Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 420886932 | Crankshaft Ass'y Formula 500. Formula 500 Deluxe. | ||
| 1 | 420827445 | DISTANCE RING Formula 500. Formula 500 Deluxe. | 1 |
| 420932589 | BALL BEARING 6206 ASS'Y Includes 3 - 4. Formula 500. Formula 500 Deluxe. | ||
| 420929972 | Dowel Pin Formula 500. Formula 500 Deluxe. | ||
| 1 | 420427684 | ADJUSTMENT WASHER Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420827050 | RETAINING DISK Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420945759 | Lock Washer, 22 mm Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420842230 | Hex. Nut M22 X 15 Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420827760 | DISTANCE RING Formula 500. Formula 500 Deluxe. | 1 |
| 2 | 420832239 | Ball Bearing 6207 Ass'y Includes 10 - 11. Formula 500. Formula 500 Deluxe. | 2 |
| 2 | 420832234 | Ball Bearing 6207 Formula 500. Formula 500 Deluxe. | 2 |
| 1 | 420927710 | Retaining Disk Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420831950 | Oil Seal Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 420246015 | Woodruff Key Formula 500. Formula 500 Deluxe. | 1 |
| 420832437 | Needle Bearing Formula 500. Formula 500 Deluxe. | ||
| 420887553 | Piston Ass'y (2 rings 69.39 mm) Includes 16 - 18. Formula 500. Formula 500 Deluxe. | ||
| 420887554 | Oversize Pist. Ass'y (2 rings 69.64 mm) Formula 500. Formula 500 Deluxe. | ||
| 420915985 | Rectangular Ring 69.5 mm Formula 500. Formula 500 Deluxe. | ||
| 420915986 | OVERSIZE RECTANGULAR RING 69.75 MM Formula 500. Formula 500 Deluxe. | ||
| 420815045 | Semi-trapez Ring 69.5 mm Formula 500. Formula 500 Deluxe. | ||
| 420815046 | Oversize Semi-trapez Ring 69.75 mm Formula 500. Formula 500 Deluxe. | ||
| 420916185 | PISTON PIN Formula 500. Formula 500 Deluxe. | ||
| 4 | 420945735 | Piston Circlip Formula 500. Formula 500 Deluxe. | 4 |
| 420932589 | BALL BEARING 6206 ASS'Y Includes 21 - 22. Formula 500. Formula 500 Deluxe. | ||
| 2 | 420831990 | Oil Seal Formula 500. Formula 500 Deluxe. | 2 |
| 420935748 | Central Gear 14 Teeth Formula 500. Formula 500 Deluxe. | ||
| 420818660 | Crankshaft (PTO side) Formula 500. Formula 500 Deluxe. | ||
| 420818690 | Crankshaft (MAG side) Formula 500. Formula 500 Deluxe. | ||
| 420886955 | Crankshaft Repair Kit (PTO side) Formula 500. Formula 500 Deluxe. | ||
| 420886956 | CRANKSHAFT REPAIR KIT (MAG SIDE) Formula 500. Formula 500 Deluxe. | ||
| 420847684 | Distance Sleeve Formula 500. Formula 500 Deluxe. | ||
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML Formula 500. Formula 500 Deluxe. | ||
| 1 | 293800039 | Loctite 642, 50 ml Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 413703000 | Loctite 242, 10 cc Formula 500. Formula 500 Deluxe. | 1 |
| 1 | 413707000 | Dow Corning 111, 150 g Formula 500. Formula 500 Deluxe. | 1 |
