Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| M870156074 | Transmission Ass'y Includes 1 - 70. Skandic WT. | ||
| M870156145 | TRANSMISSION Includes 1 - 71. Skandic SWT. | ||
| M870156100 | Transmission Ass'y Includes 1 - 70. Skandic WT LC. | ||
| 1 | M875156138 | Carter Chaine U*Case-Chain Mach. | 1 |
| M875156043 | COVER | ||
| M875156075 | H-SCHEME | ||
| M537001402 | SCREW | ||
| 3 | 207182044 | Hex. Screw M8 X 20 | 3 |
| M534801362 | Screw | ||
| 1 | M875156076 | Sleeve Nut | 1 |
| 1 | M875156078 | Ressort *Spring | 1 |
| M875156072 | SHAFT | ||
| M875156077 | SLEEVE NUT | ||
| 1 | M614601523 | O'Ring | 1 |
| 1 | M614102031 | Oil Seal | 1 |
| M510611002 | NUT | ||
| M875156073 | PIN | ||
| M654100224 | Sender | ||
| M617391218 | Shim | ||
| M615581216 | Sealing Ring | ||
| 1 | M614103562 | Oil Seal | 1 |
| M617330062 | LOCK RING | ||
| 1 | M875156063 | Variator Shaft Skandic WT. Skandic WT LC. | 1 |
| M875156155 | Variator Shaft Skandic SWT. | ||
| 4 | M616810064 | Bille *Ball | 4 |
| 2 | M875156105 | Ressort *Spring | 2 |
| M875156005 | WHEEL-CLUTCH | ||
| 1 | M875156052 | Sprocket 27Th Skandic WT. | 1 |
| M875156135 | Sprocket 29 Th Skandic SWT. | ||
| M875156115 | Sprocket 28 Th Skandic WT LC. | ||
| 1 | M611002529 | Needle Bearing | 1 |
| 1 | M616092542 | WASHER-AXIAL | 1 |
| M610063050 | BALL BEARING | ||
| M875156099 | Washer | ||
| 3 | M617395065 | Shim | 3 |
| 1 | M614100062 | Bouchon *Plug | 1 |
| 1 | M875156068 | Reverse Shaft | 1 |
| 2 | M875152953 | Bouchon *Plug | 2 |
| M610063044 | BALL BEARING | ||
| M617450028 | Circlip *Circlip | ||
| 1 | M617394252 | Shim | 1 |
| 1 | M31002 | Circlip *Circlip | 1 |
| 1 | M875156054 | Sprocket 34Th | 1 |
| 1 | M875156087 | SLEEVE Skandic WT. Skandic WT LC. | 1 |
| 1 | M875156088 | SLEEVE Skandic SWT. | 1 |
| M875156060 | Sprocket 24 Th Skandic SWT. | ||
| 1 | M875156051 | Sprocket 29Th Skandic WT. Skandic WT LC. | 1 |
| M875156136 | Sprocket 27 Th Skandic SWT. | ||
| 1 | M875156069 | Axe *Shaft | 1 |
| 1 | M617450025 | Circlip *Circlip | 1 |
| M875156112 | WASHER | ||
| 1 | M614102562 | Oil Seal | 1 |
| M614601224 | O'RING | ||
| 2 | M875156094 | Ring | 2 |
| 1 | M875156050 | Sprocket 28 Th Skandic WT. Skandic WT LC. | 1 |
| M875156059 | Sprocket 33 Th Skandic SWT. | ||
| 4 | M610063035 | Roulement Bille*Ball Bearing | 4 |
| 2 | M617330047 | Circlip *Circlip | 2 |
| M875147205 | Washer | ||
| 2 | M875147204 | Axe *Shaft | 2 |
| 2 | M614602431 | O'Ring | 2 |
| M875156049 | SPROCKET 31 TH Skandic WT. Skandic WT LC. | ||
| M875156058 | Sprocket 26 Th Skandic SWT. | ||
| 1 | M614100052 | Bouchon *Plug | 1 |
| M2652101 | SEAL-OIL | ||
| 1 | M617330068 | Circlip *Circlip | 1 |
| M610060080 | BALL BEARING | ||
| 1 | M875156048 | Pignon 55 *Sprocket-55 Skandic WT. | 1 |
| M875156057 | Sprocket 59 Th Skandic SWT. | ||
| M875156114 | Sprocket 53 Th Skandic WT LC. | ||
| M875136962 | Lower Shaft | ||
| M603345070 | Key | ||
| 1 | M617300040 | CIRCLIP | 1 |
| 1 | M617395568 | Shim | 1 |
| M875156104 | Bouchon *Plug | ||
| M615580812 | RING-GASKET | ||
| M528801342 | PLUG | ||
| M875156097 | Filler Cap Ass'y | ||
| 3 | M614600725 | O'Ring | 3 |
| M875156098 | PLUG | ||
| M610063040 | BEARING | ||
| M875156153 | Sleeve Skandic SWT. |
