Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 207161844 | Hex. Screw M6 X 18 | 4 |
| 1 | 501026300 | COUNTER SHAFT | 1 |
| 1 | 507021300 | KEY | 1 |
| 1 | 414784800 | CORK | 1 |
| 507031300 | BRAKE DISK | ||
| 1 | 517302322 | Strength Washer | 1 |
| 4 | 234161471 | Lock Washer M6, Black | 4 |
| 1 | 207087544 | HEX. SCREW M8 X 75 | 1 |
| 1 | 501026900 | Flange | 1 |
| 080039300 | Spacer (Casting) | ||
| 2 | 232581414 | Hex. Elastic Stop Nut M8 | 2 |
| 2 | 205483046 | SOCKET HEAD SCREW M8 X 30 | 2 |
| 1 | 504149100 | Spacer | 1 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML Mach Z. | ||
| 206263044 | Socket Set Screw M6 X 30 Mach Z. | ||
| 504141900 | Thrust Washer Mach Z. | ||
| 414820800 | Key Mach Z. | ||
| 414558900 | RELEASE SPRING, BEIGE Mach Z. | ||
| 417126387 | Cam Mach Z. | ||
| 371903100 | CIRCLIP Mach Z. | ||
| 3 | 232061414 | Hex. Nut M6 Mach Z. | 3 |
| 420245370 | WASHER Mach Z. | ||
| 504143200 | Sliding Flange Ass'y Mach Z. | ||
| 414918000 | CAM SLIDER SHOE Mach Z. | ||
| 415011200 | BUSHING Mach Z. | ||
| 860423000 | Garlock Bushing Kit Includes 27 - 28. Mach Z. | ||
| 205451286 | SCREW M5 X 12 Mach Z. | ||
| 399910000 | Flat Washer Mach Z. | ||
| 12 | 210251180 | HEX. FLANGED SCREW M5 X 11 Mach Z. | 12 |
| 504142100 | Ring Mach Z. | ||
| 504141800 | Washer Mach Z. | ||
| 417010200 | Fixed Flange Mach Z. | ||
| 1 | 504142000 | CUP Mach Z. | 1 |
| 417126414 | Fixed Flange Ass'y Includes 35 - 38. Mach Z R. Mach Z R Millennium Edition. | ||
| 415005800 | Adjustment Ring Mach Z R. Mach Z R Millennium Edition. | ||
| 415005900 | Adjustment Shim Mach Z R. Mach Z R Millennium Edition. | ||
| 1 | 207162544 | Hex. Screw M6 X 25 Mach Z R. Mach Z R Millennium Edition. | 1 |
| 1 | 207162244 | HEX. SCREW M6 X 22 Mach Z R. Mach Z R Millennium Edition. | 1 |
| 417126318 | Sliding Flange Ass’Y Includes 39 - 44. Mach Z R. Mach Z R Millennium Edition. | ||
| 417126373 | REAR CAM SLIDER SHOE, RED Mach Z R. Mach Z R Millennium Edition. | ||
| 3 | 417126374 | Front Cam Slider Shoe, Black Mach Z R. Mach Z R Millennium Edition. | 3 |
| XXXX | Not Available As Spare Part - Bushing Mach Z R. Mach Z R Millennium Edition. | ||
| 414978100 | BUSHING Mach Z R. Mach Z R Millennium Edition. | ||
| 371911200 | CIRCLIP Mach Z R. Mach Z R Millennium Edition. | ||
| 417126385 | Cam Ass'y Mach Z R. Mach Z R Millennium Edition. | ||
| 1 | 417126381 | GUARD Mach Z R. Mach Z R Millennium Edition. | 1 |
| 1 | 504099600 | STOPPER WASHER Mach Z R. Mach Z R Millennium Edition. | 1 |
| 1 | 414978300 | Release Spring, Purple Mach Z R. Mach Z R Millennium Edition. | 1 |
| 417126375 | Spacer Mach Z R. Mach Z R Millennium Edition. | ||
| 2 | 371911000 | HALF KEY Mach Z R. Mach Z R Millennium Edition. | 2 |
| 1 | 504112300 | SHIM Mach Z R. Mach Z R Millennium Edition. | 1 |
| 504149700 | Aerodynamic Cover Mach Z R. Mach Z R Millennium Edition. | ||
| 1 | 504151831 | AERODYNAMIC COVER Mach Z R. Mach Z R Millennium Edition. | 1 |
| 732600032 | Screw M5 x 11 Mach Z R. Mach Z R Millennium Edition. | ||
| 1 | 417126322 | SWIVEL ABUTMENT Mach Z R. Mach Z R Millennium Edition. | 1 |
| 417300055 | Protector Mach Z R. Mach Z R Millennium Edition. | ||
| 1 | 417300054 | Spacer Mach Z R. Mach Z R Millennium Edition. | 1 |
| 417126302 | SPACER Mach Z. | ||
| 293800023 | LUBRICANT LOCTITE LB 8150 | ||
| 2 | 234081410 | Flat Washer 8 mm | 2 |
| 405408200 | BALL BEARING |
