Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 515177171 | Speedometer Ass'y Includes 1 to 4 | 1 |
| 1 | 415129355 | Speedometer Button | 1 |
| 1 | 415129348 | Gauge Ring | 1 |
| 1 | 415129349 | Lens | 1 |
| 1 | 219902677 | BRP Logo 20 mm | 1 |
| 1 | 515177249 | DESS Switch Includes 6 to 9 | 1 |
| 3 | 515175232 | Male Terminal | 3 |
| 1 | 515175494 | Male Housing, 3 Circuits | 1 |
| 409902000 | Tubing 12 mm | ||
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 515177057 | DESS Cap | 1 |
| 1 | 710001248 | DC Outlet | 1 |
| 1 | 515176398 | Temperature Sensor Includes 13 to 15 | 1 |
| 1 | 515175670 | Female Terminal Housing, 2 Circuits | 1 |
| 2 | 278000632 | Female Terminal | 2 |
| XXXX | Not Available As Spare Part - Loctite 592, Pipe Sealant, 50 ml | ||
| 1 | 515176366 | Air Temperature Sensor | 1 |
| 2 | 389804300 | Push Nut | 2 |
| 515177077 | WIRING HARNESS MAIN | ||
| 1 | 710000742 | Little Fuse, 5 Amperes | 1 |
| 1 | 710000743 | Little Fuse, 7.5 Amperes | 1 |
| 1 | 710000744 | Little Fuse, 10 Amperes | 1 |
| 1 | 710000745 | Little Fuse, 15 Ampere | 1 |
| 1 | 710000746 | Little Fuse, 20 Amperes | 1 |
| 1 | 710000747 | Little Fuse, 30 Amperes | 1 |
| 1 | 710000781 | Fuse Puller | 1 |
| 1 | 710001026 | Fuse Cover | 1 |
| 1 | 278002172 | Foam | 1 |
| 1 | 710000660 | Fuse Box Ass'y | 1 |
| 516005892 | FUSE DECAL ETEC | ||
| 1 | 515176775 | Relay, 50 AMP | 1 |
| 1 | 515176774 | Relay, 30 AMP | 1 |
| 1 | 515177073 | FUSEBOX SUPPORT | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 293150037 | Avdel Rivet 3/16" | 1 |
| 3 | 390402200 | Pop Rivet 3/16" | 3 |
| 1 | 515176234 | FEMALE TERMINAL HOUSING, 6 CIRCUITS | 1 |
| 1 | 515176861 | Ground Wire | 1 |
| 1 | 515176349 | Capacitor | 1 |
| 1 | 515176607 | Capacitor Support | 1 |
| 1 | 515176605 | Capacitor Harness | 1 |
| 2 | 250000462 | Socket Head Screw M10 X 32 | 2 |
| 2 | 250200026 | Lock washer | 2 |
| 1 | 516005515 | CAPACITOR DECAL (ENGLISH) | 1 |
| 1 | 515177193 | Cap | 1 |
| XXXX | Not Available As Spare Part - Loctite 8104 (Dielectric Grease), 75ml | ||
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 517304194 | RH Headlamp Ass'y Includes 42 To 46 | 1 |
| 1 | 517304195 | LH Headlamp Ass'y Includes 42 To 46 | 1 |
| 1 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 1 |
| XXXX | Not Available As Spare Part - Bulb Holder | ||
| 2 | 515176498 | Cap | 2 |
| 1 | 515176499 | Cover | 1 |
| 5 | 250000128 | Torx Truss Screw M6 X 20 | 5 |
| 5 | 250100113 | Panel Nut, M6 X 1.0 | 5 |
| 1 | 515176661 | MANUAL START HARNESS Includes 49 to 51 | 1 |
| 2 | 515175232 | Male Terminal | 2 |
| 1 | 710000667 | Male Housing, 2 Circuits | 1 |
