Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 To 24 | ||
| 1 | 417223534 | Fixe Flange Ass'y | 1 |
| 1 | 417223606 | Slider Flange Ass'y | 1 |
| XXX | Not Available As Spare Parts include in Slider Flange Ass'y | ||
| 1 | 293370065 | Circlip | 1 |
| XXXX | Not Available As Spare Part - Loctite 609, 50ml | ||
| 6 | 417223604 | Ramp 700 Ass'y | 6 |
| XXX | Not Available As Spare Parts Included In Ramp Kit | ||
| 12 | 417223255 | Thrust Washer | 12 |
| 6 | 417223694 | Ramp Axle | 6 |
| 6 | 232551414 | Elastic Stop Nut M5 | 6 |
| 1 | 417223461 | Slider Adaptor Ass'y | 1 |
| 293370063 | CIRCLIP | ||
| 417223155 | SPRING SEAT | ||
| 1 | 417223315 | Spring Clutch | 1 |
| 3 | 250000473 | SCREW-SOCKET HEAD S.GRIP | 3 |
| 1 | 417223565 | Governor Cup Ass'y | 1 |
| 6 | 417223767 | Roller | 6 |
| 6 | 417223257 | Roller Axle | 6 |
| 3 | 293300145 | O-ring | 3 |
| 12 | 417223269 | Slider Shoe | 12 |
| 6 | 250000243 | Torx Screw M8 X 16, Scotch Grip | 6 |
| 1 | 417223476 | Crown Gear Launch | 1 |
| 1 | 250200006 | Spring Washer 14 mm | 1 |
| 1 | 417300407 | DRIVE BOLT PULLEY | 1 |
| 1 | 516005503 | Decal English | 1 |
| XXXX | Not Available As Spare Part - Driven Pulley Ass'y Includes 28 To 44 | ||
| 1 | 417127346 | Fixed Flange Ass'y | 1 |
| 2 | 417127189 | Roller | 2 |
| 2 | 417127294 | Pivot Stud | 2 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| 2 | 250400061 | Spring Pin M3 X 18 | 2 |
| 1 | 417127231 | Slider Flange Ass'y | 1 |
| 1 | 293370049 | Circlip | 1 |
| 417127148 | CAM ASS'Y | ||
| 1 | 417127243 | Spring, White | 1 |
| 4 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 4 |
| 1 | 415129604 | Calibration Ass'y | 1 |
| 1 | 205052544 | Socket Screw M5 X 25 | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 232551414 | Elastic Stop Nut M5 | 1 |
| 1 | 417127155 | Washer | 1 |
| 1 | 517302322 | Strength Washer | 1 |
| 1 | 207287544 | Hex. Cap Screw M8 X 75 | 1 |
| 1 | 417300265 | Spacer | 1 |
| 1 | 504112000 | Shim | 1 |
| 1 | 414860700 | Drive Belt | 1 |
| 1 | 417300382 | Belt Guard | 1 |
| 516004649 | Security label, Belt Guard | ||
| 1 | 417300380 | Reinforcement | 1 |
| 3 | 390909200 | Avex Rivet | 3 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300356 | Side Protector | 1 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
| 1 | 417300363 | Belt Guard Bracket | 1 |
| 417300451 | BELT GUARD BRACKET | ||
| 1 | 518325626 | Brake Hose Cover | 1 |
| 2 | 293150163 | Rivet Hucklok | 2 |
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 517281905 | Bracket | 1 |
| 2 | 390909100 | Avex Rivet | 2 |
| 1 | 516005511 | Belt Decal, English | 1 |
| 1 | 516003919 | Warning Decal (EU Models) | 1 |
| 1 | 512060745 | Coils Support | 1 |
| XXXX | Not Available As Spare Part - Loctite 8151 (Antiseize), 400ml Spray | ||
| 2 | 207162044 | Hex. Screw M6 X 20 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
