Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 219700417 | SYNTHETIC GREASE, 400 G | ||
| 3 | 250000151 | HEX. SCREW M10 X 80 | 3 |
| 1 | 207104044 | HEX. SCREW M10 X 40 | 1 |
| 504152252 | Spacer | ||
| 504083800 | Spacer | ||
| 1 | 504152237 | SPACER | 1 |
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 6 | 504073700 | WASHER | 6 |
| 504152064 | CHAINCASE | ||
| 3 | 503175800 | Washer | 3 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 3 | 233201414 | Hex. Flange Elastic Nut M10 | 3 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 2 | 732620001 | CYLINDER PIN | 2 |
| 1 | 732601314 | ADJUSTMENT SCREW | 1 |
| 1 | 234001410 | Flat Washer 10 mm | 1 |
| 2 | 414484400 | O-Ring | 2 |
| 504151951 | Chain Tensioner | ||
| 1 | 504080200 | SPACER | 1 |
| 2 | 504080300 | WASHER | 2 |
| 1 | 405403000 | NEEDLE BEARING | 1 |
| 414531300 | ROLLER | ||
| 1 | 732601144 | SCREW | 1 |
| 1 | 504151927 | SEAL | 1 |
| 371901700 | CIRCLIP | ||
| 1 | 504152006 | Ball Bearing | 1 |
| 1 | 504147200 | SHIM | 1 |
| 1 | 504152031 | Sprocket, 19 Teeth | 1 |
| 250000012 | HEX. CASTLE NUT M20 X 1.5 | ||
| 371006300 | PIN COTTER | ||
| 1 | 504151857 | Drive Chain, 74 Links | 1 |
| 1 | 504096800 | SLIDING GEAR, 56 TEETH | 1 |
| 415064300 | CIRCLIP, INTERIOR | ||
| 1 | 504094300 | WASHER | 1 |
| 1 | 415046400 | O-Ring | 1 |
| 504151845 | COVER | ||
| 1 | 414773200 | O-RING | 1 |
| 1 | 207005044 | Hex. Screw M10 X 1.5 X 50 | 1 |
| 234100602 | WASHER-LOCK SPRING DIN.128A-A2 | ||
| 4 | 210263080 | Hex. Flange Screw M6 X 30 | 4 |
| 1 | 504151750 | FILLER CAP ASSY | 1 |
| 414969400 | O-RING | ||
| 413803300 | SYNTHETIC CHAINCASE OIL, 12 X 355 ML | ||
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504151921 | Plug 1/8”-27 | 1 |
| 2 | 210251180 | HEX. FLANGED SCREW M5 X 11 | 2 |
| 504152036 | SLIDER CHAIN | ||
| 504097700 | Coupling Axle | ||
| 1 | 504096600 | Release Spring | 1 |
| 1 | 504151964 | CAP | 1 |
| 1 | 504076300 | RETAINING RING | 1 |
| 504152005 | BALL BEARING | ||
| 1 | 581096800 | SPROCK ASSY, 44 TEETH Includes 55 to 62 | 1 |
| 504084400 | Sprocket, 44 Teeth | ||
| 1 | 414772600 | NEEDLE BEARING | 1 |
| 504076800 | DRIVE PIN | ||
| 3 | 414772700 | SPRING | 3 |
| 504076100 | RETAINER RING | ||
| 6 | 207152044 | Hex. Screw M5 X 20 | 6 |
| 6 | 233551416 | NUT-LOCK SPRING DIN.980V | 6 |
| 1 | 504083100 | Reverse Shaft | 1 |
| 1 | 250400010 | Rolled Pin M3 X 10 | 1 |
| 1 | 504077300 | Spacer | 1 |
| 1 | 504078700 | Ring | 1 |
| 1 | 581096900 | Sprock Ass'y, 19 Teeth Includes 67 to 68 | 1 |
| 1 | 414773100 | NEEDLE BEARING | 1 |
| 1 | 504082900 | Washer | 1 |
| 504087700 | TAB LOCK | ||
| 504075800 | Fork | ||
| 1 | 504152367 | FORK AXLE | 1 |
| 2 | 414772500 | SPRING PIN | 2 |
| 1 | 504152632 | Ball Joint | 1 |
| 2 | 205062560 | Socket Head Screw M6 X 25 | 2 |
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 581122200 | SPROCK ASS?Y, 19 TEETH Includes 77 to 78 | ||
| 414805000 | NEEDLE BEARING | ||
| 1 | 570048600 | Alignement Rod | 1 |
| 1 | 207089044 | Hex. Screw M8 X 90 | 1 |
| 1 | 504152567 | SUPPORT | 1 |
| 1 | 504152646 | BUSHING | 1 |
| 1 | 504152561 | GRIP | 1 |
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 1 | 504152615 | HANDLE | 1 |
| 1 | 504152595 | BUSHING | 1 |
| 1 | 205583544 | Socket Head Screw M8 X 35, Scotch Grip | 1 |
| 1 | 503154000 | WASHER | 1 |
