Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Engine 800R E-TEC 800RE | ||
| 2 | 205052544 | Socket Screw M5 X 25 XRS | 2 |
| 4 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 3 | 207562544 | Hex. Flange Screw M6 X 25 | 3 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 5 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 5 |
| 1 | 207583544 | Hex Flange Screw M8 X 35, Scotch Grip DELE | 1 |
| 1 | 207652044 | Hex.Flange Screw M5 X 20 | 1 |
| 3 | 207683044 | Hex. Flange Screw M8 X 30 | 3 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 234001410 | Flat Washer 10 mm | 4 |
| 11 | 250200146 | Conical Spring Washer M8 | 11 |
| 4 | 241151640 | Hex. Flange Screw K50 X 2.24 X 16 | 4 |
| 5 | 250000079 | Panel Nut M5 X 0.8 | 5 |
| 2 | 250000248 | Torx Screw M8 X 25, Scotch Grip DELE | 2 |
| 1 | 250000248 | Torx Screw M8 X 25, Scotch Grip | 1 |
| 3 | 250000253 | Hex. Flange Screw M6 X 1.0 X 30 | 3 |
| 3 | 250000297 | Truss Head Torx Screw K50 X 20 | 3 |
| 4 | 250000528 | Torx Screw M5 X 20 | 4 |
| 1 | 250000570 | Hex. Screw M8 | 1 |
| 1 | 250200008 | Flat Washer With Teflon 8 mm DELE | 1 |
| 1 | 250200040 | Flat Washer | 1 |
| 3 | 293100003 | Nut Welded, M6 | 3 |
| 1 | 293650046 | Oetiker Clamp | 1 |
| 2 | 293650043 | Oetiker Gear Clamp | 2 |
| 5 | 293650214 | Norma Spring Clamp | 5 |
| 1 | 293710068 | T-Fitting | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 414274500 | Circlip | 1 |
| 1 | 414814100 | Male Connector | 1 |
| 2 | 420430930 | Gasket | 2 |
| 4 | 420441187 | Torx Flange Screw M10 X 90 -SW 13/T50 | 4 |
| 1 | 420889199 | Throttle Body 800RE | 1 |
| 2 | 420924724 | Hose Nipple | 2 |
| 3 | 503183200 | Yellow, Washer | 3 |
| 508000007 | GEMI CLAMP 800RE | ||
| 1 | 512059969 | Upper Housing XRS | 1 |
| 1 | 512060832 | Calibrated Module 800R E-TEC 800RE MX-Z | 1 |
| 2 | 512060810 | Ignition Coil | 2 |
| 2 | 512060094 | Ignition Cable, 177 mm | 2 |
| 1 | 512060136 | Starter Grip DMAN | 1 |
| 1 | 512060298 | Solenoid Support | 1 |
| 1 | 512060313 | Protector | 1 |
| 1 | 512060339 | NOISE SHIELD Except XTREM | 1 |
| 1 | 512060343 | Interior Noise Foam | 1 |
| 1 | 512060344 | Upper Exterior Noise Foam | 1 |
| 512060362 | LOWER EXTERIOR NOISE FOAM Except XTREM | ||
| 1 | 512060387 | Rubber Mount | 1 |
| 1 | 512060448 | Rubber Mount | 1 |
| 1 | 512060618 | Throttle Handle MX-Z XRS | 1 |
| 1 | 512060469 | Front Support, MAG | 1 |
| 1 | 512060478 | Rear Support, PTO | 1 |
| 415129484 | SPARK PLUG NGK PFR7AB 800RE | ||
| 1 | 512060559 | Rear Support, MAG | 1 |
| 1 | 512060574 | Heat Shield | 1 |
| 1 | 512060576 | Stopper Support | 1 |
| 1 | 512060624 | Throttle Cable MX-Z XRS | 1 |
| 1 | 512060575 | Heat Shield Except XTREM | 1 |
| 1 | 512060692 | Manifold | 1 |
| 1 | 512060814 | SPRING | 1 |
| 1 | 512060807 | SPRING | 1 |
| 1 | 512060695 | LH Formed Hose | 1 |
| 1 | 512060694 | RH Formed Hose | 1 |
| 1 | 512060696 | Support Coils | 1 |
| 1 | 512060714 | Front Support, PTO 800RE | 1 |
| 1 | 219704352 | Was 420660574 Pressure Hose 280 mm | 1 |
| 2 | 512060728 | Fuel Injector 800RE | 2 |
| 2 | 512060729 | Rubber Mount | 2 |
| 512060741 | FORMED HOSE, OUTPUT 800RE Except GSX | ||
| 512060762 | HOSE SUPPORT | ||
| 1 | 219704408 | Tubing 16 Mm 1000Mm Long | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 512060627 | Stopper Except SUM, Except FREE | 1 |
| 1 | 219704407 | Tubing 10 MM 1000MM Long | 1 |
| 1 | 512060774 | Solenoid Valve | 1 |
| 1 | 512060822 | Manifold Support 800RE | 1 |
| 1 | 512060858 | Calibrated Module Support | 1 |
| 1 | 512059537 | Lower Housing XRS | 1 |
| 1 | 219704409 | Was 415080100 Fuel Line Primer 3,2mm | 1 |
| 1 | 219704399 | Was 409901700 Tubing (9 mm) | 1 |
| 1 | 515177389 | Starter DELE | 1 |
| 2 | 518325560 | Adhesive Patch | 2 |
| 2 | 710000992 | Clip | 2 |
| 2 | 732601143 | Flange Screw | 2 |
