Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518325438 | Cross Member Includes 1 to 9 | ||
| 2 | 207085544 | Hex. Screw M8 X 55 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 234081410 | Flat Washer 8 mm | 2 |
| 1 | 518325422 | FRONT PLATE | 1 |
| 518324107 | Plate Reinforcement | ||
| 4 | 390909100 | Avex Rivet | 4 |
| 2 | 207151644 | Hex. Screw M5 X 16 | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 2 | 518324181 | CORNER REINFORCEMENT | 2 |
| 6 | 390402200 | Pop Rivet 3/16" | 6 |
| 1 | 518324505 | HANDLE SUPPORT | 1 |
| 1 | 518317504 | CABLE PROTECTOR | 1 |
| 1 | 518323472 | BRACE, BLACK | 1 |
| 1 | 518323854 | BRACKET BLOCK | 1 |
| 1 | 518324574 | UPPER CROSS MEMBER | 1 |
| 1 | 518324182 | RH MEMBER | 1 |
| 518324183 | LH Member | ||
| 9 | 207151644 | Hex. Screw M5 X 16 | 9 |
| 6 | 234051410 | Flat Washer M5 | 6 |
| 19 | 390402200 | Pop Rivet 3/16" | 19 |
| 2 | 205051644 | Socket Screw M5 X 16 | 2 |
| 12 | 390402400 | Pop Rivet 3/16" | 12 |
| 11 | 233251414 | Hex. Flange Elastic Nut M5 | 11 |
| 25 | 390909200 | Avex Rivet | 25 |
| 1 | 518325014 | RH SHOCK BRACKET | 1 |
| 1 | 518325015 | LH SHOCK BRACKET | 1 |
| 1 | 518323532 | INTAKE AIR ADMISSION SUPPORT | 1 |
| 1 | 518322726 | GUARD BELT BRACKET, BLACK | 1 |
| 518323274 | Trunk Bracket, Black | ||
| 518323535 | RH Console Support | ||
| 518323536 | LH Console Support | ||
| 1 | 518324391 | RH TOE HOLD | 1 |
| 1 | 518324392 | LH TOE HOLD | 1 |
| 1 | 518324465 | REAR BUMPER | 1 |
| 1 | 518323896 | TRUNK BRACKET, BLACK | 1 |
| 4 | 236282084 | Hex. Screw M8 X 20 | 4 |
| 518324071 | Front Protector | ||
| 518325020 | Protector | ||
| 518325016 | FRAME PROTECTOR | ||
| 2 | 510004418 | WASHER | 2 |
| 518325017 | Protector | ||
| 2 | 390407200 | Pop Rivet 3/16” | 2 |
| 6 | 390410100 | Pop Rivet 3/16” | 6 |
| 2 | 207063044 | Hex. Screw M6 X 30 | 2 |
| 2 | 207161844 | Hex. Screw M6 X 18 | 2 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 1 | 207682544 | Hex. Flange Screw M8 X 25 | 1 |
| 2 | 205862044 | Socket Head Screw M6 X 20, Scotch Grip | 2 |
| 518324096 | RH Tunnel Stiffener | ||
| 4 | 250000154 | Torx Screw M8 X 13 | 4 |
| 12 | 233281414 | Hex. Flange Elastic Nut M8 | 12 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 207663544 | Hex. Flange Screw M6 X 35 | 1 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 8 | 207683544 | Hex. Flange Screw M8 X 35 | 8 |
| 6 | 415107300 | Insert | 6 |
| 1 | 207687044 | Hex. Flange Screw M8 X 70 | 1 |
| 2 | 293450166 | Insert | 2 |
| 4 | 207662044 | Hex. Flange Screw M6 X 20 | 4 |
| 1 | 207161444 | Hex. Screw M6 X 14 | 1 |
| 1 | 224061121 | Flat Washer | 1 |
| 293450232 | Insert M6 X 1.0 | ||
| 6 | 518321954 | Panel Fastener | 6 |
| 1 | 207085544 | Hex. Screw M8 X 55 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
