Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Seat Ass'y, (2 Passengers) | ||
| 414966903 | Seat Cover | ||
| 414932902 | Foam Seat | ||
| 732601186 | Hex. Screw M8 x 20 | ||
| 517284200 | Rack Ass’y | ||
| 414942700 | Grip | ||
| 732601175 | Screw M8 x 25 | ||
| 414108300 | Hair Pin | ||
| 414988700 | Reflective Sheet | ||
| XXX | Not Available As Spare Parts | ||
| 572070800 | LH Rear Moulding Includes 11 to 14 | ||
| 572070900 | RH Rear Moulding Includes 11 to 14 | ||
| 414510100 | REFLECTOR, RED | ||
| 2 | 222851065 | SCREW-PAN HD.PH.DIN.7985A | 2 |
| 224151101 | WASHER-LOCK SERRATED DIN.6798A | ||
| 6 | 365901100 | HEX. SCREW 12 X 3/4 | 6 |
| 4 | 228761045 | Elastic Flange Nut M6 | 4 |
| 732601126 | «T» Bolt M6 | ||
| 4 | 732610072 | Push Nut | 4 |
| 572051200 | Rear Trunk | ||
| 5 | 517225900 | Flat Washer | 5 |
| 5 | 390906800 | Pop Rivet 3/16" | 5 |
| 409206100 | MALE TERMINAL | ||
| 409204500 | MALE HOUSING | ||
| 4 | 222082065 | Hex. Screw M8 x 20 | 4 |
| 4 | 224781140 | Lock Washer 8 mm | 4 |
| 517272510 | Rear Bumper | ||
| 2 | 414516300 | Screw | 2 |
| 2 | 414516400 | Washer | 2 |
| 414513700 | Lens | ||
| 1 | 410504100 | Bulb | 1 |
| 2 | 228751045 | Elastic Flange Nut M5 | 2 |
| 414942500 | Taillamp Housing | ||
| 517257300 | Guide | ||
| 570027400 | Rubber Shim | ||
| 2 | 517251300 | SPACER | 2 |
| 572038200 | Lock Lever | ||
| 2 | 414821400 | Pin | 2 |
| 517257600 | Eye Bolt | ||
| 414977500 | Backrest Ass’y Includes 42 to 56 | ||
| 1 | 414820900 | TILLER HANDLE | 1 |
| 414821000 | Cap | ||
| 517274900 | RH Arm | ||
| 517275000 | LH Arm | ||
| 414813300 | Recliner | ||
| 2 | 222082565 | Hex. Screw M8 x 25 | 2 |
| 1 | 224081201 | FLAT WASHER | 1 |
| 2 | 224781140 | Lock Washer 8 mm | 2 |
| 2 | 222082065 | Hex. Screw M8 x 20 | 2 |
| 2 | 228581045 | Elastic Stop Nut M8 | 2 |
| 1 | 413703000 | Loctite 242, 10 cc | 1 |
| 414821200 | Backrest Foam | ||
| 414977503 | Backrest Cover | ||
| 1 | 415015500 | STRIP | 1 |
| 414819600 | Washer | ||
| 6 | 228581045 | Elastic Stop Nut M8 | 6 |
| 4 | 224081171 | Flat Washer 8 mm | 4 |
| 2 | 410110000 | Heating Grip | 2 |
| 6 | 732900030 | Spring Washer 8 mm | 6 |
| 414819500 | Washer | ||
| 517250000 | Nut | ||
| 1 | 409204200 | FEMALE HOUSING | 1 |
| 414985400 | Holding Strap | ||
| 2 | 224080251 | Washer 8 mm | 2 |
| 414728000 | SEAT BUCKLE | ||
| 572076400 | Snow Guard | ||
| 4 | 390908000 | Rivet (Black) | 4 |
| 4 | 517225900 | Flat Washer | 4 |
| 414975300 | RH Rear Footrest | ||
| 414975400 | LH Rear Footrest | ||
| 4 | 365901100 | HEX. SCREW 12 X 3/4 | 4 |
| 4 | 224061151 | Washer 6 mm | 4 |
| 529027900 | Tool Kit | ||
| 572036310 | BOX COVER | ||
| 529030700 | Wrench-Adjuster | ||
| 390403600 | Pop Rivet 3/16 | ||
| 518301100 | Retainer Plate | ||
| 518306000 | Reinforcement | ||
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 517264500 | Lens Rear Support |
