Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 207582544 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 4 | 207661684 | Hex. Flange Screw M6 X 16 | 4 |
| 1 | 207662054 | Hex. Flange Screw M6 X 20 | 1 |
| 4 | 207662584 | Hex. Flange Screw M6 X 25 | 4 |
| 2 | 207663034 | Hex. Flange Screw M6 X 30 | 2 |
| 5 | 207663544 | Hex. Flange Screw M6 X 35 | 5 |
| 2 | 207664544 | Hex. Flange Screw M6 X 45 | 2 |
| 1 | 207665044 | Hex. Flange Screw M6 X 50 | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 207682534 | Hex. Flange Screw M8 X 25 Package-XXC | 2 |
| 8 | 207763044 | Carriage Bolt M6 X 30 | 8 |
| 3 | 210261280 | Hex. Flange Screw M6 X 12 | 3 |
| 7 | 224061201 | Flat Washer | 7 |
| 2 | 232862412 | Square Nut M6 | 2 |
| 1 | 233251434 | Flange Elastic Nut M5 | 1 |
| 45 | 233261434 | Flange Elastic Nut M6 | 45 |
| 1 | 233281434 | Hex. Flange Elastic Nut M8 | 1 |
| 8 | 234062410 | Flat Washer 6 mm | 8 |
| 2 | 234062670 | Stainless Steel Flat Washer Package-XXC | 2 |
| 2 | 250000712 | Torx Screw M6 X 20 Package-XXC | 2 |
| 2 | 250000117 | Torx Screw M8 X 20, Scotch Grip | 2 |
| 1 | 250000128 | Torx Truss Screw M6 X 20 | 1 |
| 6 | 250000721 | Torx Truss Screw M6 X 16 | 6 |
| 6 | 250000720 | Torx Screw K50 X 16 | 6 |
| 8 | 250000261 | Torx Screw M6 X 16 | 8 |
| 9 | 250000284 | Torx Screw M6 x 25 | 9 |
| 2 | 250000454 | Torx Screw M6 X 12 | 2 |
| 1 | 250300039 | Ball Head Stud | 1 |
| 4 | 293150089 | Tuflok Plastic Rivet | 4 |
| 293450232 | Insert M6 X 1.0 | ||
| 1 | 293830005 | Rubber Bumper | 1 |
| 2 | 390402400 | Pop Rivet 3/16" | 2 |
| 3 | 414479100 | Clip | 3 |
| 4 | 293450275 | Insert | 4 |
| 9 | 705000321 | Oval Washer | 9 |
| 1 | 705002958 | Black, LH Lateral Panel Package-STD Yellow | 1 |
| 1 | 705002959 | Black, RH Side Panel Package-STD Yellow | 1 |
| 1 | 705002946 | PANEL_BODY LH B-190 Package-XXC Black-Yellow | 1 |
| 1 | 705002949 | PANEL_BODY RH B-190 Package-XXC Black-Yellow | 1 |
| 1 | 705008623 | Digital CAMO LH Lateral Panel Package-XXC-Digital Camo | 1 |
| 1 | 705008625 | Digital CAMO RH Lateral Panel Package-XXC-Digital Camo | 1 |
| 1 | 705001910 | Black LH Cap | 1 |
| 1 | 705003556 | Dashboard | 1 |
| 1 | 705002276 | LH Grille | 1 |
| 1 | 705002277 | RH Grille | 1 |
| 1 | 705002282 | Support | 1 |
| 2 | 705002326 | Footrest | 2 |
| 4 | 705002342 | Hook | 4 |
| 1 | 705002343 | Rear Carpet | 1 |
| 1 | 705002353 | Cap | 1 |
| 2 | 705002408 | Red Reflector | 2 |
| 2 | 705002409 | Amber Reflector | 2 |
| 1 | 705002420 | NECK CAP | 1 |
| 1 | 705002667 | Engine Cover Support | 1 |
| 6 | 705003264 | Grommet | 6 |
| 1 | 705003505 | Bumper Support | 1 |
| 1 | 705003510 | Body Tube | 1 |
| 1 | 705003511 | Front Tube | 1 |
| 1 | 705003599 | Bracket | 1 |
| 1 | 705003646 | Engine Cover Support | 1 |
| 1 | 705003948 | Front Facia | 1 |
| 1 | 705004176 | LH Footboard | 1 |
| 1 | 705004177 | RH Footboard | 1 |
| 715002157 | YELLOW FRONT FENDER KIT Package-STD Yellow | ||
| 1 | 715002154 | Deep Black Front Fender Kit Package-XXC Black-Yellow | 1 |
| 1 | 715002550 | BLACK FRONT FENDER KIT Package-XXC Digital Camo North America | 1 |
| 1 | 715002570 | BLACK FRONT FENDER KIT Package-XXC Digital Camo Europe | 1 |
| 1 | 715002570 | BLACK FRONT FENDER KIT Package-XXC Digital Camo International | 1 |
| 705004307 | LH INNER FENDER | ||
| 1 | 705004308 | RH INNER FENDER | 1 |
| 1 | 705004416 | Lever Indicator | 1 |
| 1 | 705004729 | RH Footboard/Fender | 1 |
| 1 | 705004730 | LH Footboard/Fender | 1 |
| 1 | 705004731 | LH Rear Facia | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 705004732 | RH Rear Facia | 1 |
| 1 | 705004850 | Front Bumper Plate | 1 |
| 1 | 705004966 | Engine Cover | 1 |
| 1 | 705004988 | Panel Extension | 1 |
| 1 | 705004993 | Welded Front Bumper | 1 |
| 1 | 705005840 | Reflective Sheet | 1 |
| 1 | 715002374 | Protective Plate Kit Package-STD | 1 |
| 1 | 705007820 | Skid Plate Package-XXC | 1 |
| 1 | 705204031 | Central Skid Plate Package-XXC | 1 |
| 2 | 207762044 | Carriage Bolt M6 X 20 Package-XXC | 2 |
| 1 | 705005809 | Spacer | 1 |
| 1 | 715001881 | YELLOW REAR FENDER KIT Package-STD Yellow | 1 |
| 1 | 715001887 | REAR FENDER KIT Package-XXC Black-Yellow | 1 |
| 1 | 715002572 | Black Rear Fender Kit Package-XXC Digital Camo North America | 1 |
| 1 | 715002574 | Black Rear Fender Kit Package-XXC Digital Camo International | 1 |
| 1 | 715002575 | REAR FENDER KIT Package-XXC Digital Camo Europe | 1 |
| 2 | 705003668 | Oblong Grommet | 2 |
| 1 | 715001493 | Yellow Central Pannel Kit Package-STD Yellow, XXC Black-Yellow | 1 |
| 1 | 715002577 | Digital Camo Central Pannel Kit Package-XXC Digital Camo North America | 1 |
| 1 | 715002581 | Digital Camo Central Pannel Kit Package-XXC Digital Camo Europe | 1 |
| 1 | 715002581 | Digital Camo Central Pannel Kit Package-XXC Digital Camo International | 1 |
