector FRENCH | ||
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 1 | 207661244 | Hex. Flange Screw M6 X 12 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 705000708 | Front Fascia, Slate Gray | ||
| 705001048 | Light Protector | ||
| 705000474 | Head Lamp Support | ||
| 4 | 572106600 | Handle | 4 |
| 6 | 250000008 | HEX. SCREW K40 X 40 | 6 |
| 4 | 517168600 | Spring | 4 |
| 4 | 241641040 | PHILLIPS SCREW K40 X 10 | 4 |
| 4 | 293720053 | Grommet | 4 |
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 4 | 224060201 | Flat Washer | 4 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 703500264 | Front Luggage Rack, Black INCLUDES ITEMS 34 TO 36 | ||
| 704900037 | Warning Label, Front Load ENGLISH | ||
| 704900038 | Warning Label, Tray Cover ENGLISH | ||
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 4 | 250000035 | TRUSS PHILLIPS SCREW M6 X 25 | 4 |
| 705000710 | Tank Cover, Slate Gray | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 705000828 | RH Front Mudguard | ||
| 705000827 | LH Front Mudguard | ||
| 12 | 207162044 | Hex. Screw M6 X 20 | 12 |
| 12 | 224060201 | Flat Washer | 12 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 12 |
| 1 | 705000134 | RH TANK PROTECTOR | 1 |
| 1 | 705000133 | LH TANK PROTECTOR | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 1 | 705000713 | PROTECTOR PLATE, SLATE GRAY | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 STD | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" XT | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 STD | 2 |
| 705200535 | Skid Plate | ||
| 4 | 705200533 | CUP | 4 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 705000081 | Lever Indicator | ||
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 570041600 | Rubber Cover | ||
| 705000994 | Mounting Plate XT | ||
| 705000839 | WINCH XT | ||
| 1 | 705000194 | CABLE GUIDE XT | 1 |
| 1 | 705000618 | Hook XT | 1 |
| 1 | 250400022 | Cotter Pin XT | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 XT | 2 |
| 4 | 234081410 | Flat Washer 8 mm XT | 4 |
| 4 | 234181401 | Lock Washer 8 mm XT | 4 |
| 1 | 250400021 | Clevis Pin XT | 1 |
