Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 501027400 | DRIVE AXLE | 1 |
| 2 | 504151781 | SPROCKET, 9 TEETH | |
| 3 | 504151918 | Oil Seal Ass'y | 1 |
| 4 | 371910200 | CIRCLIP | |
| 5 | 504152009 | Ball Bearing | 1 |
| 6 | 501017400 | BEARING PROTECTOR | 1 |
| 7 | 504152456 | Track 16" X 136" X 1.25" Ass'y | 1 |
| 8 | 504152410 | Guide | 1 |
| 9 | XXX | Not Available As Spare Parts | |
| 10 | 504151860 | BEARING HOUSING | 1 |
| 11 | 501025000 | FLANGE | |
| 12 | 504152345 | Rotation Sensor | 1 |
| 13 | 515175671 | FEMALE TERMINAL HOUSING, 3 CIRCUITS | 1 |
| 14 | 278000632 | Female Terminal | 1 |
| 15 | 515175676 | Female Lock, 3 Circuits | 1 |
| 16 | 504152040 | MAGNETIC ADAPTOR | |
| 17 | 219700417 | SYNTHETIC GREASE, 400 G | |
| 18 | 233281414 | Hex. Flange Elastic Nut M8 | 3 |
| 19 | 504152292 | COUNTER SHAFT | 1 |
| 20 | 371910000 | Circlip | 2 |
| 21 | 504151968 | SPACER | |
| 22 | 504152535 | Ball Bearing | 1 |
| 23 | 501026900 | Flange | 1 |
| 24 | 207782544 | Carriage Bolt, M8 X 25 | 3 |
| 25 | 232581414 | Hex. Elastic Stop Nut M8 | 3 |
| 26 | 234081410 | Flat Washer 8 mm | 1 |
| 27 | 250000151 | HEX. SCREW M10 X 80 | 3 |
| 28 | 207102544 | Hex. Screw M10 X 25 | 1 |
| 29 | 504152252 | Spacer | |
| 30 | 504083800 | Spacer | |
| 31 | 504152237 | SPACER | 1 |
| 32 | 293800005 | Loctite 271, 10 ml | 1 |
| 33 | 504073700 | WASHER | 6 |
| 34 | 504152481 | CHAINCASE | 1 |
| 35 | 503175800 | Washer | 3 |
| 36 | 219704461 | LUBRICANT LOCTITE LB 8150 236ML | |
| 37 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 37 | 233201414 | Hex. Flange Elastic Nut M10 | 1 |
| 38 | 293800060 | Loctite 243, 10 ml | 1 |
| 39 | 732601314 | ADJUSTMENT SCREW | 1 |
| 40 | 234001410 | Flat Washer 10 mm | 1 |
| 41 | 414484400 | O-Ring | 2 |
| 42 | 219700417 | SYNTHETIC GREASE, 400 G | |
| 43 | 504151951 | Chain Tensioner | |
| 44 | 504080200 | SPACER | 1 |
| 45 | 504080300 | WASHER | 2 |
| 46 | 405403000 | NEEDLE BEARING | 1 |
| 47 | 414531300 | ROLLER | |
| 48 | 732601144 | SCREW | 1 |
| 49 | 293800005 | Loctite 271, 10 ml | 1 |
| 50 | 504151927 | SEAL | 1 |
| 51 | 371901700 | CIRCLIP | |
| 52 | 504152006 | Ball Bearing | 1 |
| 53 | 504152587 | SHIM | 1 |
| 54 | 504152031 | Sprocket, 19 Teeth | 1 |
| 55 | 250000012 | HEX. CASTLE NUT M20 X 1.5 | |
| 56 | 371006300 | PIN COTTER | |
| 57 | 504151830 | DRIVE CHAIN, 72 LINKS | |
| 58 | 504148500 | 43 TEETH SPROCKET, LARGE | |
| 59 | 415064300 | CIRCLIP, INTERIOR | |
| 60 | 415046400 | O-Ring | 1 |
| 61 | 504152471 | CHAINCASE COVER | 1 |
| 62 | 207102544 | Hex. Screw M10 X 25 | 1 |
| 63 | 210263080 | Hex. Flange Screw M6 X 30 | 4 |
| 64 | 504151703 | FILLER CAP ASS'Y | 1 |
| 65 | 414969400 | O-RING | |
| 66 | 413803300 | SYNTHETIC CHAINCASE OIL, 12 X 355 ML | |
| 67 | 414575600 | Hair Pin | 1 |
| 68 | 504151921 | Plug 1/8”-27 | 1 |
| 69 | 219704455 | Was 293800018 Loctite 592, 50 ml | 1 |
| 70 | 504152460 | CAP | |
| 71 | 504152005 | BALL BEARING | |
| 72 | 504152058 | Shim |
