Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 420889431 | Servomotor | 1 |
| 1 | 420997033 | Bowden Cable Ass'y | 1 |
| 1 | 293370122 | Circlip | 1 |
| 1 | 205551060 | Socket Head Screw M5 X 10 | 1 |
| 2 | 207551044 | Hex. Flange Screw M5 X 10 | 2 |
| 1 | 512061136 | Rear PTO Support Includes 1000 to 1000a | 1 |
| 1 | 512060295 | Rubber Mount | 1 |
| 1 | 512061354 | Spacer Ref Service Bulletin 2018-8 | 1 |
| 2 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 2 | 250200146 | Conical Spring Washer M8 | 2 |
| 1 | 512061025 | Front PTO Support | 1 |
| 1 | 512061027 | MAG Support | 1 |
| 1 | 512061344 | MAG Support Ref Service Bulletin 2018-8 | 1 |
| 3 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 3 |
| 3 | 250200146 | Conical Spring Washer M8 | 3 |
| 1 | 512061145 | Rubber Mount | 1 |
| 1 | 512061347 | Shim Ref Service Bulletin 2018-8 | 1 |
| 2 | 250000822 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 207585544 | Hex. Flange Screw M8 X 55 | 2 |
| 1 | 207086046 | Hex. Screw M8 X 60 Ref Service Bulletin 2018-8 | 1 |
| 1 | 503183200 | Yellow, Washer | 1 |
| 1 | 506151245 | Washer Ref Service Bulletin 2018-8 | 1 |
| 2 | 250200008 | Flat Washer With Teflon 8 mm | 2 |
| 1 | 512061333 | Washer Ref Service Bulletin 2018-8 | 1 |
| 1 | 250200146 | Conical Spring Washer M8 | 1 |
| 1 | 207683044 | Hex. Flange Screw M8 X 30 | 1 |
| 1 | 250000671 | Torx Screw Ref Service Bulletin 2018-8 | 1 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 2 | 512061137 | Engine Stopper | 2 |
| 1 | 512061334 | PTO Limiter Ref Service Bulletin 2018-8 | 1 |
| 2 | 512061198 | Spacer | 2 |
| 1 | 508000795 | Primary Chamber Ass'y Includes 2000 to 2000c | 1 |
| 10 | 732610072 | Push Nut | 10 |
| 1 | 512061083 | Rubber | 1 |
| 2 | 420441840 | Screw | 2 |
| 2 | 293650212 | GEMI Clamp | 2 |
| 1 | 293650247 | Gemi Clamp | 1 |
| 2 | 420201630 | Rubber Cap | 2 |
| 1 | 512061086 | AIRBOX SUPPORT | 1 |
| 3 | 293150103 | Pop Rivet 3/16" | 3 |
| 1 | 293150104 | Pop Rivet 3/16" | 1 |
| 1 | 512061026 | THROTTLE CABLE | 1 |
| 1 | 414274500 | Circlip | 1 |
| 1 | 512060859 | Upper Housing | 1 |
| 1 | 512060860 | Lower Housing | 1 |
| 1 | 512061167 | Throttle Ass'y | 1 |
| 2 | 732601143 | Flange Screw | 2 |
| 1 | 512061168 | Ignition Coil | 1 |
| 3 | 250000760 | Torx Screw Truss Head K50X20 T20 | 3 |
| 2 | 512061166 | Ignition Cable | 2 |
| 1 | 516007661 | Warning Decal, Injectors | 1 |
| 2 | 512061238 | Spark Plug Wire Holder | 2 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 2 | 512060993 | Clamp | 2 |
| 1 | 512060136 | Starter Grip | 1 |
| 1 | 512061213 | Acoustic Cover | 1 |
| 1 | 512061215 | LH Acoustic Cover | 1 |
| 1 | 512061216 | RH Acoustic Cover | 1 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 250000725 | Screw M4 X 16 | 1 |
