Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 403138550 | VM 36-190 Carburetor Includes 1 - 37. Formula III 600. | ||
| 403138551 | VM 38 Central Carburetor Formula III 700. | ||
| 404105100 | COVER Formula III 600. Formula III 700. | ||
| 3 | 404154800 | Spring Formula III 600. Formula III 700. | 3 |
| 3 | 404122100 | Cover Formula III 600. Formula III 700. | 3 |
| 3 | 404160800 | CONNECTOR Formula III 600. Formula III 700. | 3 |
| 6 | 404121300 | Screw With Washer Formula III 600. Formula III 700. | 6 |
| 404157900 | Needle J8-6DEY2 Formula III 600. | ||
| 404161800 | Needle J8-6DEH5 Formula III 700. | ||
| 3 | 404152400 | E-Ring Formula III 600. Formula III 700. | 3 |
| 3 | 404105500 | Guide Screw Formula III 600. Formula III 700. | 3 |
| 404154700 | Valve Piston 2.5 Formula III 600. | ||
| 404131300 | Piston Valve CA 2.5 Formula III 700. | ||
| 404158500 | Needle Jet Formula III 600. | ||
| 404159000 | Needle Jet Formula III 700. | ||
| 404104700 | GASKET Formula III 600. Formula III 700. | ||
| 3 | 404109500 | PILOT JET 50 Formula III 600. Formula III 700. | 3 |
| 3 | 404103300 | Lever Pin Formula III 600. Formula III 700. | 3 |
| 3 | 404105000 | FLOAT LEVER Formula III 600. Formula III 700. | 3 |
| 404105400 | FLOAT Formula III 600. Formula III 700. | ||
| 3 | 404101500 | O-RING Formula III 600. Formula III 700. | 3 |
| 404105600 | DRAIN PLUG SCREW Formula III 600. Formula III 700. | ||
| 3 | 404149000 | AIR SCREW Formula III 600. Formula III 700. | 3 |
| 404139800 | SPRING Formula III 600. Formula III 700. | ||
| 3 | 404101700 | Spring Formula III 600. Formula III 700. | 3 |
| 404154400 | Adjuster Formula III 600. | ||
| 404102800 | IDLE SPEED SCREW Formula III 700. | ||
| 6 | 404105800 | Cap Formula III 600. Formula III 700. | 6 |
| 6 | 404101600 | Seat Washer Formula III 600. Formula III 700. | 6 |
| 3 | 404147400 | Needle Valve 1.5 Formula III 600. Formula III 700. | 3 |
| 3 | 404100400 | Main Jet MJ 270 Formula III 600. | 3 |
| 3 | 404101100 | Main Jet 290 Formula III 700. | 3 |
| 6 | 404103000 | PLATE Formula III 600. Formula III 700. | 6 |
| 12 | 404102000 | Screw With Lock Washer Formula III 600. Formula III 700. | 12 |
| 404161802 | Air Vent Tube Formula III 600. Formula III 700. | ||
| 3 | 404153400 | Nipple Formula III 600. Formula III 700. | 3 |
| 3 | 404161100 | GUIDE HOLDER Formula III 600. Formula III 700. | 3 |
| XXXX | Not Available As Spare Part - Baffle Formula III 600. Formula III 700. | ||
| 404127400 | SPRING Formula III 600. Formula III 700. | ||
| 3 | 404161000 | PLUNGER ASS'Y Formula III 600. Formula III 700. | 3 |
| 3 | 404154900 | CAP Formula III 600. Formula III 700. | 3 |
| 404158900 | Filter Formula III 600. Formula III 700. | ||
| 3 | 404117000 | Packing Formula III 700. | 3 |
| 404152500 | Cap Formula III 700. | ||
| 404112000 | TOOL KIT Formula III 600. Formula III 700. | ||
| 861767000 | High Altitude Kit, (Not Shown) Formula III 600. | ||
| 861766900 | High Altitude Kit, (Not Shown) Formula III 700. |
