Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 224701188 | WASHER-LOCK SPRING DIN.128A-A2 Formula Z. | ||
| 2 | 222003565 | Hex. Screw M10 x 35 Formula Z. | 2 |
| 503169200 | Pivot Welded Arm Formula Z. | ||
| 503154703 | Lower Axle Pivot Formula Z. | ||
| 6 | 224081201 | FLAT WASHER Formula Z. | 6 |
| 1 | 732601198 | Long Bolt M8 Formula Z. | 1 |
| 4 | 408200700 | Grease Fitting Formula Z. | 4 |
| 503172800 | Welded Rear Arm Formula Z. | ||
| 1 | 503144300 | Upper Axle, Pivot Arm Formula Z. | 1 |
| 1 | 732601197 | Bolt M8, Short Formula Z. | 1 |
| 3 | 228581045 | Elastic Stop Nut M8 Formula Z. | 3 |
| 2 | 224081171 | Flat Washer 8 mm Formula Z. | 2 |
| 503168700 | Rear Cross Shaft Formula Z. | ||
| 2 | 572080700 | Bushing Formula Z. | 2 |
| 415010500 | RH Spring Formula Z. | ||
| 415010600 | LH Spring Formula Z. | ||
| 2 | 228561045 | Elastic Stop Nut M6 Formula Z. | 2 |
| 572091400 | Idler Wheel Includes 17 - 18. Formula Z. | ||
| 2 | 405404500 | Ball Bearing 6205 Formula Z. | 2 |
| 2 | 503168800 | Retaining Ring Formula Z. | 2 |
| XXXX | Not Available As Spare Part - Socket Set Screw M6 Formula Z. | ||
| 1 | 572030800 | LH ADJUST CAM Formula Z. | 1 |
| 1 | 572030900 | RH ADJUST CAM Formula Z. | 1 |
| 4 | 224001211 | Flat Washer 10 mm Formula Z. | 4 |
| 371907100 | e Circlip Formula Z. | ||
| 415040400 | Shock Formula Z. | ||
| 2 | 414936000 | Bushing Formula Z. | 2 |
| 1 | 222085065 | Hex. Screw M8 x 50 Formula Z. | 1 |
| 2 | 572056600 | Spring Support Formula Z. | 2 |
| 503152700 | SPRING AXLE GUIDE Formula Z. | ||
| 517041700 | Retainer Washer Formula Z. | ||
| 2 | 222064565 | Hex. Screw M6 x 45 Formula Z. | 2 |
| 413706100 | LITHIUM GREASE, 400 GR Formula Z. | ||
| 2 | 222983065 | Socket Head Screw M8 x 30 Formula Z. | 2 |
| 2 | 224781140 | Lock Washer 8 mm Formula Z. | 2 |
| 222083066 | Hex. Screw M8 x 30 Formula Z. | ||
| 503158600 | Tie Rod Shaft Formula Z. | ||
| 503158700 | Tie Rod Formula Z. | ||
| 1 | 222087565 | Hex. Screw M8 x 75 Formula Z. | 1 |
| 503171900 | Bracket Weld Formula Z. | ||
| 503172900 | Bushing Formula Z. | ||
| 3 | 570049600 | RUBBER STOPPER Formula Z. | 3 |
| 503103600 | Cup Formula Z. | ||
| 371910700 | Circlip Formula Z. | ||
| 503173100 | Threaded Rod Formula Z. | ||
| 1 | 228701045 | Flange Elastic Nut M10 Formula Z. | 1 |
| 580647900 | Pivot Block Formula Z. | ||
| 1 | 415027800 | CUSHION Formula Z. | 1 |
| 1 | 413707400 | Loctite 271, 10cc Formula Z. | 1 |
| 1 | 228781045 | Elastic Flange Stop Nut M8 Formula Z. | 1 |
| 503172700 | Washer Formula Z. | ||
| 503173000 | Washer Formula Z. | ||
| 2 | 222903565 | Socket Head Screw M10 x 35 Formula Z. | 2 |
| 2 | 224001211 | Flat Washer 10 mm Formula Z. | 2 |
