Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504153055 | Chaincase | 1 |
| 2 | 207662034 | Hex. Flange Screw M6 X 20 | 2 |
| 6 | 233261434 | Flange Elastic Nut M6 | 6 |
| 1 | 518325816 | Plate Includes 4 to 5 | 1 |
| XXXX | Not Available As Spare Part - Clinch Stud M6 X 20 | ||
| 1 | 415049300 | Oil Seal | 1 |
| 1 | 293350055 | Ball Bearing | 1 |
| 1 | 504152576 | Circlip | 1 |
| 1 | 504152628 | Shim | 1 |
| 1 | 504091000 | Sprocket 23 Teeth 23 Teeth, Freeride 137'' | 1 |
| 1 | 504096200 | Sprocket, 21 Teeth 21 Teeth, Freeride | 1 |
| 1 | 504152030 | Sprocket, 19 Teeth 19 Teeth, Freeride 154'' | 1 |
| 1 | 504152784 | Spring Washer M10 | 1 |
| 1 | 207103044 | Hex. Screw M10 X 30 | 1 |
| 1 | 504152571 | Seal | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504152581 | Sprocket, 49 Teeth 49 Teeth, Freeride 146'', 154'' | 1 |
| 1 | 504152593 | Sprocket, 45 Teeth 45 Teeth, Freeride 137'', 146'' | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 293300122 | O-Ring | 1 |
| 1 | 504152619 | Magnetic Cap | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 504152579 | Drive Chain, 102 Links 102 Chain Link, Freeride 137'', 146'' | 1 |
| 1 | 504152629 | Drive Chain, 104 Links 104 Chain Link, Freeride 137'', 154'' | 1 |
| 1 | 504152630 | Drive Chain, 106 Links 106 Chain Link, Freeride 146'', 154'' | 1 |
| 1 | 232006414 | Hex. Nut M10 X 1.5 | 1 |
| 1 | 504152602 | Adjustment Screw | 1 |
| 1 | 504152854 | Magnetic Plug 1/8 - 27 NPTF | 1 |
| 1 | 250200100 | Bonded Washer | 1 |
| 1 | 504152685 | Chain Tensioner | 1 |
| 1 | 504152739 | Slider Chain | 1 |
| 1 | 504152841 | Tensioner Axle | 1 |
| 1 | 504152282 | Circlip | 1 |
| 1 | 504153059 | Chaincase Cover Ass'y Includes 33 to 33b | 1 |
| 1 | 293300130 | Tight Seal | 1 |
| 7 | 210263080 | Hex. Flange Screw M6 X 30 | 7 |
| 1 | 504152860 | Cap Not Included 37a: 414580700, 37b 415080200 | 1 |
| 1 | 504152949 | Housing Bearing | 1 |
| 1 | 504152974 | Bearing Housing | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 504153085 | Drive Axle Ass'y | 1 |
| 1 | 504152803 | Track Ass'y 16" X 137" X 1.7" Includes 52 to 52b, 137X1.7P | 1 |
| 1 | 504153008 | Track Ass'y 16" X 146" X 2.50" Includes 52 to 52b, 146X2.5PII | 1 |
| 1 | 504153009 | Track Ass'y 16" X 154" X 2.50" Includes 52 to 52b, 154X2.5PII | 1 |
| 1 | 504153014 | Tarck Ass'y 16" X 146" X 2.31" Includes 52 to 52b, 146X2.2P | 1 |
| 1 | 504153015 | Track Ass'y 16" X 154" X 2.2"P Includes 52 to 52b, 154X2.2P | 1 |
| 1 | 504153103 | Track Ass'y 16" X 137" X 2.25" Includes 52 to 52b, 137X2.2P | 1 |
| 1 | 504152917 | Chaincase Cover | 1 |
| 1 | 504152896 | Rotation Sensor | 1 |
| 1 | 414580700 | Male Connector | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 32 | 415129528 | Track Guide | 32 |
| 64 | 415129529 | Cleat | 64 |
| 26 | 415129529 | Cleat | 26 |
