Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 517305744 | Black, Front Hood Package TNT & X, Model Black | 1 |
| 1 | 517306099 | Sunburst Yellow, Front Hood Package X, Model Yellow | 1 |
| 1 | 517306269 | Bright White, Front Hood Package TNT, Model White | 1 |
| 4 | 250000528 | Torx Screw M5 X 20 | 4 |
| 4 | 250000079 | Panel Nut M5 X 0.8 | 4 |
| 2 | 233251494 | Elastic Flange Nut M5 | 2 |
| 2 | 250200040 | Flat Washer | 2 |
| 2 | 250000587 | Torx Screw M5 X 26 | 2 |
| 1 | 517305763 | RH Front Hood Foam | 1 |
| 1 | 517305764 | LH Front Hood Foam | 1 |
| 1 | 517306007 | Black - Hood RH Package TNT & X, Model Black | 1 |
| 1 | 517306100 | Yellow - Hood RH Package X, Model Yellow | 1 |
| 1 | 517306270 | White - Hood RH Package TNT, Model White | 1 |
| 3 | 250000725 | Screw M4 X 16 | 3 |
| 1 | 517306001 | RH Hood Foam | 1 |
| 1 | 517306008 | Black - Hood LH Package TNT & X, Model Black | 1 |
| 1 | 517306101 | Yellow - Hood LH Package X, Model Yellow | 1 |
| 1 | 517306271 | White - Hood LH Package TNT, Model White | 1 |
| 1 | 517306002 | LH Hood Foam | 1 |
| 1 | 517305745 | Rear Console, Deep Black | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 1 | 517304518 | Console Nut | 1 |
| 3 | 275500241 | Black, Cap | 3 |
| 1 | 517305781 | Indicator Support, Deep Black | 1 |
| 2 | 705000321 | Oval Washer | 2 |
| 1 | 860201448 | Black, Low Windshield Kit Includes 800 to 800b | 1 |
| 1 | 517305749 | Deep Black, Windshield Support | 1 |
| 6 | 732610072 | Push Nut | 6 |
| 1 | 517306183 | Deep Black, Windshield Support | 1 |
| 1 | 517306063 | Deflector RH, Black 63% Light Transm. | 1 |
| 1 | 517306064 | Deflector LH, Black 63% Light Transm. | 1 |
| 4 | 250000720 | Torx Screw K50 X 16 | 4 |
| 4 | 250200025 | Washer M5 | 4 |
| 4 | 250200024 | Rubber Washer 5 mm | 4 |
| 3 | 517303756 | Grommet | 3 |
| 1 | 517305860 | Black, RH Panel Package TNT & X, Model Black | 1 |
| 1 | 517306087 | Yellow, Panel RH Package X, Model Yellow | 1 |
| 1 | 517306272 | White - Panel RH Package TNT, Model White | 1 |
| 1 | 517305861 | Deep Black, RH Panel Trim | 1 |
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 5 | 517124300 | Washer | 5 |
| 1 | 517305109 | Rivet Plate | 1 |
| 1 | 517305773 | RH Rear Latch | 1 |
| 1 | 517305979 | RH Front Latch | 1 |
| 5 | 250000725 | Screw M4 X 16 | 5 |
| 1 | 517306311 | RH Hook | 1 |
| 1 | 517305767 | RH Central Panel Foam | 1 |
| 1 | 517306116 | RH Rear Panel Foam | 1 |
| 1 | 517306262 | Rubber Sheet | 1 |
| 1 | 517305862 | Deep Black, RH Grille | 1 |
| 2 | 250000725 | Screw M4 X 16 | 2 |
| 1 | 517305864 | Black, LH Panel Package TNT & X, Model Black | 1 |
| 1 | 517306096 | Yellow, Panel LH Package X, Model Yellow | 1 |
| 1 | 517306273 | White - Panel LH Package TNT, Model White | 1 |
| 1 | 517305865 | Black - Panel Trim LH | 1 |
| 1 | 293150104 | Pop Rivet 3/16" | 1 |
| 1 | 517124300 | Washer | 1 |
| 1 | 517305774 | LH Rear Latch | 1 |
| 1 | 517305980 | LH Front Latch | 1 |
| 1 | 517306312 | LH Hook | 1 |
| 1 | 517305769 | LH Front Panel Foam | 1 |
| 1 | 517305770 | LH Central Panel Foam | 1 |
| 1 | 517305766 | FOAM | 1 |
| 2 | 517305985 | Rear Stud | 2 |
| 2 | 517305988 | Front Stud | 2 |
| 4 | 250000725 | Screw M4 X 16 | 4 |
| 1 | 517306309 | RH Lower Latch | 1 |
| 1 | 293150100 | Pop Rivet 3/16" | 1 |
| 1 | 517305290 | Deep Black, LH Arm | 1 |
| 1 | 517305293 | Deep Black, RH Arm | 1 |
| 1 | 517305291 | LH Deflector, Smoked 60% | 1 |
| 1 | 517305294 | RH Deflector, Smoked 60% | 1 |
| 1 | 517305589 | Sunburst Yellow, LH Cap, SKI-DOO Package X, Model Yellow | 1 |
| 1 | 517305601 | Deep Black, LH Cap, SKI-DOO Package TNT & X, Model Black | 1 |
| 1 | 517305930 | White - LH Cap Package TNT, Model White | 1 |
| 1 | 517305588 | Sunburst Yellow, RH Cap, SKI-DOO | 1 |
| 1 | 517305602 | Deep Black, RH Cap SKI-DOO | 1 |
| 1 | 517305931 | White - RH Cap | 1 |
| 2 | 517305296 | Clamp | 2 |
| 2 | 250000760 | Torx Screw Truss Head K50X20 T20 | 2 |
| 4 | 250000724 | Torx Screw M5 X 20 | 4 |
| 1 | 517305752 | Headlamp | 1 |
| 1 | 415130081 | Bulb | 1 |
| 1 | 517305776 | RH Deflector Black 63% Light Transm. | 1 |
| 2 | 517302841 | Grommet | 2 |
| 1 | 517305777 | Deflector LH, Black 63% Light Transm. | 1 |
| 1 | 517305871 | Deep Black, Cover Ass'y Includes 3200 to 3200a | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 517306058 | Trunk Ass'y Includes 3400 to 3400a | 1 |
| 2 | 517305157 | Seal Joint | 2 |
| 1 | 517305746 | Deep Black, Headlamp Fairing | 1 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
