Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | XXXX | Not Available As Spare Part - Engine 1200 4-TEC | |
| 2 | 512060591 | Rear Support, PTO | 1 |
| 3 | 207585086 | Hex. Flange Screw M8 X 50, Scotch Grip | 1 |
| 4 | 234281474 | Conical Spring Washer M8 | 3 |
| 5 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 1 |
| 6 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 1 |
| 7 | 512060593 | Front Support, PTO | 1 |
| 8 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 9 | 234281474 | Conical Spring Washer M8 | 2 |
| 10 | 512060594 | Rear Support, MAG | 1 |
| 11 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 12 | 234281474 | Conical Spring Washer M8 | 2 |
| 13 | 512060596 | Front Support, MAG | 1 |
| 14 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 15 | 234281474 | Conical Spring Washer M8 | 2 |
| 16 | 512060729 | Rubber Mount | 2 |
| 17 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 18 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 19 | 207562534 | Hex. Flange Screw M6 X 25, Scotch Grip | 1 |
| 20 | 207586044 | Hex. Flange Screw M8 X 60, Scotch Grip | 2 |
| 21 | 503183200 | Yellow, Washer | 3 |
| 22 | 250200008 | Flat Washer With Teflon 8 mm | 2 |
| 23 | 250000257 | Cone Screw, M8 X 30 | 2 |
| 24 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 25 | 512060244 | Stopper | 2 |
| 26 | 512060285 | Spacer | 2 |
| 27 | 293650047 | Crimp Clamp, 15.3-706R | 2 |
| 28 | 512061256 | Housing Ass'y Includes 28 to 34 | 1 |
| 29 | 415130047 | Handle Ass'y kit | 1 |
| 30 | 512060862 | Cap | 1 |
| 31 | 250000623 | Torx Screw M2.9 x 9.5 | 3 |
| 32 | 250000671 | Torx Screw | 4 |
| 33 | 512060961 | Screw | 1 |
| 34 | 250000528 | Torx Screw M5 X 20 | 1 |
| 43 | 515177362 | Emergency Stop Switch | 1 |
| 45 | 512060844 | Support | 1 |
| 46 | 294000973 | Friction Tape | 1 |
| 47 | 515177946 | Protector Tube | 1 |
| 48 | 250000263 | Torx Screw #8-18 | 2 |
| 49 | 512060987 | Front Housing | 1 |
| 50 | 250000632 | Torx Screw M5 X 14 | 2 |
| 51 | 241151640 | Hex. Flange Screw K50 X 2.24 X 16 | 4 |
| 52 | 512061012 | Module Support | 1 |
| 53 | 250000958 | Panel Nut M5 X 0.8 | 2 |
| 54 | 207552044 | Hex. Flange Screw M5 X 20, Scotch Grip | 2 |
| 55 | 516005521 | Caution Decal, Oil Level | 1 |
| 56 | 39065 | Aluminium coated fiberglass tube | |
| 57 | 414115200 | Tie-Rap 180 mm | 1 |
| 58 | 512060675 | Heat Shield | |
| 59 | 20068 | Lock Washer D10 | 1 |
| 60 | 205002044 | Screw-socket M10 X 20 | |
| 61 | 414115200 | Tie-Rap 180 mm | 1 |
| 62 | 414115200 | Tie-Rap 180 mm | 1 |
| 63 | 414115200 | Tie-Rap 180 mm | 1 |
| 64 | 293750002 | Tie Wrap 142 mm | 1 |
