Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 503179000 | Runner Formula Deluxe 670. | ||
| 503188953 | Shoe Runner Formula Deluxe 670. | ||
| 2 | 216362560 | Countersunk Phillips Screw M6 x 25 Formula Deluxe 670. | 2 |
| 2 | 228561045 | Elastic Stop Nut M6 Formula Deluxe 670. | 2 |
| 572075400 | RUNNER PROTECTOR Formula Deluxe 670. | ||
| 222052565 | SCREW-HEX.CAP DIN.933 Formula Deluxe 670. | ||
| 4 | 228551045 | Elastic Stop Nut M5 Formula Deluxe 670. | 4 |
| 4 | 391301600 | Washer Formula Deluxe 670. | 4 |
| 1 | 503151600 | Axle Formula Deluxe 670. | 1 |
| 2 | 732601284 | Hex. Flange Screw M8 x 25 Formula Deluxe 670. | 2 |
| 570063000 | Rubber Stopper Formula Deluxe 670. | ||
| 2 | 572084800 | Reinforcement Stopper Formula Deluxe 670. | 2 |
| 222054065 | SCREW-HEX.CAP DIN.931 Formula Deluxe 670. | ||
| 4 | 391301700 | Washer Formula Deluxe 670. | 4 |
| 503174600 | SUPPORT Formula Deluxe 670. | ||
| 2 | 572097612 | Bonded Wheel 135 Includes 16 - 17. Formula Deluxe 670. | 2 |
| 2 | 405404500 | Ball Bearing 6205 Formula Deluxe 670. | 2 |
| 371901700 | CIRCLIP Formula Deluxe 670. | ||
| 503173700 | WASHER Formula Deluxe 670. | ||
| 2 | 222088565 | Hex. Screw M8 x 85 Formula Deluxe 670. | 2 |
| 2 | 503183100 | Washer Formula Deluxe 670. | 2 |
| 4 | 228781045 | Elastic Flange Stop Nut M8 Formula Deluxe 670. | 4 |
| 2 | 222082565 | Hex. Screw M8 x 25 Formula Deluxe 670. | 2 |
| 4 | 503188997 | Wheel 135 Includes 24 - 25. Formula Deluxe 670. | 4 |
| 4 | 405404500 | Ball Bearing 6205 Formula Deluxe 670. | 4 |
| 8 | 415112700 | Cushion Formula Deluxe 670. | 8 |
| 8 | 503154000 | WASHER Formula Deluxe 670. | 8 |
| 6 | 207603044 | Hex. Flange Screw M10 X 30 Formula Deluxe 670. | 6 |
| 503153100 | Spacer Formula Deluxe 670. | ||
| 503188800 | SPACER Formula Deluxe 670. | ||
| 503155300 | Tensioner Formula Deluxe 670. | ||
| 4 | 222062065 | Hex. Screw M6 x 20 Formula Deluxe 670. | 4 |
| 4 | 228761045 | Elastic Flange Nut M6 Formula Deluxe 670. | 4 |
| 732601017 | Hex. Screw M10 x 110 Formula Deluxe 670. | ||
| 2 | 228501045 | Elastic Stop Nut M10 Formula Deluxe 670. | 2 |
| 1 | 503160700 | Rear Axle Formula Deluxe 670. | 1 |
| 2 | 503188949 | Wheel 180 (Yellow 2000) Includes 37 - 38. Formula Deluxe 670. | 2 |
| 2 | 503183300 | Washer Formula Deluxe 670. | 2 |
| 1 | 572106400 | Plastic Wheel 180 Includes 40 - 41. Formula Deluxe 670. | 1 |
| 1 | 405404500 | Ball Bearing 6205 Formula Deluxe 670. | 1 |
| 1 | 503182900 | Inner Spacer Formula Deluxe 670. | 1 |
| 503183000 | CENTRAL SPACER Formula Deluxe 670. | ||
| 4 | 503180400 | Washer Formula Deluxe 670. | 4 |
| 2 | 503154800 | Outer Spacer Formula Deluxe 670. | 2 |
| 572102300 | Spacer Formula Deluxe 670. | ||
| 503181100 | Axle Formula Deluxe 670. | ||
| 1 | 413707400 | Loctite 271, 10cc Formula Deluxe 670. | 1 |
| 2 | 503188700 | WHEEL AXLE Formula Deluxe 670. | 2 |
| 732601002 | Hex. Screw Formula Deluxe 670. | ||
| 503189215 | Spacer Formula Deluxe 670. | ||
| 4 | 570063600 | Wheel Cap Formula Deluxe 670. | 4 |
