Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 503190818 | RUNNER 162 162" Track | 2 |
| 1 | 503191050 | RUNNER 151 151" Track | 2 |
| 2 | 503190368 | Rail 151", Black 151" Track | |
| 2 | 503190383 | RAIL 151, YELLOW 151" Track | 2 |
| 2 | 503190864 | Shoe Slider 162", Yellow 162" Track | |
| 2 | 503190866 | SHOE SLIDER 162, BLACK 162" Track | |
| 3 | 208562560 | Phillips Screw M6 X 25 | 2 |
| 4 | 232561414 | Elastic Stop Nut M6 | 2 |
| 5 | 572075400 | RUNNER PROTECTOR | |
| 6 | 207152544 | HEX. SCREW M5 X 25 | |
| 7 | 232551414 | Elastic Stop Nut M5 | 2 |
| 8 | 391301600 | Washer | 4 |
| 9 | 503155300 | Tensioner | |
| 10 | 503189160 | TENSIONER SPACER | |
| 11 | 207063044 | Hex. Screw M6 X 30 | 4 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 13 | 230100044 | HEX. SCREW M10 X 100 | |
| 14 | 233601416 | Elastic Locking Nut M10 X 1.5 | 2 |
| 15 | 503190905 | RUBBER STOPPER ASS'Y | |
| 16 | 570063000 | Rubber Stopper | |
| 17 | 572084800 | Reinforcement Stopper | 1 |
| 18 | 207054044 | HEX. SCREW M5 X 40 | |
| 19 | 391301700 | Washer | 8 |
| 20 | 232551414 | Elastic Stop Nut M5 | 4 |
| 21 | 503190429 | Rear Axle | 1 |
| 22 | 503190430 | Spacer | 1 |
| 23 | 503190682 | Labyrinth Seal | 1 |
| 24 | 503190428 | Rear Wheel Spacer | 3 |
| 25 | 503190432 | Washer | 1 |
| 26 | 503190342 | Wheel 180 With Pattern Ass'y, Yellow X / Includes 26 to 27 | 2 |
| 26 | 503190752 | WHEEL 180, FULL MOON Includes 26 to 27 | 2 |
| 26 | 503191103 | WHEEL 180 WITH PATTERN ASS'Y, RED Includes 26 to 27 | 2 |
| 27 | 503190396 | Ball Bearing | 1 |
| 28 | 503190395 | Wheel 180 Includes 28 to 29 | 1 |
| 29 | 503190396 | Ball Bearing | 1 |
| 30 | 503190439 | Washer | 2 |
| 31 | 250000019 | Hex. Screw With Nylon | 2 |
| 32 | 503191317 | WHEEL 147 WITH PATTERN ASS'Y, FULL MOON Includes 32 to 33 | 2 |
| 32 | 503191319 | WHEEL 147 WITH PATTERN ASS'Y, YELLOW X / Includes 32 to 33 | |
| 32 | 503191320 | WHEEL 147 WITH PATTERN ASS'Y, RED Includes 32 to 33 | |
| 33 | 503190396 | Ball Bearing | 1 |
| 34 | 503191311 | Black, Wheel Ass'y 147 mm Includes 34 to 35 | 2 |
| 35 | 503190396 | Ball Bearing | 1 |
| 36 | 503190580 | Support | |
| 37 | 207087544 | HEX. SCREW M8 X 75 | 4 |
| 38 | 207182544 | Hex. Screw M8 X 25 | 4 |
| 39 | 233281414 | Hex. Flange Elastic Nut M8 | 8 |
| 40 | 211200041 | Washer | 4 |
| 41 | 570063600 | Wheel Cap | 4 |
| 42 | 503190434 | Labyrinth Seal | 7 |
