Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518322708 | REAR BUMPER | ||
| 4 | 207682044 | Hex. Flange Screw M8 X 20 | 4 |
| XXXX | Not Available As Spare Part - Seat Ass'y | ||
| 572088200 | Sub-Seat | ||
| 732601221 | «T» Bolt | ||
| 572106300 | Rear Trunk, Se-Air | ||
| 5 | 517297900 | WASHER | 5 |
| XXXX | Not Available As Spare Part - Pop Rivet | ||
| 2 | 732610072 | Push Nut | 2 |
| 510004060 | Seat Cover | ||
| 415046302 | Foam Seat | ||
| 2 | 207053044 | Hex. Screw M5 X 30 | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 1 | 510004061 | LIGHT HOUSING | 1 |
| 1 | 410504100 | Bulb | 1 |
| 414513700 | Lens | ||
| 2 | 209632540 | Phillips Tapping Screw M3.9 X 25 | 2 |
| 2 | 414516400 | Washer | 2 |
| 515175250 | Female Terminal Housing, 3 Circuits | ||
| 3 | 409205300 | WIRE SEAL | 3 |
| 1 | 409204200 | FEMALE HOUSING | 1 |
| 409206100 | MALE TERMINAL | ||
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 572103804 | Snow Guard | ||
| 1 | 572108200 | REINFORCEMENT | 1 |
| 4 | 517225900 | Flat Washer | 4 |
| 4 | 293150087 | Pop Rivet 3/16” | 4 |
| 415073300 | Cap | ||
| 861777700 | RH MOULDING KIT Includes 29 - 30. | ||
| 861777800 | LH Moulding Kit | ||
| 516000237 | RH Reflector, Red | ||
| 516000238 | LH Reflector, Red | ||
| 3 | 561503100 | FEMALE TERMINAL | 3 |
| 6 | 243141640 | Hex. Flange Plastite Screw M4.8 X 16 | 6 |
| 529034100 | ADJUSTER WRENCH (SUSPENSION) | ||
| 1 | 520000126 | Adjustment Wrench | 1 |
| 520000107 | Tool Box Ass'y Includes 35 - 40. | ||
| 517168500 | Latch | ||
| XXXX | Not Available As Spare Part - Pop Rivet 5/32" | ||
| XXXX | Not Available As Spare Part - Steel Wire | ||
| 561502800 | Terminal Ring | ||
| 414112400 | HAIR PIN | ||
| 3 | 390409600 | Pop Rivet 3/16" | 3 |
| 3 | 517124300 | Washer | 3 |
| 409204300 | Female Housing | ||
| 529035592 | Tool Kit (Not Shown) Includes 44 - 55. | ||
| XXXX | Not Available As Spare Part - Bag Perforated (Not Shown) | ||
| 529019200 | DRIVER SCREW | ||
| 1 | 529014900 | Socket Wrench 10/13 mm | 1 |
| 529032800 | Wrench Socket (21/26 mm) (Not Shown) | ||
| 529017300 | FORK WRENCH | ||
| XXXX | Not Available As Spare Part - Wrench Fork (16/18 mm) (Not Shown) | ||
| 529014700 | MULTI-WRENCH | ||
| 1 | 219704403 | Was 412500100 Rope-Starter | 1 |
| 1 | 529019400 | Starter Grip | 1 |
| 1 | 529035501 | Spacing Tool | 1 |
| 1 | 529019300 | Wrench Fork 15/17 mm | 1 |
