Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | BRX-14101-10-00 | Carburetor Assy 1 | 1 |
| 1 | 4JT-14171-00-00 | . .Plunger, Starter | 1 |
| 1 | 4SR-14985-00-00 | . .Float | 1 |
| 1 | 4JT-14984-00-00 | . .Gasket, Float Chamber | 1 |
| 1 | 4MX-14115-00-00 | . .Plug, Screw | 1 |
| 1 | 4MX-14561-00-00 | . .O-Ring | 1 |
| 1 | 4MX-14392-00-00 | . .Valve, Needle | 1 |
| 2 | 4XL-14146-00-00 | . .Plate | 2 |
| 1 | 4MX-14948-07-00 | . .Jet, Slow (#50) AP | 1 |
| 1 | 4MX-14948-08-00 | . .Jet, Slow (#52) AP | 1 |
| 1 | 4MX-14948-09-00 | . .Jet, Slow (#55) AP | 1 |
| 1 | 4MX-14948-10-00 | . .Jet, Slow (#58) AP | 1 |
| 1 | 4MX-14948-11-00 | . .Jet, Slow (#60) AP | 1 |
| 1 | 4MX-14948-12-00 | . .Jet, Slow (#62) AP | 1 |
| 1 | B4X-14948-17-00 | . .Jet, Slow (#75) AP | 1 |
| 1 | B4X-14948-19-00 | . .Jet, Slow (#80) AP | 1 |
| 1 | B4X-14948-18-00 | . .Jet, Slow (#78) AP | 1 |
| 1 | B4X-14948-16-00 | . .Jet, Slow (#72) AP | 1 |
| 1 | B4X-14948-15-00 | . .Jet, Slow (#70) AP | 1 |
| 1 | B4X-14948-14-00 | . .Jet, Slow (#68) AP | 1 |
| 1 | B4X-14948-13-00 | . .Jet, Slow (#65) STD | 1 |
| 1 | B4X-14916-DF-00 | . .Needle (Nydf) AP | 1 |
| 1 | B4X-14916-FD-00 | . .Needle (Nyfd) AP | 1 |
| 1 | B4X-14916-FE-00 | . .Needle (Nyfe) AP | 1 |
| 1 | B4X-14916-FF-00 | . .Needle (Nyff) AP | 1 |
| 1 | B4X-14916-FG-00 | . .Needle (Nyfg) AP | 1 |
| 1 | B4X-14916-FH-00 | . .Needle (Nyfh) AP | 1 |
| 1 | B4X-14916-CD-00 | . .Needle (Nycd) AP | 1 |
| 1 | B4X-14916-CE-00 | . .Needle (Nyce) AP | 1 |
| 1 | B4X-14916-CF-00 | . .Needle (Nycf) STD | 1 |
| 1 | B4X-14916-CG-00 | . .Needle (Nycg) AP | 1 |
| 1 | B4X-14916-CH-00 | . .Needle (Nych) AP | 1 |
| 1 | B4X-14916-DD-00 | . .Needle (Nydd) AP | 1 |
| 1 | B4X-14916-DE-00 | . .Needle (Nyde) AP | 1 |
| 1 | B4X-14916-DG-00 | . .Needle (Nydg) AP | 1 |
| 1 | B4X-14916-DH-00 | . .Needle (Nydh) AP | 1 |
| 1 | B4X-14916-ED-00 | . .Needle (Nyed) AP | 1 |
| 1 | B4X-14916-EE-00 | . .Needle (Nyee) AP | 1 |
| 1 | B4X-14916-EF-00 | . .Needle (Nyef) AP | 1 |
| 1 | B4X-14916-EG-00 | . .Needle (Nyeg) AP | 1 |
| 1 | B4X-14916-EH-00 | . .Needle (Nyeh) AP | 1 |
| 1 | 4MX-14919-00-00 | . .Clip | 1 |
| 1 | BRX-14340-65-00 | . .Valve Assy | 1 |
| 1 | 5HC-14261-00-00 | . .Holder | 1 |
| 1 | 5HC-14126-00-00 | . .Gasket | 1 |
| 1 | 4SR-14105-01-00 | . .Pilot Screw Set | 1 |
| 1 | 5HC-14131-00-00 | . .Spring, Throttle Valve | 1 |
| 1 | 633-14159-00-00 | . .Clip | 1 |
| 4 | 91312-04014-00 | . .Bolt, Hexagon Socket Head | 4 |
| 2 | 4XL-14197-10-00 | . .Pipe | 2 |
| 1 | 4XL-14196-10-00 | . .Pipe, Over Flow 1 | 1 |
| 1 | 676-14548-00-00 | . .Pin, Float Arm | 1 |
| 5 | 3TJ-14137-40-00 | . .Clip | 5 |
| 1 | 4MX-14943-42-00 | . .Jet, Main (#175) AP | 1 |
| 1 | 4MX-14943-40-00 | . .Jet, Main (#165) AP | 1 |
| 1 | 4MX-14943-91-00 | . .Jet, Main (#168) AP | 1 |
| 1 | 4MX-14943-41-00 | . .Jet, Main (#170) AP | 1 |
| 1 | 4MX-14943-92-00 | . .Jet, Main (#172) AP | 1 |
| 1 | 4MX-14943-89-00 | . .Jet, Main (#158) AP | 1 |
| 1 | 4MX-14943-39-00 | . .Jet, Main (#160) STD | 1 |
| 1 | 4MX-14943-90-00 | . .Jet, Main (#162) AP | 1 |
| 1 | 4MX-14943-88-00 | . .Jet, Main (#152) AP | 1 |
| 1 | 4MX-14943-38-00 | . .Jet, Main (#155) AP | 1 |
| 1 | 4MX-14943-37-00 | . .Jet, Main (#150) AP | 1 |
| 1 | 4MX-14943-87-00 | . .Jet, Main (#148) AP | 1 |
| 1 | 4MX-14194-00-00 | . .Ring | 1 |
| 2 | 91317-04012-00 | . .Bolt, Hexagon Socket Head | 2 |
| 1 | 4XL-1410E-00-00 | . .Hose | 1 |
| 1 | 4JT-1494F-01-00 | . .Jet (#35) STD | 1 |
| 1 | 4JT-1494F-03-00 | . .Jet (#40) AP | 1 |
| 1 | 4JT-1494F-07-00 | . .Jet (#50) AP | 1 |
| 1 | 4JT-1494F-11-00 | . .Jet (#60) AP | 1 |
| 1 | 4JT-1494F-09-00 | . .Jet (#55) AP | 1 |
| 1 | 4JT-1494F-05-00 | . .Jet (#45) AP | 1 |
| 5HC-14146-00-00 | . .Plate | ||
| 1 | 98580-04006-00 | . .Screw, Pan Head | 1 |
| 1 | 5NX-1410H-11-00 | . .Solenoid Valve | 1 |
| 1 | 4JT-14147-00-00 | . .O-Ring | 1 |
| 1 | 5HC-14264-00-00 | . .Collar | 1 |
| 1 | 5HC-14275-00-00 | . .Spring | 1 |
| 1 | 5HC-14922-00-00 | . .Screw, Throttle | 1 |
| 1 | 5HC-14934-00-00 | . .Spring, Throttle Stop | 1 |
| 1 | B4X-14208-00-00 | . .Lever Comp. 1 | 1 |
| 2 | 5HC-14216-09-00 | . .Screw | 2 |
| 1 | B4X-85885-00-00 | . .Throttle Sensor Assy | 1 |
| 1 | 5NX-14562-00-00 | . .O-Ring | 1 |
| 1 | 5NX-14216-00-00 | . .Screw | 1 |
