Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 5PX-17541-00-00 | CASE, TRANSFER 1 | 1 |
| 1 | 93306-00907-00 | BEARING | 1 |
| 1 | 5PX-17521-10-00 | HOUSING, BEARING | 1 |
| 4 | 90110-06039-00 | BOLT, HEXAGON SOCKET HEAD | 4 |
| 1 | 93306-20601-00 | BEARING (B6206C3) | 1 |
| 1 | 4WM-13286-00-00 | CLEANER | 1 |
| 1 | 4WM-17682-00-00 | SPROCKET, CHAIN DRIVE | 1 |
| 5PX-1755A-10-00 | MIDDLE DRIVEN SHAFT ASSY | ||
| 1 | 4WM-16139-00-00 | CHAIN, PRIMARY | 1 |
| 1 | 5PX-17929-00-00 | GASKET 1 | 1 |
| 1 | 4WM-17931-00-00 | GASKET 2 | 1 |
| 1 | 5PX-17542-00-00 | CASE, TRANSFER 2 | 1 |
| 1 | 5PX-13100-00-00 | OIL PUMP ASSY | 1 |
| 2 | 90110-06004-00 | BOLT, HEXAGON SOCKET HEAD | 2 |
| 1 | 93210-48214-00 | O-RING | 1 |
| 2 | 93603-07073-00 | PIN, DOWEL | 2 |
| 1 | 4WM-13116-00-00 | GASKET, PUMP CASE | 1 |
| 3 | 90110-06047-00 | BOLT, HEXAGON SOCKET HEAD | 3 |
| 2 | 90110-06039-00 | BOLT, HEXAGON SOCKET HEAD | 2 |
| 1 | 95814-08016-00 | BOLT, FLANGE | 1 |
| 1 | 90430-08119-00 | GASKET | 1 |
| 2 | 99530-10114-00 | PIN, DOWEL | 2 |
| 6 | 91314-06025-00 | BOLT, HEXAGON SOCKET HEAD | 6 |
| 1 | 5PX-17691-00-00 | PLATE 3 | 1 |
| 1 | 93102-40330-00 | OIL SEAL | 1 |
| 1 | 93210-27672-00 | O-RING | 1 |
| 1 | 90387-3003P-00 | COLLAR | 1 |
| 1 | 90340-14132-00 | PLUG, STRAIGHT SCREW | 1 |
| 1 | 214-11198-01-00 | GASKET | 1 |
| 1 | 5PX-13421-00-00 | STRAINER 2 | 1 |
| 1 | 93210-14003-00 | O-RING | 1 |
| 1 | 91317-06012-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 1 | 5PX-17631-00-00 | CAP | 1 |
| 5PX-17932-01-00 | GASKET, 3 | ||
| 1 | 5PX-13582-00-00 | PIPE | 1 |
| 1 | 5PX-13132-00-00 | JOINT | 1 |
| 1 | 93210-35512-00 | O-RING | 1 |
| 1 | 90110-06039-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 1 | 5PX-15362-00-00 | PLUG, OIL LEVEL | 1 |
| 1 | 90179-22006-00 | NUT | 1 |
| 1 | 90208-22002-00 | WASHER, CONICAL SPRING | 1 |
| 1 | 90179-08004-00 | NUT | 1 |
| 4 | 91314-08050-00 | BOLT, HEXAGON SOCKET HEAD | 4 |
| 1 | 5PX-15779-00-00 | COVER | 1 |
| 1 | 90340-32002-00 | PLUG, STRAIGHT SCREW | 1 |
| 1 | 93210-32172-00 | O-RING | 1 |
| 1 | 92014-06010-00 | BOLT, BUTTON HEAD | 1 |
| 1 | 90430-06016-00 | GASKET | 1 |
| 1 | 93210-92448-00 | O-RING | 1 |
| 5 | 91314-06050-00 | BOLT, HEXAGON SOCKET HEAD | 5 |
| 2 | 91314-08055-00 | BOLT, HEXAGON SOCKET HEAD | 2 |
| 1 | 5PX-17613-00-00 | STAY | 1 |
| 1 | 5PX-17654-00-00 | SPACER 1 | 1 |
| 91317-10050-00 | BOLT | ||
| 5 | 92907-10600-00 | WASHER, PLATE | 5 |
| 3 | 95814-10050-00 | BOLT, FLANGE | 3 |
| 99480-10018-00 | PIN | ||
| 2 | 4WM-17653-00-00 | SLIDER | 2 |
| 2 | 93606-76259-00 | PIN, DOWEL | 2 |
| 1 | 5PX-17076-00-00 | COVER | 1 |
| 1 | 5PX-17655-00-00 | DAMPER, SLIDER | 1 |
| 1 | 5PX-1542B-00-00 | DAMPER 2 | 1 |
| 1 | 5PX-1542C-00-00 | DAMPER 3 | 1 |
| 1 | 5PX-15491-00-00 | PROTECTOR | 1 |
| 1 | 5PX-15449-00-00 | RING, RUBBER | 1 |
| 1 | 5PX-17665-00-00 | PLATE 1 | 1 |
| 1 | 5PX-17675-00-00 | PLATE 2 | 1 |
| 1 | 4H7-15486-00-00 | GROMMET | 1 |
| 1 | 90209-06096-00 | WASHER | 1 |
| 1 | 95807-06012-00 | BOLT, FLANGE | 1 |
| 6 | 91314-06030-00 | BOLT, HEXAGON SOCKET HEAD | 6 |
| 1 | 5PX-17651-00-00 | PULLEY, BELT | 1 |
| 1 | 5PX-17538-00-00 | CAP, HOUSING | 1 |
| 5PX-17933-01-00 | GASKET, 4 | ||
| 7 | 91317-06085-00 | BOLT | 7 |
| 9 | 91317-06025-00 | BOLT, HEXAGON SOCKET HEAD | 9 |
| 3 | 91317-06045-00 | BOLT | 3 |
| 5PX-1763A-00-00 | PLATE, CAP | ||
| 3 | 90269-07005-00 | RIVET | 3 |
| 90465-08038-00 | CLAMP | ||
| 1 | 5PX-17446-00-00 | PLATE | 1 |
| 5PX-17471-00-00 | PLATE, COVER | ||
| 2 | 90154-06008-00 | SCREW, BINDING | 2 |
| 4 | 90201-05015-00 | WASHER, PLATE | 4 |
| 2 | 90480-13007-00 | GROMMET | 2 |
| 90480-13006-00 | GROMMET | ||
| 1 | 90387-07007-00 | COLLAR | 1 |
| 1 | 90111-06039-00 | BOLT, HEX. SOCKET BUTTON | 1 |
