Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 58303001600 | FRAME SX WITH BEARINGS FOR LINKING 96 | ||
| 58303001700 | FRAME SC WITH BEARINGS FOR UNKING 97 | ||
| 58303102400 | SUB FRAME CPL ALU 96 | ||
| 58303002045 | BUSHING EXC-NUMBERPLATECARRIER | ||
| 58303002145 | BUSHING EGS-NUMBERPLATECARRIER | ||
| 1 | 71003007000 | STEERING HEAD LOCK CPL. ZADI | 1 |
| 2 | 0015060123 | HH COLLAR SCREW M 6X12 WS=8 WS-8 | 2 |
| 58003012000 | SPACER ROLLER 10,3X20X22 (As Required) | ||
| 2 | 71001012000 | PVC CAP D=22MM | 2 |
| 58307015000 | TANK SUPPORT '93 93 | ||
| 58303055000 | ENGINE SUPPORT AGW '94 94 | ||
| 0931101103 | HH SCREW DIN0931-M10X110 | ||
| 1 | 49009082000 | flanged hex nut DIN 6927 M10 WS15 WS=17 | 1 |
| 54310086000 | SELF LOCKING NUT M8 | ||
| 58003055600 | ENGINE SUPPORT L/S ALU SX | ||
| 58003155600 | ENGINE SUPPORT R/S ALU SX | ||
| 0931101203 | HH SCREWDIN0931-MLOX 120 | ||
| 31004001100 | WASHER 10,5 X 21 X 3 | ||
| 2 | 0931080803 | HH SCREW DIN0931-M 8X80 | 2 |
| 0931100603 | HH SCREW DIN0931-ML0X60 | ||
| 2 | 0985100003 | SELF LOCKING NUT DIN0985-M10 | 2 |
| 1 | 0912101603 | AH SCREW DIN0912-M10X160 | 1 |
| 1 | 54630044000 | COLLAR NUT M10 WS=13 WS=13 | 1 |
| 1 | 55007016001 | PVC-HOSE 7X10 PER METER | 1 |
| 1 | 50303089000 | ANGLE PIECE '97 97 | 1 |
| 58303038000 | FOOTREST BRACKET L/S '93 93 | ||
| 58303040000 | FOOTREST L/S ' 93 | ||
| 54603140000/19 | FOOTREST R/S 93 | ||
| 58303041000 | FOOTREST SPRING L/S '93 93 | ||
| 1 | 54603041000 | FOOTREST SPRING L/S & R/S | 1 |
| 58303044000 | BOLT FOR FOOTREST | ||
| 1 | 54603044000 | BOLT FOR FOOTREST 9,8 X 50 | 1 |
| 2 | 0125100003 | washer DIN 125 A 10.5 | 2 |
| 094032253 | PIN DIN0094-3,2X25 STEEL | ||
| 42007049000 | PLASTIC CAP | ||
| 1 | 50203053000 | CHAIN ROLL D=30MM | 1 |
| 50203053100 | CHAIN ROLL D=35MM | ||
| 2 | 74003021000 | BUSHING 8.2 X 12 X 6 | 2 |
| 4 | 0625006087 | GROOVED BALL BEAR. 608 2RS C3 | 4 |
| 1 | 54403135000 | PLASTIC CAP SFL10 | 1 |
| 1 | 58303063000 | BRAKE LEVER STOP '93 93 | 1 |
| 1 | 0991060203 | FLAT H.SCREW DIN7991-M6X20 | 1 |
| 1 | 36003014000 | LOCK WASHER 8MM (As Required) | 1 |
| 1 | 0015080303 | HH COLLAR SCREW M 8X30 WS=10 WS=10 | 1 |
| 1 | 0015080353 | HH COLLAR SCREW M 8X35 WS=10 WS=10 | 1 |
| 2 | 0015080253 | HH COLLAR SCREW M 8X25 WS=10 WS=10 | 2 |
| 54510052000 | SPROCKET SCREWAH M8X26 | ||
| 1 | 0797080003 | TOOTHLOCK WASHER DIN6797-J 8,4 (As Required) | 1 |
| 1 | 0125080003 | washer DIN 125 A -8.4 (As Required) | 1 |
| 2 | 49109481052 | HH COLLAR SCREW M 8X16 WS=13 | 2 |
| 58303005144 | ENGINE PROTECTOR CPL 97 | ||
| 014060133 | HH COLLAR SCREW M 6X13 WS=8 | ||
| 58003012100 | ENGINE PROTECTOR BRACKET L/S | ||
| 58003012200 | ENGINE PROTECTOR BRACKET '97 | ||
| 4 | 0014060153 | HH COLLAR SCREW M 6X15 WS=8 WS=8 | 4 |
