Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 400702603 | <<793>> Engine | ||
| 512059282 | Engine Support | ||
| 512059405 | Rubber Mount | ||
| 512059712 | Rubber Mount | ||
| 4 | 233201416 | Hex. Flange Elastic Nut M10 | 4 |
| 4 | 506151251 | Washer | 4 |
| 4 | 250000094 | Screw M10 X 30 | 4 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 512059585 | Plate | ||
| 1 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 1 |
| 250500002 | Stopper Screw | ||
| 1 | 512059610 | STOPPER | 1 |
| 512059057 | WASHER | ||
| 1 | 232170411 | Hex. Jam Nut M14 | 1 |
| 403138667 | Carburetor Kit TM-40-B184 | ||
| 2 | 512059305 | Clamp | 2 |
| 2 | 512059552 | Spark Plug NGK BR9ECS-5 | 2 |
| 516000986 | Spark Plug Decal | ||
| 1 | 512059564 | IGNITION COIL Includes 19 - 22. | 1 |
| 1 | 515175670 | Female Terminal Housing, 2 Circuits | 1 |
| 515175707 | Female Lock, 2 Circuits | ||
| 2 | 278000632 | Female Terminal | 2 |
| 1 | 410914600 | Plastic Clip, Spark Plug Wire | 1 |
| 1 | 512059485 | Cable Ass’Y, 380 mm | 1 |
| 512059486 | CABLE ASSY, 455 MM | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 2 | 207066044 | Hex. Screw M6 X 60 | 2 |
| 1 | 234061410 | Flat Washer 6 mm | 1 |
| 2 | 232561414 | Elastic Stop Nut M6 | 2 |
| 1 | 394001900 | EXTERNAL TOOTH LOCK WASHER | 1 |
| 2 | 517203200 | Spacer | 2 |
| 1 | 512059553 | Handle Ass'y (28 mm) | 1 |
| 1 | 512059682 | Throttle Handle Housing | 1 |
| 512059683 | Cover | ||
| 250000098 | PHILLIPS SCREW M2.9 X 16 | ||
| 2 | 732601143 | Flange Screw | 2 |
| 1 | 512059265 | Throttle Cable | 1 |
| 512059611 | Protector | ||
| 1 | 414753300 | Washer | 1 |
| 1 | 414753500 | Circlip | 1 |
| 1 | 414274500 | Circlip | 1 |
| 512059266 | CHOKE CABLE Includes 42 - 43. | ||
| 394103300 | Lock Washer, Interior Teeth | ||
| 1 | 512059094 | PLASTIC NUT | 1 |
| 512059501 | Pressure Manifold Ass'y Includes 45 - 53. | ||
| 1 | 270600009 | CAP | 1 |
| 1 | 293300042 | O-RING | 1 |
| 1 | 515175701 | PRESSURE MANIFOLD HARNESS Includes 48 - 49. | 1 |
| 1 | 278001665 | Female Terminal | 1 |
| 1 | 415061600 | SOLENOID LOCK | 1 |
| 1 | 241140060 | Screw K40 X 10 | 1 |
| XXXX | Not Available As Spare Part - Starter Jet (1.6) | ||
| 404161825 | STARTER JET | ||
| 1 | 512058919 | SUPPORT | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 414729300 | T-FITTING | 1 |
| 1 | 513032908 | Grommet | 1 |
| 1 | 293710035 | Straight Fitting | 1 |
| 512059273 | Calibrated Module | ||
| 516000245 | Electrical Box Decal | ||
| 409901300 | LOW TEMPERATURE VINYL TUBING | ||
| 1 | 515175673 | Male Housing, 6 Circuits | 1 |
| 1 | 515175678 | Male Wedge, 6 Circuits | 1 |
