Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 570029400 | Rubber Flange | ||
| 414532700 | COLLAR | ||
| 403119800 | Carburetor VM 38-317, PTO Side | ||
| 403119900 | Carburetor VM 38-318, MAG Side | ||
| 414532800 | Collar | ||
| 580628502 | Air Silencer Ass‘y Includes 7,9,10,40 | ||
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 2 | 732610057 | JACK NUT M6 | 2 |
| 409008500 | Female Terminal Housing (3 circuits) | ||
| 570038400 | Intake Adaptor | ||
| 414161500 | Warning Decal | ||
| 403900900 | Fuel Pump | ||
| XXXX | Not Available As Spare Part - Hex. Screw M6 x 20 | ||
| 1 | 414554800 | Spring Clamp | 1 |
| 410108400 | Fuel Level Sensor | ||
| 1 | 219704439 | Hose 1/4 1000Mm Long - Call Your Local BRP Dealership | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 219704414 | Was 415110000 Polyurethane Hose 5.2 mm | 1 |
| 1 | 414222500 | T-fitting | 1 |
| 1 | 414222400 | T-Fitting | 1 |
| 414296900 | Fuel Line 3.18 mm | ||
| 1 | 414518500 | Male Connector | 1 |
| 1 | 570045500 | Grommet | 1 |
| 1 | 414865700 | Fuel Filter | 1 |
| 414931500 | Security Label | ||
| 414935900 | SHUT OFF VALVE | ||
| 517249200 | Fuel Tank Bracket | ||
| 1 | 414479200 | Primer Valve | 1 |
| 572057100 | Fuel Tank | ||
| 2 | 224061121 | Flat Washer | 2 |
| 2 | 224761110 | Lock Washer 6 mm | 2 |
| 517256400 | Spacer | ||
| 1 | 572039600 | Cap-Fuel Tank | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 414966801 | Throttle Cable and Housing | ||
| 1 | 414274500 | Circlip | 1 |
| 1 | 414753300 | Washer | 1 |
| 1 | 414753500 | Circlip | 1 |
| 1 | 222062565 | Hex. Screw M6 x 25 | 1 |
| 222063565 | Hex. Screw M6 x 35 | ||
| 572029007 | Air Filter Foam (2 Holes Silencer) | ||
| 1 | 414176000 | Open Clamp | 1 |
| 2 | 414227300 | Clip | 2 |
| 1 | 414814100 | Male Connector | 1 |
| 2 | 414893700 | Spring | 2 |
| 1 | 570135100 | Grommet | 1 |
| 413701700 | Dielectric Grease, 3 Oz | ||
| 2 | 570273900 | Grommet | 2 |
| 391300700 | WASHER-FLAT | ||
| 1 | 414473200 | Screw | 1 |
| 1 | 414612700 | Kill Switch | 1 |
| 1 | 414440800 | Socket Set Screw M8 X 10 | 1 |
| 4 | 732601143 | Flange Screw | 4 |
| 1 | 572044600 | THROTTLE COVER | 1 |
| 1 | 572056900 | Heat Throttle Handle Ass'y (38 mm) | 1 |
| 572028600 | Throttle Handle Housing | ||
| 561503400 | MALE TERMINAL (18/16 GA.) | ||
| 561503200 | Female Terminal PACKARD | ||
| 5 | 228551045 | Elastic Stop Nut M5 | 5 |
| 2 | 414415200 | Spring Clamp | 2 |
| 409204500 | MALE HOUSING |
