Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 504144700 | Chaincase Formula 500. Formula Z. Formula 583. | ||
| 1 | 228911045 | Castellated Nut M20 Formula 500. Formula 583. | 1 |
| 228610012 | Castellated Nut M20 Formula Z. | ||
| 371801300 | Cotter Pin Formula 500. Formula 583. | ||
| 371006300 | PIN COTTER Formula 500. Formula Z. | ||
| 504087100 | Washer Formula 500. Formula Z. Formula 583. | ||
| 504078400 | Sprocket Narrow (23 Tooth) Formula 500. | ||
| 1 | 504084300 | Sprocket 25 Teeth (Large) Formula Z. | 1 |
| 504085200 | Sprocket (25 Tooth, Narrow) Formula 583. | ||
| 504093400 | Shim Formula 500. Formula Z. Formula 583. | ||
| 1 | 405404400 | Ball Bearing <<6205>> Formula 500. Formula Z. Formula 583. | 1 |
| 413706100 | LITHIUM GREASE, 400 GR Formula 500. Formula Z. Formula 583. | ||
| 1 | 414882800 | OIL SEAL Formula 500. Formula 583. | 1 |
| 414531200 | Seal Formula 500. Formula Z. | ||
| 371901700 | CIRCLIP Formula 500. Formula Z. Formula 583. | ||
| 504057300 | Sprocket Narrow (44 Tooth) Formula 500. Formula 583. | ||
| 504085500 | Sprocket Large (44 Tooth) Formula Z. | ||
| 501021800 | Inner Shim Formula 500. Formula Z. Formula 583. | ||
| 412105500 | Drive Chain, (72 Links-Narrow) Formula 500. | ||
| 1 | 412106900 | Drive Chain (74 Links-Large) Formula Z. | 1 |
| 412105800 | Drive Chain Narrow (74 Links) Formula 583. | ||
| 1 | 504081000 | MACHINED TENSIONER Formula 500. Formula Z. Formula 583. | 1 |
| 2 | 504080300 | WASHER Formula 500. Formula Z. Formula 583. | 2 |
| 1 | 405403000 | NEEDLE BEARING Formula 500. Formula Z. Formula 583. | 1 |
| 414531300 | ROLLER Formula 500. Formula Z. Formula 583. | ||
| 1 | 504080200 | SPACER Formula 500. Formula Z. Formula 583. | 1 |
| 732601267 | Tensioner Adjustment Screw (Forging) Formula 500. Formula Z. Formula 583. | ||
| 732900020 | Copper Washer Formula 500. Formula Z. Formula 583. | ||
| 1 | 414484400 | O-Ring Formula 500. Formula Z. Formula 583. | 1 |
| 1 | 414575600 | Hair Pin Formula 500. Formula Z. Formula 583. | 1 |
| 732601112 | Hex. Screw M10 x 40 Formula 500. Formula Z. Formula 583. | ||
| 5 | 228501045 | Elastic Stop Nut M10 Formula 500. Formula Z. Formula 583. | 5 |
| 732601111 | Hex. Screw M10 x 70 Formula 500. Formula Z. Formula 583. | ||
| 504083800 | Spacer Formula 500. Formula Z. Formula 583. | ||
| 501022100 | Protector Formula 500. Formula Z. Formula 583. | ||
| 414362300 | O-Ring Formula 500. Formula Z. Formula 583. | ||
| 080037100 | CASTING COVER Formula 500. Formula Z. Formula 583. | ||
| 4 | 732600004 | Hex. Flange Screw M6 x 30 Formula 500. Formula Z. Formula 583. | 4 |
| 572092700 | FILLER CAP ASS'Y Formula 500. Formula Z. Formula 583. | ||
| 1 | 504073700 | WASHER Formula 500. Formula Z. Formula 583. | 1 |
| 3 | 224001211 | Flat Washer 10 mm Formula 500. Formula Z. Formula 583. | 3 |
| 501022400 | Cap Formula 500. Formula Z. Formula 583. | ||
| 414969400 | O-RING Formula 500. Formula Z. Formula 583. | ||
| 224701188 | WASHER-LOCK SPRING DIN.128A-A2 Formula 500. Formula Z. Formula 583. | ||
| 1 | 222002565 | Hex. Screw M10 x 25 Formula 500. Formula Z. Formula 583. | 1 |
| 732601132 | Socket Head Screw M8 x 10 Formula 500. Formula Z. Formula 583. | ||
| 2 | 504082900 | Washer Formula 500. Formula Z. Formula 583. | 2 |
| 219704462 | ADHESIVE LOCTITE 515 50ML Formula 500. Formula Z. Formula 583. | ||
| 581056500 | OIL SEAL ASS'Y Formula 500. Formula Z. Formula 583. | ||
| 1 | 732601144 | SCREW Formula 500. Formula Z. Formula 583. | 1 |
| 1 | 413707400 | Loctite 271, 10cc Formula 500. Formula Z. Formula 583. | 1 |
| 417000900 | Spring Washer Formula 500. Formula 583. | ||
| 1 | 413703000 | Loctite 242, 10 cc Formula 500. Formula Z. Formula 583. | 1 |
| 414784900 | Circlip (Int-rior) Formula 500. Formula Z. Formula 583. | ||
| 405403900 | Ball Bearing 6206 Formula 500. Formula Z. Formula 583. |
