Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 410109500 | Pilot Lamp (Red) | ||
| 410109600 | Pilot Lamp (Blue) | ||
| 410109300 | Pilot Lamp (Heated Handle) | ||
| 410109400 | Pilot Lamp (Heated Thumb) | ||
| 2 | 414176000 | Open Clamp | 2 |
| 414991700 | BLANK KEY | ||
| 1 | 570013700 | Switch Boot | 1 |
| 1 | 410107800 | Face Nut | 1 |
| 410113602 | IGNITION SWITCH | ||
| 1 | 572150700 | FEMALE TERMINAL HOUSING, 9 CIRCUITS | 1 |
| 561503200 | Female Terminal PACKARD | ||
| 1 | 561503100 | FEMALE TERMINAL | 1 |
| 1 | 515151500 | Cap Ass’Y | 1 |
| 1 | 515145900 | Switch Nut | 1 |
| 1 | 570151100 | Plunger Cap | 1 |
| 391302500 | Washer | ||
| 1 | 410106700 | Brake Switch | 1 |
| 413701700 | Dielectric Grease, 3 Oz | ||
| 1 | 409205600 | CLIP | 1 |
| 409003200 | OPEN BARREL | ||
| 1 | 409209300 | MALE HOUSING | 1 |
| 515163800 | VOLTAGE REGULATOR | ||
| 561503400 | MALE TERMINAL (18/16 GA.) | ||
| 409204500 | MALE HOUSING | ||
| 732600016 | Hex. Screw M6 x 35 | ||
| 2 | 410107300 | Switch (Heating Grip) | 2 |
| 2 | 570013900 | Switch Cover | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 410911000 | Resistance 30 ohms | 1 |
| 415034000 | Speedometer (KMH) | ||
| 415034100 | Speedometer (MH) | ||
| 415034200 | Tachometer | ||
| 517258500 | Washer | ||
| 572022300 | Drive Angle | ||
| 410608800 | HEADLAMP ASS'Y Includes 34 - 38. | ||
| 410608900 | Headlamp | ||
| 1 | 410503700 | Halogen Bulb 60/55 W | 1 |
| 1 | 410608200 | RUBBER STOPPER | 1 |
| 1 | 410608300 | BULB HOLDER | 1 |
| 410607100 | PROTECTOR CAP | ||
| 572078600 | Projector Nut | ||
| 2 | 517225900 | Flat Washer | 2 |
| 409206100 | MALE TERMINAL | ||
| 2 | 517166000 | SPRING | 2 |
| 414806500 | Case Holder | ||
| 414807100 | O-Ring | ||
| 414806900 | Nut | ||
| 414806700 | Lock Washer | ||
| 4 | 414806800 | Flat Washer | 4 |
| 414761400 | Speedometer Cable | ||
| 2 | 365901100 | HEX. SCREW 12 X 3/4 | 2 |
| 517249300 | Headlamp Support | ||
| 410504200 | INSTRUMENTATION BULB | ||
| 415042800 | Temperature Gauge | ||
| 409204300 | Female Housing | ||
| 415042900 | Fuel Gauge | ||
| 2 | 414807200 | O-RING | 2 |
| 2 | 517258600 | WASHER | 2 |
| 414806600 | Case Holder | ||
| 4 | 391301700 | Washer | 4 |
| 414833700 | Lock Washer | ||
| 414833600 | NUT | ||
| 1 | 409204900 | FEMALE HOUSING | 1 |
| 415006100 | Adjuster Screw Ass'y Includes 62 - 63. | ||
| 732603004 | Screw M4 x 40 | ||
| 414893000 | Reflective Sheet | ||
| 517274400 | Bracket | ||
| 1 | 517124300 | Washer | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 1 | 748001001 | Tie Rap | 1 |
| 515166200 | Wiring ass'y |
