Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 1 | 234042600 | Flat Washer 4 mm, Stainless | 1 |
| 1 | 241141660 | Hex. Flange Screw K40 X 16 | 1 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 | 1 |
| 1 | 250000128 | Torx Truss Screw M6 X 20 | 1 |
| 4 | 250000129 | Torx Screw M6 X 16 | 4 |
| 1 | 250000146 | Truss Head Torx Screw K50 X 16 | 1 |
| 1 | 250000465 | Torx Screw M5 X 20 | 1 |
| 1 | 250200024 | Rubber Washer 5 mm | 1 |
| 2 | 250200025 | Washer M5 | 2 |
| 1 | 293150108 | Pop Rivet 3/16” SE Model | 1 |
| 2 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 2 |
| 515176493 | BULB HOLDER | ||
| 2 | 515176498 | Cap | 2 |
| 2 | 515176499 | Cover | 2 |
| 1 | 517302785 | Edge Clip | 1 |
| 1 | 517303612 | RH Panel Latch | 1 |
| 1 | 517303739 | Black Hood | 1 |
| 517304374 | HOOD, BRIGHT WHITE | ||
| 517305158 | HOOD B-341 | ||
| 517305159 | HOOD B-321 | ||
| 1 | 517303741 | Black Console | 1 |
| 1 | 517304381 | CONSOLE, BRIGHT WHITE | 1 |
| 1 | 517305163 | MAGNESIUM CONSOLE ASS'Y | 1 |
| 1 | 517305259 | CONSOLE B-341 ASSY | 1 |
| XXX | Not Available As Spare Parts Grand Touring Model | ||
| 517304373 | PANEL_BODY LWR R B-160 | ||
| 1 | 517304894 | CENTRAL FOAM PANEL RH | 1 |
| 1 | 517304895 | REAR PANEL FOAM RH | 1 |
| 1 | 517303753 | Black LH Pannel GSX LE, SE Model | 1 |
| 1 | 517305327 | White LH Pannel | 1 |
| 1 | 517305174 | PANEL_BODY LH B-321 | 1 |
| 1 | 517304362 | PANEL_BODY LWR L B-160 | 1 |
| 1 | 517303756 | Grommet | 1 |
| 1 | 517305233 | DEFLECTOR_AIR KNEE LH B-341 | 1 |
| 1 | 517305232 | DEFLECTOR_AIR KNEE RH B-341 | 1 |
| 517303797 | HIGHT WINDSHIELD (430) GSX Model | ||
| 1 | 517303798 | Medium Windshield Support GSX Model | 1 |
| 517303799 | RH CONSOLE AIR DEFLECTOR GSX Model | ||
| 1 | 517303800 | LH CONSOLE AIR DEFLECTOR GSX Model | 1 |
| 1 | 517304909 | PANEL GRILL GSX SE, Grand Touring SE | 1 |
| 1 | 517304242 | LH Hood Grille GSX SE, Grand Touring SE | 1 |
| 1 | 517304243 | RH Hood Grille GSX SE, Grand Touring SE | 1 |
| 1 | 517303808 | LH Panel Latch | 1 |
| XXXX | Not Available As Spare Part - Padding Protector | ||
| 2 | 517305000 | Panel Latch | 2 |
| 1 | 517303996 | INDICATOR SUPPORT SE Model | 1 |
| 1 | 517304027 | Deep Black, Cap Console | 1 |
| XXX | Not Available As Spare Parts Grand Touring SE | ||
| 1 | 517304006 | Black RH Pannel GSX, Grand Touring , LE, SE | 1 |
| 517305328 | PANEL_BODY RH B-341 | ||
| 1 | 517305168 | Magnesium RH Panel | 1 |
| 1 | 517304905 | RH LOWER PANEL FOAM | 1 |
| 1 | 517304901 | LH LOWER PANEL FOAM | 1 |
| 1 | 517304908 | RH UPPER PANEL FOAM | 1 |
| XXX | Not Available As Spare Parts Grand Touring Black Model | ||
| 1 | 517304893 | Hood Foam | 1 |
| 1 | 517304904 | LH REAR PANEL FOAM | 1 |
| 1 | 517304194 | RH Headlamp Ass'y | 1 |
| 1 | 517304195 | LH Headlamp Ass'y | 1 |
| 1 | 517304221 | Latch Support | 1 |
| 1 | 517304899 | LH CENTRAL PANEL FOAM | 1 |
| 1 | 517304902 | LH UPPER PANEL FOAM | 1 |
| 517304897 | CENTRAL FOAM PANEL LH | ||
| 1 | 517304518 | Console Nut | 1 |
| 1 | 732601210 | HEX. FLANGED SCREW #8 X 3/8 GSX SE, Grand Touring SE | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 517305100 | RH Mirror Ass'y | 1 |
| 1 | 517305101 | LH Mirror Ass'y | 1 |
