Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 517124300 | Washer | 2 |
| 517302170 | Hood GT 700. GT SE Millennium Edition. | ||
| 517302427 | Hood GT SE. | ||
| 2 | 517302152 | Hood Latch | 2 |
| 517302205 | RH Front Grille Ass'y Includes 4 - 6. GT 700. GT SE. | ||
| 517302406 | RH Front Grille Ass'y GT SE Millennium Edition. | ||
| 517302208 | LH Front Grille Ass'y GT 700. GT SE. | ||
| 517302407 | LH Front Grille Ass'y GT SE Millennium Edition. | ||
| 414070300 | Wing Nut M5 | ||
| 234451418 | WASHER-LOCK SERRATED DIN.6798A | ||
| 15 | 732601210 | HEX. FLANGED SCREW #8 X 3/8 | 15 |
| 517302073 | Center Grill Ass'y Includes 8 - 14. GT 700. GT SE. | ||
| 517302408 | Center Grille Ass'y GT SE Millennium Edition. | ||
| 517289100 | Central Grille GT 700. GT SE. | ||
| 517302384 | Central Grille GT SE Millennium Edition. | ||
| 517289103 | RH Front Sliding Grille | ||
| 517289104 | LH Front Sliding Grille | ||
| 517289105 | RH Rear Sliding Grille | ||
| 517289106 | LH Rear Sliding Grille | ||
| 12 | 572103500 | STUD GT 700. | 12 |
| 10 | 517302264 | STUD GT SE. GT SE Millennium Edition. | 10 |
| 10 | 732610072 | Push Nut | 10 |
| 8 | 391301700 | Washer | 8 |
| 6 | 233251414 | Hex. Flange Elastic Nut M5 | 6 |
| 2 | 390402400 | Pop Rivet 3/16" | 2 |
| 572107300 | Air Intake Deflector | ||
| 2 | 414745900 | Tuflock Phillips Plastic Screw | 2 |
| 4 | 243141640 | Hex. Flange Plastite Screw M4.8 X 16 | 4 |
| 572087800 | Plate | ||
| 415123100 | Filter Foam | ||
| 517302076 | Windshield Support | ||
| 2 | 415018100 | Rubber Stopper | 2 |
| 2 | 390401600 | Pop Rivet 1/8" | 2 |
| 2 | 293150007 | WASHER | 2 |
| 4 | 207152044 | Hex. Screw M5 X 20 | 4 |
| 8 | 391301600 | Washer | 8 |
| 517302249 | Console | ||
| 390409400 | RIVET_POP 5/32 X ,400 BLACK | ||
| 517296800 | Rope Guide | ||
| 517296900 | Bracket | ||
| 2 | 390910000 | Pop Rivet 3/16” | 2 |
| 515175512 | Dash | ||
| 4 | 241140060 | Screw K40 X 10 | 4 |
| 2 | 414436800 | RETAINER CAP | 2 |
| 2 | 414436900 | BLACK SNAP CAP | 2 |
| 2 | 234042600 | Flat Washer 4 mm, Stainless | 2 |
| 517302067 | RH Mirror Ass'y | ||
| 517302068 | LH Mirror Ass'y | ||
| 517302414 | Plate | ||
| 4 | 517124300 | Washer | 4 |
| 4 | 232541414 | Elastic Stop Nut M4 | 4 |
| 414632400 | Acoustic Foam | ||
| 414631900 | Acoustic Foam | ||
| 517302156 | RH Grille GT 700. GT SE. | ||
| 517302390 | RH Grille GT SE Millennium Edition. | ||
| 517302167 | LH Grille GT 700. GT SE. | ||
| 517302389 | LH Grille GT SE Millennium Edition. | ||
| 517302155 | Inlet Duct | ||
| 517301200 | RH Hood Guide | ||
| 517301300 | LH Hood Guide | ||
| 517302108 | Hood Guide | ||
| 2 | 207151644 | Hex. Screw M5 X 16 | 2 |
| 517302184 | LH Side Foam | ||
| 415045100 | RH Side Foam | ||
| 415045300 | Center Foam | ||
| 415045400 | Rear Foam | ||
| 415045500 | Deflector Foam | ||
| 293750015 | TIE RAP MOUNT | ||
| 13 | 517302183 | Clip | 13 |
| 420845270 | WASHER-LOCK SERRATED INT.EXT.M6 | ||
| 415082500 | High Windshield GT 700. | ||
| 517302268 | High Windshield GT SE. GT SE Millennium Edition. | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 517302265 | Washer GT SE. GT SE Millennium Edition. | ||
| 517302360 | RH Handle Ass'y Includes 61 - 67. GT SE. GT SE Millennium Edition. | ||
| 517302361 | LH Handle Ass'y GT SE. GT SE Millennium Edition. | ||
| 517302260 | Handle GT SE. GT SE Millennium Edition. | ||
| 517302262 | Stopper GT SE. GT SE Millennium Edition. | ||
| 517302263 | Spring GT SE. GT SE Millennium Edition. | ||
| 516000331 | RH Decal GT SE. GT SE Millennium Edition. | ||
| 516000332 | LH Decal GT SE. GT SE Millennium Edition. | ||
| 517302261 | Guard GT SE. GT SE Millennium Edition. | ||
| 517302321 | Gear GT SE. GT SE Millennium Edition. | ||
| 517302323 | Spacer GT SE. GT SE Millennium Edition. | ||
| 1 | 415110900 | VELCRO 1/2? | 1 |
| 517302269 | RH Plate Ass'y GT SE. GT SE Millennium Edition. | ||
| 517302270 | LH Plate Ass'y GT SE. GT SE Millennium Edition. | ||
| 250000031 | PHILLIPS TAPPING SCREW M4.8 X 16 GT SE. GT SE Millennium Edition. |
