Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 45030000044 | ENGINE CASE CPL. '97 | |
| 3 | 45030039000 | ENGINE CASE GASKET | |
| 4 | 45030023000 | DOWEL PIN | |
| 5 | 0912060403 | AH SCREW DIN0912-M 6X40 | |
| 6 | 0912060453 | AH SCREW DIN0912-M 6X45 | 3 |
| 7 | 0912060503 | AH SCREW DIN0912-M 6X50 | |
| 8 | 0912060553 | AH SCREW DIN0912-M 6X55 | 2 |
| 9 | 45030001000 | CLUTCH COVER | |
| 10 | 45030025000 | GASKET CLUTCH COVER | |
| 11 | 45030002000 | IGNITION COVER | |
| 12 | 45030092000 | RETAINING SPRING | |
| 13 | 45039006000 | IGNITION COIL CPL | |
| 14 | 45039005000 | FLYWHEEL | |
| 16 | 36330030000 | CYL BASE GASKET | |
| 17 | 45030006000 | CYLINDER HEAD | |
| 18 | 36330036000 | CYL HEAD GASKET | |
| 19 | 36330042000 | STUD BOLTM6XI12 | |
| 20 | 0934060003 | hex nut DIN 934 M6 | 5 |
| 21 | 0125060003 | WASHER DIN0125-A 6,4 | 8 |
| 22 | 36330050000 | INTAKE FLANGE FOR DELLORTO | |
| 23 | 49130438000 | GASKET FOR INTAKE PIPE | |
| 24 | 45030091000 | RUBBER GASKET | |
| 25 | 45030095000 | RUBBER | |
| 26 | 45030047000 | SECURING GUIDE | |
| 27 | 15130020000 | OIL LEVEL CONTR. PLUG PVCM14 | |
| 28 | 15130021000 | SEAL RING 14,2X20X1 | |
| 29 | 0933080103 | HH SCREW DIN0933-M 8X10 | 1 |
| 30 | 45038017000 | SEAL RING 8X14X1 AI | 1 |
| 31 | 45030018000 | % CRANKSHAFT STROKE 41,7MM | |
| 32 | 45030015000 | CON. ROD REPAIR KIT | |
| 33 | 45030034000 | NEEDLE CAGE | |
| 34 | 45030074000 | CIRCLIP | |
| 35 | 45030007000 | PISTON CPL. 39MM | |
| 36 | 36330031000 | PISTON RING D=39MM | |
| 37 | 0625062031 | BALL BEARING 6203 TN9.C3 | |
| 38 | 15130086000 | RADIAL SEAL RING | |
| 39 | 0888025030 | WOODRUFF KEY DIN6888-2,5X3 | 1 |
| 40 | 16030028000 | NUT | |
| 41 | 45032001000 | CLUTCH HUB CPL | |
| 42 | 45032002000 | INNER CLUTCH HUB | |
| 43 | 16032011000 | CLUTCH BLOCK | |
| 44 | 45032005000 | CLUTCH SPRING | |
| 45 | 45032008000 | JOINT FOR BLOCKS | |
| 46 | 45032045000 | ROLLER 3X13,8 | |
| 47 | 16032095000 | BUSH | |
| 48 | 45033050000 | STARTING SHAFT | |
| 49 | 45033052000 | KICKST. RATCHET | |
| 50 | 45033056000 | SPRING | |
| 51 | 45032002044 | CLUTCH HUB CPL. | |
| 52 | 16233039000 | STOP SCREW | |
| 53 | 16233040000 | RUBBER | |
| 54 | 45039003000 | GROUND PLATE | |
| 55 | 45033076000 | KICKST. RUBBER | |
| 56 | 0933070253 | HH SCREW DIN0933-M 7X25 | |
| 57 | 45033054000 | SPRING | |
| 58 | 45033051000 | KICKSTARTER SPROCKETS | |
| 59 | 45033077000 | PLASTIC CAP KICKSTARTER | |
| 60 | 0770012020 | O-RING 16X1,75 | |
| 61 | 45033078000 | WASHER | |
| 62 | 45033002000 | COUNTER SHAFT | |
| 63 | 0625062027 | BALL BEARING 6202 2RS1 C3 | 2 |
| 64 | 15133028000 | RADIAL SEAL RING | |
| 65 | 45033029000 | CHAIN SPROCKET 11-Z | |
| 66 | 15133031000 | WASHER 12,2X20X1,8 | |
| 67 | 45039008000 | RUBBER CAP | |
| 68 | 45033022000 | WASHER | |
| 69 | 45030009000 | CYLINDER + PISTON | |
| 70 | 36333096000 | CIRCLIP 14X1,2 | |
| 71 | 45033023000 | WASHER 16X25X0,5 | 1 |
| 72 | 0471160150 | CIRCLIP DIN0471-16X1 | |
| 73 | 0125050003 | WASHER DIN0125-A 5,3 | 2 |
| 74 | 45030090000 | SCREW M4X10 | 3 |
| 75 | 45039093004 | SPARK PLUG BOSCH W 4 AC | |
| 76 | 45039090000 | SPARK PLUG CONNECTOR | |
| 77 | 0797050003 | TOOTH LOCK WASH. DIN6797-J 5,3 | |
| 78 | 45030046000 | EXHAUST GASKET ENGINE S5-E | |
| 79 | 0912050123 | AH SCREW DIN0912-M 5X12 | 1 |
| 81 | 45033024000 | CIRCLIP 17,5X1,2 | |
| 82 | 36330032000 | COMP. RING | |
| 83 | 15130033000 | PISTON PIN | |
| 84 | 0912060603 | AH SCREW DIN0921-M 6X60 | |
| 86 | 0912050203 | AH SCREW DIN0912-M 5X20 | 2 |
| 87 | 0933060253 | HH SCREW DIN0933-M 6X25 | 2 |
| 88 | 15133032000 | HH-NUT M12X1,25 6MM HIGH | |
| 89 | 45033070000 | STARTING LEVER | |
| 90 | 51010086000 | SELF LOCKING NUT M 6 COPPER | |
| 91 | 0933060203 | HH SCREW DIN0933-M 6X20 | 2 |
| 92 | 45030079000 | HH-NUT M6 36MM HIGH WS=12 | |
| 99 | 45030099000 | SET OF GASKETS | |
| 99 | 45030099100 | GASKET SET SEAL RINGS |
