Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 400800311 | Engine <<809>> Mach Z (Sport). | ||
| 400800310 | Engine <<809>> Mach Z (Tech Plus). | ||
| 512059089 | Engine Support (MAG Side) | ||
| 512059090 | Engine Support (PTO Side) | ||
| 8 | 234001410 | Flat Washer 10 mm | 8 |
| 234100602 | WASHER-LOCK SPRING DIN.128A-A2 | ||
| 4 | 232006414 | Hex. Nut M10 X 1.5 | 4 |
| 570128700 | RUBBER MOUNT | ||
| 4 | 233601416 | Elastic Locking Nut M10 X 1.5 | 4 |
| 512050900 | Engine Support | ||
| 4 | 512056700 | Lock Washer | 4 |
| 4 | 207102544 | Hex. Screw M10 X 25 | 4 |
| 1 | 512056000 | STOPPER PLATE | 1 |
| 1 | 234181401 | Lock Washer 8 mm | 1 |
| 1 | 207181644 | Hex. Screw M8 x 16 | 1 |
| 512056900 | Stopper Screw | ||
| 512059055 | STOPPER | ||
| 512059058 | Washer | ||
| 1 | 232120414 | HEX. NUT M12 | 1 |
| 3 | 414961100 | Spark Plug NGK BR9ES | 3 |
| 516000986 | Spark Plug Decal | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 2 | 514052743 | RUBBER MOUNT | 2 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 514052887 | Support | ||
| 517294300 | Bracket | ||
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 570066200 | Exhaust Grommet | ||
| 514053346 | Muffler Ass'y Includes 28 - 32. | ||
| 514053374 | RH Heat Shield | ||
| 514052835 | LH Heat Shield | ||
| 14 | 390910000 | Pop Rivet 3/16” | 14 |
| 514052862 | Heat Shield | ||
| XXXX | Not Available As Spare Part - R.H. Insulator | ||
| XXXX | Not Available As Spare Part - L.H. Insulator | ||
| 420978818 | Exhaust Socket | ||
| 3 | 420850552 | Gasket | 3 |
| 12 | 205062544 | Socket Head Screw M6 X 25 | 12 |
| 12 | 234161471 | Lock Washer M6, Black | 12 |
| 514052766 | Tuned Pipe Ass'y Includes 37 - 45. | ||
| 514052774 | Upper Shell | ||
| 514052775 | Lower Shell | ||
| 514052776 | Insulator | ||
| 514052866 | Rubber Pad | ||
| 3 | 514052859 | Norma Gear Clamp | 3 |
| 514052860 | Norma Clamp | ||
| 3 | 514052924 | Norma Clamp | 3 |
| 3 | 514052861 | Gear Clamp (Norma) | 3 |
| 514052954 | Support | ||
| 514052955 | Spring Bracket | ||
| 514052777 | RH Tuned Pipe Support | ||
| 514052778 | LH Tuned Pipe Support | ||
| 2 | 207152044 | Hex. Screw M5 X 20 | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 2 | 391301700 | Washer | 2 |
| 514052779 | Tail Pipe (MAG) | ||
| 514052782 | Tail Pipe (Center) | ||
| 514052785 | Tail Pipe (PTO) | ||
| 514052788 | Support | ||
| 1 | 293800090 | Sealant, Loctite, 80 ml | 1 |
| 27 | 415107100 | Spring | 27 |
| 415083800 | RH Reflective Sheet | ||
| 415083900 | Leaf Valve Ø16 X 0.114 (C36) | ||
| 415111900 | Reflective Sheet | ||
| 415115000 | Reflective Sheet | ||
| 415112300 | RH Reflective Sheet | ||
| 415112400 | LH Reflective Sheet | ||
| 514052950 | Reflective Sheet | ||
| 415112500 | RH Reflective Sheet | ||
| 415112600 | LH Reflective Sheet | ||
| 415114800 | RH Reflective Sheet | ||
| 415114900 | LH Reflective Sheet | ||
| 570044100 | Rubber Pad | ||
| 2 | 390906800 | Pop Rivet 3/16" | 2 |
| 2 | 517225900 | Flat Washer | 2 |
| 10 | 390409600 | Pop Rivet 3/16" | 10 |
| 514051000 | Spring Bracket | ||
| 514052951 | Reflective Sheet | ||
| 514052956 | Reflective Sheet | ||
| 2 | 570048700 | Rubber Bumper | 2 |
