Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 20S-YK241-00-P1 | FUEL TANK COMP. UR FOR RYC1, RYY AND RYCY | ||
| 20S-Y2410-00-04 | FUEL TANK COMP. UR FOR BWC1, RYW AND RYCW | ||
| 36P-24240-00-00 | GRAPHIC SET UR FOR BWC1, RYW AND RYCW | ||
| 1 | 20S-24191-00-00 | BRACKET, FUEL TANK 1 | 1 |
| 2 | 90480-16010-00 | GROMMET | 2 |
| 2 | 90387-06068-00 | COLLAR | 2 |
| 2 | 90119-06062-00 | BOLT, WITH WASHER | 2 |
| 2 | 20S-24183-00-00 | DAMPER, LOCATING 3 | 2 |
| 4 | 90465-15011-00 | CLAMP | 4 |
| 1 | 20S-13907-00-00 | FUEL PUMP COMP. | 1 |
| 1 | 13S-24491-00-00 | BRACKET, FUEL PUMP | 1 |
| 1 | 5JW-24486-00-00 | O-RING | 1 |
| 6 | 90110-05028-00 | BOLT, HEXAGON SOCKET HEAD | 6 |
| 2 | 90111-06127-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 2 | 5VX-24181-00-00 | DAMPER, LOCATING 1 | 2 |
| 1 | 90387-061W6-00 | COLLAR | 1 |
| 1 | 91312-06090-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 1 | 20S-2413Y-00-00 | BRACKET, TANK FITTING | 1 |
| 2 | 95702-06500-00 | NUT, WITH WASHER | 2 |
| 2 | 90387-06299-00 | COLLAR | 2 |
| 1 | 20S-24181-00-00 | DAMPER, LOCATING 1 | 1 |
| 1 | 20S-2414H-00-00 | DAMPER, PLATE 1 | 1 |
| 1 | 20S-21296-00-00 | NUT | 1 |
| 1 | 5JJ-24602-00-00 | CAP ASSY | 1 |
| 3 | 90110-05112-00 | BOLT, HEXAGON SOCKET HEAD | 3 |
| 1 | 91317-05010-00 | BOLT, HEX. SOCKET HEAD | 1 |
| 1 | 5VX-13971-00-00 | PIPE, FUEL 1 | 1 |
| 1 | 90464-16005-00 | CLAMP | 1 |
| 1 | 90445-106J2-00 | HOSE (L650) | 1 |
| 1 | 90467-090A2-00 | CLIP | 1 |
| 1 | 90467-100A1-00 | CLIP FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 1 | 20S-24106-00-00 | TANK SIDE COVER ASSY 1 | 1 |
| 1 | 20S-2173T-00-00 | TAPE 1 | 1 |
| 1 | 20S-24108-00-00 | TANK SIDE COVER ASSY 2 | 1 |
| 1 | 20S-2173U-00-00 | TAPE 2 | 1 |
| 1 | 5GK-2118K-00-00 | LABEL, CAUTION FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 2 | 5JW-2413B-00-00 | EMBLEM | 2 |
| 1 | 5C7-24170-00-00 | CANISTER ASSY FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 36P-2419F-00-00 | BRACKET, CANISTOR FOR CALIFORNIA, RYCW AND RYCY | ||
| 2 | 95802-06016-00 | BOLT, FLANGE FOR CALIFORNIA, RYCW AND RYCY | 2 |
| 2 | 90480-13163-00 | GROMMET FOR CALIFORNIA, RYCW AND RYCY | 2 |
| 2 | 90387-062L2-00 | COLLAR FOR CALIFORNIA, RYCW AND RYCY | 2 |
| 1 | 5RB-24180-00-00 | ROLL OVER VALVE ASSY FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 1 | 90445-11065-00 | HOSE (L30) FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 36P-24314-00-00 | PIPE 4 FOR CALIFORNIA, RYCW AND RYCY | ||
| 1 | 36P-14466-00-00 | PIPE FOR CALIFORNIA, RYCW AND RYCY | 1 |
| 36P-24315-00-00 | PIPE 5 FOR CALIFORNIA, RYCW AND RYCY | ||
| 5 | 90467-100A1-00 | CLIP FOR CAL, RYCW AND RYCY | 5 |
| 2 | 95802-08016-00 | BOLT, FLANGE FOR CALIFORNIA, RYCW AND RYCY | 2 |
| 36P-24667-00-00 | GUIDE, PIPE FOR CALIFORNIA, RYCW AND RYCY | ||
| 1 | 95802-06010-00 | BOLT, FLANGE FOR CALIFORNIA, RYCW AND RYCY | 1 |
