Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 505067810 | Ski (Welded) Formula 500. Formula 583. | ||
| 572085700 | Ski Plastic Formula 500 Deluxe. Formula Z. | ||
| 518306700 | Support | ||
| 413706100 | LITHIUM GREASE, 400 GR | ||
| 505066320 | Carbide Runner Includes 4 - 5. Formula 500. Formula 583. | ||
| 505067320 | Runner Carbide (5) Formula 500 Deluxe. Formula Z. | ||
| 4 | 228581045 | Elastic Stop Nut M8 Formula 500. Formula 583. | 4 |
| 2 | 224080251 | Washer 8 mm Formula 500. Formula 583. | 2 |
| 517254800 | Front Link Plate | ||
| 2 | 222006065 | Hex. Screw M10 x 60 | 2 |
| 4 | 408200700 | Grease Fitting | 4 |
| 732601176 | Hex. Screw M12 | ||
| 2 | 228521045 | Elastic Stop Nut M12 | 2 |
| 414530600 | CUSHION | ||
| 8 | 228521045 | Elastic Stop Nut M12 | 8 |
| 570053500 | Ski Stopper Formula 500. Formula 583. | ||
| 570046800 | Ski Stopper Formula 500 Deluxe. Formula Z. | ||
| 506139200 | Ski Leg | ||
| 506081200 | Wear Plate | ||
| 572069900 | Cushion | ||
| 506134810 | LH Swing Arm Formula 500. Formula 500 Deluxe. | ||
| 506135010 | LH Swing Arm Formula Z. | ||
| 506133610 | LH Swing Arm Formula 583. | ||
| 506134710 | RH Swing Arm Formula 500. Formula 500 Deluxe. | ||
| 506134910 | RH Swing Arm Formula Z. | ||
| 506133710 | RH Swing Arm Formula 583. | ||
| 506080900 | Thrust Washer | ||
| 2 | 371910400 | CIRCLIP | 2 |
| 2 | 572091300 | Cap | 2 |
| 570062200 | DAMPER | ||
| 2 | 506115800 | Cup | 2 |
| 2 | 224781140 | Lock Washer 8 mm | 2 |
| 2 | 222982565 | Socket Head Screw M8 x 25 | 2 |
| 732601113 | Hex. Screw M12 x 100 | ||
| 2 | 572045900 | CAP | 2 |
| 222025075 | Hex. Screw M12 x 50 | ||
| 580649700 | Arm Ass'y (42") | ||
| 4 | 228501045 | Elastic Stop Nut M10 | 4 |
| 415040200 | Front Shock | ||
| 414976100 | Spring (Red) | ||
| 2 | 503140600 | Spring Stopper | 2 |
| 2 | 222005565 | Hex. Screw M10 x 55 | 2 |
| 8 | 390402300 | Pop Rivet 3/16" | 8 |
| 2 | 390909200 | Avex Rivet Formula 500. Formula 500 Deluxe. Formula 583. | 2 |
| 572069800 | Block Sliding | ||
| 506127300 | Ball Joint Formula 500. Formula 500 Deluxe. Formula 583. | ||
| 503142200 | Ball Joint Formula Z. | ||
| 506134100 | Stabilisator Formula 500. Formula 500 Deluxe. Formula 583. | ||
| 506131800 | Stabilisator Formula Z. | ||
| 572077600 | Half-Bushing Formula 500. Formula 500 Deluxe. Formula 583. | ||
| 572029900 | Half-Bushing Formula Z. | ||
| 506117300 | BUSHING Formula 500. Formula 583. | ||
| 2 | 503165100 | GUIDE_SPRING | 2 |
| 517254900 | Rear Link Plate | ||
| 503169000 | Cam | ||
| 1 | 413707000 | Dow Corning 111, 150 g | 1 |
| 2 | 503146700 | WASHER | 2 |
| 1 | 293550014 | Grease, Super Lube #823-28 | 1 |
| 6 | 228501045 | Elastic Stop Nut M10 Formula 500 Deluxe. Formula Z. | 6 |
| 580649800 | Arm Ass'y Formula Z. | ||
| 2 | 228371042 | Hex. Jam Nut M14 Formula Z. | 2 |
| 415042500 | RH Ball Joint Formula Z. | ||
| 2 | 228761045 | Elastic Flange Nut M6 Formula 500 Deluxe. Formula Z. | 2 |
| 2 | 222262565 | Carriage Bolt M6 x 25 Formula 500 Deluxe. Formula Z. | 2 |
| 505067500 | Ski Support Formula Z. | ||
| 505068100 | Ski Support Formula 500 Deluxe. | ||
| 505067509 | Stopper Formula 500 Deluxe. Formula Z. | ||
| 224002251 | FLAT WASHER Formula 500 Deluxe. Formula Z. | ||
| 2 | 222282565 | Carriage Bolt M8 x 25 Formula 500 Deluxe. Formula Z. | 2 |
| 6 | 228781045 | Elastic Flange Stop Nut M8 Formula 500 Deluxe. Formula Z. | 6 |
| 2 | 222283065 | Carriage Bolt M8 x 30 Formula 500 Deluxe. Formula Z. | 2 |
| XXXX | Not Available As Spare Part - Washer Formula 500 Deluxe. Formula Z. | ||
| 2 | 222284065 | Carriage Bolt M8 x 40 Formula 500 Deluxe. Formula Z. | 2 |
| 505063700 | Ski Reinforcement Formula Z. | ||
| 505068000 | Ski Reinforcement Formula 500 Deluxe. | ||
| 4 | 228761045 | Elastic Flange Nut M6 Formula Z. | 4 |
| 4 | 222065565 | Screw Hex. M6 x 55 Formula Z. | 4 |
| XXXX | Not Available As Spare Part - Rivet Formula Z. |
