Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 63503001100C1 | Frame 635TA | 1 |
| 1 | 6350300200633 | Subframe, right | 1 |
| 1 | 6350300200533 | Subframe, left | 1 |
| 1 | 63508019050 | Rear reinforcement | 1 |
| 1 | 6350304800033 | Rear footpeg bracket left | 1 |
| 1 | 6350304900033 | Rear footpeg bracket left | 1 |
| 1 | 6350300200733 | Cross member, black | 1 |
| 2 | 60003044100 | footrest bolt, rear | 2 |
| 2 | 60003152000 | ENGAGE PANEL FOOTREST L/S 03 | 2 |
| 1 | 60003051000 | FOOTREST CPL. R/S REAR 03 | 1 |
| 1 | 60003050000 | FOOTREST CPL. L/S REAR 03 | 1 |
| 2 | 60003052000 | ENGAGE PANEL FOOTREST R/S 03 | 2 |
| 2 | 0799060003 | retaining washer DIN 6799 - 6 | 2 |
| 1 | 6410301300033 | Engine strut black | 1 |
| 1 | 6350309019033 | Skid plate frame holder, right cmpl. | 1 |
| 1 | 6350309018033 | Skid plate frame holder, left cmpl. | 1 |
| 1 | 6350800600033 | Mask support, right | 1 |
| 1 | 6350800500033 | Mask support, left | 1 |
| 1 | 63503039051 | Rear master cylinder guard | 1 |
| 1 | 63503039000C1 | Front footpeg bracket, right | 1 |
| 1 | 63503038000C1 | Front footpeg bracket left | 1 |
| 2 | 08000010025U0 | Bushing 10,4x20x25 | 2 |
| 2 | 0035080356S | SCREW M8X35 ISA45 SS | 2 |
| 6 | 0035080206S | SHCS M8x20 TX45 | 6 |
| 4 | 0024060136 | HH collar screw M6x13 TX30 | 4 |
| 2 | 0035100209 | AH-COLLAR SCREW M10X20 ISA45 | 2 |
| 3 | 0035100309S | SHCS M10x30 TX45 | 3 |
| 2 | 63503002093 | Retain. brack., seat cowl pad front left | 2 |
| 2 | 63503002090 | Rubber seat cowl pad | 2 |
| 4 | 0025060126S | Hex collar screw M6x12 ISA30 self-lockin | 4 |
| 1 | 69014017000 | SPECIAL SCREW M6X18 ISA30 08 | 1 |
| 2 | 58411098100 | CONTACT WASHER M6 VSV-K6 | 2 |
| 2 | 0035100456S | ISA screw M10x45 ISA45 | 2 |
| 4 | 0035100409S | ISA collar screw M10x40 ISA45 | 4 |
| 4 | 0025080166S | HH collar screw M8x16 TX40 SL | 4 |
| 1 | 0035100609S | AH-COLLAR SCREW M10X60 ISA45 | 1 |
| 2 | 0024060156S | HH collar screw M6x15 TX30 | 2 |
| 1 | 0025080166 | HH COLLAR SCREW M8X16 TX40 | 1 |
| 2 | 0025060256 | HH collar screw M6x25 TX30 | 2 |
| 1 | 54310086200 | SELF LOCKING NUT M8 10.9 | 1 |
| 1 | 014579080301S | screw ISO 14579-M8x30-10.9-MK black | 1 |
| 2 | 014579080506S | CYL. SCREW DIN14579 M8X50 SS | 2 |
| 1 | 60003041010 | FOOTREST RUBBER FRONT R/S 03 | 1 |
| 1 | 60003040010 | FOOTREST RUBBER FRONT L/S 03 | 1 |
| 6 | 0025060166S | HH collar screw M6x16 TX30 SL | 6 |
| 1 | 63503096000 | Front sprocket cover | 1 |
| 2 | 0035080356 | AH-COLLAR SCREW M8X35 ISA45 | 2 |
| 2 | 0125080003 | washer DIN 125 A -8.4 | 2 |
| 2 | 60307048000 | RUBBER SEAT-CONTACT SURFACE | 2 |
| 2 | 54803044000 | PIN FOR FOOT PED 51.5X9.8 MM | 2 |
| 1 | 78003041050 | FOOTREST R/S 08 | 1 |
| 1 | 78003040050 | FOOTREST L/S 08 | 1 |
| 2 | 54603041000 | FOOTREST SPRING L/S & R/S | 2 |
| 2 | 0125100003 | washer DIN 125 A 10.5 | 2 |
| 2 | 0094032253 | PIN DIN0094-3,2X25 STEEL | 2 |
| 6 | 54603048100 | clip nut M6 | 6 |
| 2 | 54603048600 | RANGE CHANGE METAL NUT M5 INOX | 2 |
| 2 | 54603048000 | RANGE CHANGE METAL NUT M8 | 2 |
| 3 | 69008021160 | special screw M5x12 | 3 |
| 1 | 0035100656S | ISA screw, M10x65 ISA45 | 1 |
