Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 572089400 | RH Protector | ||
| 572089500 | LH Protector | ||
| 415041803 | Seat Cover | ||
| 415041902 | Foam Seat | ||
| 732601186 | Hex. Screw M8 x 20 | ||
| 517286500 | Rack Ass'y | ||
| 415050200 | LH Grip, 370 mm | ||
| 415050300 | RH Grip, 250 mm | ||
| 732601175 | Screw M8 x 25 | ||
| 414108300 | Hair Pin | ||
| 414988700 | Reflective Sheet | ||
| 580651300 | RH Rear Moulding Ass'y Includes 11 - 14. | ||
| 580651400 | LH Rear Moulding Ass'y | ||
| 414510100 | REFLECTOR, RED | ||
| 2 | 222851065 | SCREW-PAN HD.PH.DIN.7985A | 2 |
| 224151101 | WASHER-LOCK SERRATED DIN.6798A | ||
| 6 | 365901100 | HEX. SCREW 12 X 3/4 | 6 |
| 4 | 228761045 | Elastic Flange Nut M6 | 4 |
| 1 | 418001800 | HEAT GRIP DECAL | 1 |
| 732601221 | «T» Bolt | ||
| 4 | 732610072 | Push Nut | 4 |
| 572051200 | Rear Trunk | ||
| 5 | 517225900 | Flat Washer | 5 |
| 5 | 390906800 | Pop Rivet 3/16" | 5 |
| 409206100 | MALE TERMINAL | ||
| 410108500 | Rocker Switch | ||
| 4 | 222082065 | Hex. Screw M8 x 20 | 4 |
| 4 | 224781140 | Lock Washer 8 mm | 4 |
| 4 | 224081171 | Flat Washer 8 mm | 4 |
| 517272510 | Rear Bumper | ||
| 2 | 503169800 | Yellow Washer | 2 |
| 2 | 732601253 | Self Tapping Phillips Screw | 2 |
| 2 | 414516400 | Washer | 2 |
| 414513700 | Lens | ||
| 1 | 410504000 | Bulb, Tail Lamp | 1 |
| 2 | 228751045 | Elastic Flange Nut M5 | 2 |
| 415041200 | Taillamp Housing | ||
| 517257300 | Guide | ||
| 570027400 | Rubber Shim | ||
| 2 | 517251300 | SPACER | 2 |
| 572038200 | Lock Lever | ||
| 4 | 414821400 | Pin | 4 |
| 517257600 | Eye Bolt | ||
| 415044600 | Backrest Ass'y Includes 42 - 56. | ||
| 1 | 414820900 | TILLER HANDLE | 1 |
| 414821000 | Cap | ||
| 517287600 | RH Arm | ||
| 517289800 | LH Arm | ||
| 414813300 | Recliner | ||
| 2 | 222082565 | Hex. Screw M8 x 25 | 2 |
| 1 | 224081201 | FLAT WASHER | 1 |
| 2 | 224781140 | Lock Washer 8 mm | 2 |
| 2 | 222082065 | Hex. Screw M8 x 20 | 2 |
| 2 | 228581045 | Elastic Stop Nut M8 | 2 |
| 1 | 413703000 | Loctite 242, 10 cc | 1 |
| 414821200 | Backrest Foam | ||
| 415044603 | Backrest Cover | ||
| 1 | 415015500 | STRIP | 1 |
| 414819600 | Washer | ||
| 4 | 228581045 | Elastic Stop Nut M8 | 4 |
| 732600009 | PAN HEAD FORMING SCREW M6 X 18 | ||
| 2 | 410110000 | Heating Grip | 2 |
| 4 | 732900030 | Spring Washer 8 mm | 4 |
| 414819500 | Washer | ||
| 517250000 | Nut | ||
| 2 | 409204200 | FEMALE HOUSING | 2 |
| 414985400 | Holding Strap | ||
| 1 | 409209300 | MALE HOUSING | 1 |
| 414728000 | SEAT BUCKLE | ||
| 517293700 | Washer | ||
| 732601255 | Screw | ||
| 572089300 | Plate | ||
| 517286600 | RH Arm (Rack) | ||
| 517286700 | LH Arm (Rack) | ||
| 572091100 | Snow Guard (Blue) | ||
| 390909600 | Rivet (Black) 3/16 | ||
| 4 | 517225900 | Flat Washer | 4 |
| 572088700 | RH Footrest | ||
| 572088800 | LH Footrest | ||
| 211000074 | SCREW-PLASTITE HEX.UNSL | ||
| 6 | 224061121 | Flat Washer | 6 |
| 529027900 | Tool Kit | ||
| 572036310 | BOX COVER | ||
| 529030700 | Wrench-Adjuster | ||
| 4 | 390906800 | Pop Rivet 3/16" | 4 |
| 1 | 223580804 | Screw Set M8 x 8 | 1 |
| 415050400 | Grip, Short, 60 mm | ||
| 572089200 | Switch Housing | ||
| 572086200 | Sub-Seat | ||
| 2 | 211200021 | Washer Plastic 6 mm | 2 |
| 228561065 | Nut M6 | ||
| 517290000 | Guide | ||
| 570063800 | Outer Spacer | ||
| 572088900 | Spacer Block | ||
| 517275500 | Support | ||
| 572097000 | Reinforcement | ||
| 518301100 | Retainer Plate | ||
| 518306000 | Reinforcement | ||
| 4 | 390402200 | Pop Rivet 3/16" | 4 |
| 2 | 228561045 | Elastic Stop Nut M6 | 2 |
| 1 | 517008700 | Welded Hitch Plate | 1 |
| 517001700 | Clevis Pin | ||
| 1 | 371800200 | Cotter Pin | 1 |
| 517223500 | Reinforcement | ||
| 2 | 517191700 | SPACER | 2 |
| 2 | 222065065 | Hex. Screw M6 x 50 (Europe) | 2 |
| 2 | 222262065 | Carriage Bolt M6 x 20 (Europe) | 2 |
| 517256100 | Inner Plate | ||
| 4 | 222262065 | Carriage Bolt M6 x 20 (Europe) | 4 |
| 414998500 | Instruction Label (Hitch) | ||
| 8 | 228761045 | Elastic Flange Nut M6 | 8 |
