Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 511000317 | RACK | 1 |
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 511000398 | INSERT | ||
| 511000322 | RH OUTSIDE ARM | ||
| 1 | 511000326 | RH INSIDE ARM | 1 |
| 1 | 511000323 | LH OUTSIDE ARM | 1 |
| 1 | 511000327 | LH INSIDE ARM | 1 |
| 1 | 511000321 | RH SIDE BAR | 1 |
| 1 | 511000345 | LH SIDE BAR | 1 |
| 510004442 | REFLECTOR Sport | ||
| 1 | 511000431 | BULB SUPPORT | 1 |
| 1 | 511000466 | BULB SOCKET | 1 |
| 1 | 410504100 | Bulb | 1 |
| 1 | 511000315 | Lens Sport | 1 |
| 861509300 | Lens And Reflector Kit Includes 15 to 17, LTD | ||
| XXXX | Not Available As Spare Part - Lens, Clear | ||
| 510004442 | REFLECTOR | ||
| 2 | 209632580 | PHILLIPS TAPPING SCREW 3.9 X 25 | 2 |
| 2 | 414516400 | Washer | 2 |
| 1 | 515175494 | Male Housing, 3 Circuits | 1 |
| 1 | 515175232 | Male Terminal | 1 |
| 1 | 511000354 | HITCH, BLACK Europe | 1 |
| 517152700 | Hitch Protector Europe | ||
| 1 | 517152800 | SPRING Europe | 1 |
| XXXX | Not Available As Spare Part - Chain Europe | ||
| 1 | 114045200 | Hair Pin Europe | 1 |
| 1 | 207063044 | Hex. Screw M6 X 30 Europe | 1 |
| 1 | 232561414 | Elastic Stop Nut M6 Europe | 1 |
| 390409400 | RIVET_POP 5/32 X ,400 BLACK Europe | ||
| 1 | 732804000 | SPRING PIN M3 X 24 Europe | 1 |
| XXXX | Not Available As Spare Part - Flat Washer Europe | ||
| 1 | 516003037 | WARNING DECAL-SECURITY-ENGLISH Europe | 1 |
| 2 | 205484546 | Socket Head Screw M8 X 45 Europe | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 Europe | 2 |
| 1 | 511000440 | RADIATOR COVER Sport | 1 |
| 511000439 | Radiator Cover LTD | ||
| 2 | 250000113 | Screw M4 X 16, Type K-40 Sport | 2 |
| 511000357 | Tank Cover | ||
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
| 1 | 516002960 | WARNING DECAL, MAXIMUM CARGO LOAD | 1 |
| 1 | 511000442 | RH SUITCASE Includes 40 to 42, LTD | 1 |
| 1 | 520000237 | REAR REFLECTOR, RED LTD | 1 |
| 219902477 | BRP Logo, Vinyl LTD | ||
| 511000443 | LH Suitcase Includes 43 to 45, LTD | ||
| 2 | 511000341 | THREAD INSERT | 2 |
| 2 | 250000198 | TORX TRUSS SCREW M8 X 16 Sport | 2 |
| 2 | 511000337 | SUITCASE STUD LTD | 2 |
| 2 | 511000423 | STUD NUT LTD | 2 |
| 2 | 511000358 | RUBBER BUMPER LTD | 2 |
| 511000338 | SUPPORT ROD LTD | ||
| 4 | 205882044 | SOCKET HEAD SCREW M8 X 20, SCOTCH GRIP LTD | 4 |
| 2 | 207162544 | Hex. Screw M6 X 25 | 2 |
| 2 | 511000340 | FLANGED BUSHING | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 250000197 | Torx Truss Screw M8 X 30 | ||
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 511000325 | BUSHING | 2 |
| 2 | 250000130 | Torx Screw M5 X 20 | 2 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 1 | 516003035 | CLENCHING DECAL | 1 |
| 516003036 | Seat Decal LTD |
