Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 To 32 | ||
| 1 | 417222937 | Fixed Flange Ass'y | 1 |
| 1 | 417222181 | Sliding Flange Ass'y Includes 3 To 6 | 1 |
| 1 | 417222758 | Bushing | 1 |
| XXXX | Not Available As Spare Part - Loctite 609, 50ml | ||
| 1 | 293370037 | Circlip | 1 |
| 3 | 417222671 | Lever | 3 |
| 3 | 417222947 | Roller | 3 |
| 6 | 417004302 | Stopper Washer | 6 |
| 1 | 417222594 | Pin | 1 |
| 3 | 250400060 | Cotter Pin | 3 |
| 3 | 417223164 | Lever Axle | 3 |
| 1 | 417222312 | Spring Seat | 1 |
| 1 | 414993000 | Tra Spring | 1 |
| 1 | 417007500 | Spring Cover Ass'y Includes 15 To 17 | 1 |
| 1 | 417009204 | Bushing | 1 |
| 3 | 205084044 | Socket Head Screw M8 X 1.25 X 40 | 3 |
| 3 | 250200009 | Lock Washer 8 mm | 3 |
| 1 | 417223669 | Governor Cup Ass'y | 1 |
| 3 | 417222444 | Ramp 600 | 3 |
| 3 | 250400050 | Spring Pin M10 X 22 | 3 |
| 6 | 250000418 | Hex. Flange Screw M6 X 18, Scotch Grip | 6 |
| 3 | 417223501 | Calibration Screw | 3 |
| 3 | 417005600 | Washer | 3 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
| 6 | 732401030 | O-Ring | 6 |
| 420460045 | Corrugated Tube NW 6 Slit 385MM | ||
| 1 | 417223042 | Ring Gear | 1 |
| 6 | 250000533 | Hex. Flange Screw M8 X 1.25 X 16 | 6 |
| 6 | 250000412 | Hex. Flange Screw M6 X 12, Scotch Grip | 6 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 250200006 | Spring Washer 14 mm | 1 |
| 1 | 417120000 | Drive Pulley Bolt | 1 |
| 1 | 516005503 | Decal English | 1 |
| XXXX | Not Available As Spare Part - Driven Pulley Ass'y Includes 36 To 54 | ||
| 1 | 417127346 | Fixed Flange Ass'y Includes 37 To 41 | 1 |
| 2 | 417127189 | Roller | 2 |
| 2 | 417127294 | Pivot Stud | 2 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| 2 | 250400061 | Spring Pin M3 X 18 | 2 |
| 1 | 417127231 | Slider Flange Ass'y Includes 42 To 43 | 1 |
| 1 | 293370049 | Circlip | 1 |
| 1 | 417127205 | Cam Ass'y Includes 44 To 45 | 1 |
| 1 | 417127243 | Spring, White | 1 |
| 4 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 4 |
| 1 | 415129604 | Calibration Ass'y | 1 |
| 1 | 205052544 | Socket Screw M5 X 25 | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 232551414 | Elastic Stop Nut M5 | 1 |
| 1 | 417127155 | Washer | 1 |
| 1 | 517302322 | Strength Washer | 1 |
| 1 | 207287544 | Hex. Cap Screw M8 X 75 | 1 |
| XXXX | Not Available As Spare Part - Loctite 8151 (Antiseize), 400ml Spray | ||
| 1 | 417300265 | Spacer | 1 |
| 1 | 504112000 | Shim | 1 |
| 1 | 417300383 | Drive Belt | 1 |
| 1 | 417300357 | Belt Guard | 1 |
| 516004649 | Security label, Belt Guard | ||
| 1 | 417300380 | Reinforcement | 1 |
| 4 | 390909200 | Avex Rivet | 4 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300356 | Side Protector | 1 |
| 5 | 293150103 | Pop Rivet 3/16" | 5 |
| 1 | 417300413 | Belt Guard Bracket | 1 |
| 417300451 | BELT GUARD BRACKET | ||
| 1 | 518327035 | Brake Hose Cover | 1 |
| 2 | 293150163 | Rivet Hucklok | 2 |
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 517281905 | Bracket | 1 |
| 2 | 390909100 | Avex Rivet | 2 |
| 1 | 516005511 | Belt Decal, English | 1 |
| 1 | 512060696 | Support Coils | 1 |
| 2 | 207162044 | Hex. Screw M6 X 20 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
