Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518327038 | Frame Includes 1 To 27 | ||
| 518326518 | E MODULE Includes 2 To 12 | ||
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 1 | 518326198 | Front Member | 1 |
| 4 | 605636002 | Clinch Nut Hexsert M8 | 4 |
| 7 | 390909100 | Avex Rivet | 7 |
| 2 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 4 | 293150119 | Hemlock Rivet, 6.5 mm | 4 |
| 2 | 505072690 | Leg Bushing | 2 |
| 518327185 | Muffler Support | ||
| 1 | 293150163 | Rivet Hucklok | 1 |
| 1 | 509000645 | Radiator Tunnel | 1 |
| 2 | 518326107 | Fastening rail | 2 |
| XXXX | Not Available As Spare Part - Fastening Bracket | ||
| XXXX | Not Available As Spare Part - Drive Axle Cover LH | ||
| XXXX | Not Available As Spare Part - Drive Axle Cover RH | ||
| XXXX | Not Available As Spare Part - Battery Support | ||
| 2 | 518327457 | SEAT BOX BRACKET | 2 |
| 1 | 518326109 | SUPPORT TUBE BRACKET LH | 1 |
| 1 | 518326110 | SUPPORT TUBE BRACKET RH | 1 |
| 1 | 518326430 | Clinch Nut plate | 1 |
| XXXX | Not Available As Spare Part - Frame Corner LH | ||
| XXXX | Not Available As Spare Part - Frame Corner RH | ||
| 2 | 518325560 | Adhesive Patch | 2 |
| 1 | 518325645 | Rear Profile | 1 |
| 6 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 6 |
| 1 | 205061244 | Socket Screw | 1 |
| XXXX | Not Available As Spare Part - Gasket A6 x 10 | ||
| 518326123 | GEARBOX FRONT PLATE | ||
| 1 | 518326124 | Gearbox Rear Plate | 1 |
| 3 | 390402200 | Pop Rivet 3/16" | 3 |
| 2 | 518326357 | RUBBER COVER | 2 |
| 518325641 | FOOTBOARD SUPPORT TUBE, LH | ||
| 1 | 518325642 | FOOTBOARD SUPPORT TUBE, RH | 1 |
| 207662086 | SCREW-HEX.FLANGE DIN.6921 | ||
| 2 | 520000492 | Footrest | 2 |
| 8 | 390909100 | Avex Rivet | 8 |
| 518327445 | TOE HOOK LH | ||
| 2 | 605636003 | Clinch Nut M6 Hexsert | 2 |
| 1 | 518327447 | TOE HOOK RH | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 4 | 250000129 | Torx Screw M6 X 16 | 4 |
| 1 | 514054846 | Spring Bracket | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 518327645 | BRACE ASS'Y LH Includes 47 To 48 | 1 |
| 2 | 512060295 | Rubber Mount | 2 |
| 1 | 234281474 | Conical Spring Washer M8 | 1 |
| 1 | 518326213 | S Module Includes 50 To 51 | 1 |
| 12 | 390909200 | Avex Rivet | 12 |
| 2 | 210262080 | Hex. Forming Screw M6 X 20 | 2 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 6 | 390909100 | Avex Rivet | 6 |
| 5 | 390909200 | Avex Rivet | 5 |
| 1 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 1 |
| 2 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 2 |
| 1 | 207584044 | Hex. Flange Screw M8 X 40, Scotch Grip | 1 |
| 1 | 518326140 | Engine Support | 1 |
| 4 | 390909100 | Avex Rivet | 4 |
| 2 | 293150119 | Hemlock Rivet, 6.5 mm | 2 |
| 1 | 518326754 | Front Member Ass'y Includes 64 To 66 | 1 |
| 1 | 502007077 | LH Bumper Fastener | 1 |
| 1 | 502007078 | RH Bumper Fastener | 1 |
| 2 | 390909200 | Avex Rivet | 2 |
| 6 | 207662044 | Hex. Flange Screw M6 X 20 | 6 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 2 | 224061201 | Flat Washer | 2 |
| 8 | 207662044 | Hex. Flange Screw M6 X 20 | 8 |
| 8 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 8 |
| 4 | 207662044 | Hex. Flange Screw M6 X 20 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 390909200 | Avex Rivet | 4 |
| 518326103 | UPPER SUPPORT TUBE WELDED | ||
| XXXX | Not Available As Spare Part - Lock Washer | ||
| 2 | 518326848 | Upper Column Support | 2 |
| 1 | 518326355 | Center Column Support | 1 |
| 2 | 250000522 | Hex Flange Screw M6 x 25 | 2 |
| 1 | 515177073 | FUSEBOX SUPPORT | 1 |
| 1 | 518327035 | Brake Hose Cover | 1 |
| 6 | 293150174 | Hemlock Rivet, 6.4 mm | 6 |
