Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 400509705 | <<583>> Engine Formula Z 583. | ||
| 400604001 | <<670>> Engine Formula Z 670. | ||
| 9 | 414893700 | Spring Formula Z 583. Formula Z 670. | 9 |
| 414746400 | Reflection Sheet Formula Z 583. Formula Z 670. | ||
| 514044300 | Heat Deflector Formula Z 583. Formula Z 670. | ||
| 512058916 | Engine Support Formula Z 583. Formula Z 670. | ||
| 570127700 | RUBBER MOUNT Formula Z 583. Formula Z 670. | ||
| 512050900 | Engine Support Formula Z 583. Formula Z 670. | ||
| 8 | 224001211 | Flat Washer 10 mm Formula Z 583. Formula Z 670. | 8 |
| 4 | 228501045 | Elastic Stop Nut M10 Formula Z 583. Formula Z 670. | 4 |
| 415014900 | Reflection Sheet Formula Z 583. Formula Z 670. | ||
| 503128100 | Spacer Formula Z 583. Formula Z 670. | ||
| 2 | 514052743 | RUBBER MOUNT Formula Z 583. Formula Z 670. | 2 |
| 4 | 228781045 | Elastic Flange Stop Nut M8 Formula Z 583. Formula Z 670. | 4 |
| 514048300 | Tail Pipe Formula Z 583. | ||
| 514044700 | Tail Pipe Formula Z 670. | ||
| 514045100 | Pipe Bracket Formula Z 583. Formula Z 670. | ||
| 2 | 732600004 | Hex. Flange Screw M6 x 30 Formula Z 583. Formula Z 670. | 2 |
| 512049100 | Stopper Plate Formula Z 583. | ||
| 512052900 | Stopper Plate Formula Z 670. | ||
| 1 | 222081665 | Hex. Screw M8 x 16 Formula Z 583. | 1 |
| 1 | 222061665 | Hex. Screw M6 x 16 Formula Z 670. | 1 |
| 1 | 224781140 | Lock Washer 8 mm Formula Z 583. | 1 |
| 1 | 224761110 | Lock Washer 6 mm Formula Z 670. | 1 |
| 570027300 | Exhaust Grommet Formula Z 583. Formula Z 670. | ||
| 514044400 | Muffler Formula Z 583. Formula Z 670. | ||
| 414851600 | Spring Formula Z 583. Formula Z 670. | ||
| 517267100 | Side Bracket Formula Z 583. Formula Z 670. | ||
| 415049500 | Reflection Sheet Formula Z 583. Formula Z 670. | ||
| 2 | 224061151 | Washer 6 mm Formula Z 583. Formula Z 670. | 2 |
| 2 | 517124300 | Washer Formula Z 583. Formula Z 670. | 2 |
| 512055500 | Plate Formula Z 583. Formula Z 670. | ||
| 1 | 222082565 | Hex. Screw M8 x 25 Formula Z 583. Formula Z 670. | 1 |
| 1 | 224081171 | Flat Washer 8 mm Formula Z 583. Formula Z 670. | 1 |
| 1 | 228581045 | Elastic Stop Nut M8 Formula Z 583. Formula Z 670. | 1 |
| 1 | 732610019 | RH Hex. Jam Nut M12 Formula Z 583. Formula Z 670. | 1 |
| 570045400 | STOPPER Formula Z 583. Formula Z 670. | ||
| 4 | 512056700 | Lock Washer Formula Z 583. Formula Z 670. | 4 |
| 224701188 | WASHER-LOCK SPRING DIN.128A-A2 Formula Z 583. Formula Z 670. | ||
| 4 | 222002565 | Hex. Screw M10 x 25 Formula Z 583. Formula Z 670. | 4 |
| 512052400 | Screw Formula Z 583. Formula Z 670. | ||
| 1 | 413710300 | Loctite 17914, Sealant, 80 ml Formula Z 583. Formula Z 670. | 1 |
| 414706200 | Reflection Plate Formula Z 583. Formula Z 670. | ||
| 4 | 228001045 | Hex. Nut M10 Formula Z 583. Formula Z 670. | 4 |
| 514044200 | Support Ass'y Formula Z 583. Formula Z 670. | ||
| 415049100 | Reflection Sheet (In Hood) Formula Z 583. Formula Z 670. | ||
| 1 | 390906800 | Pop Rivet 3/16" Formula Z 583. Formula Z 670. | 1 |
| 1 | 413707400 | Loctite 271, 10cc Formula Z 583. Formula Z 670. | 1 |
| 2 | 570048700 | Rubber Bumper Formula Z 583. Formula Z 670. | 2 |
| 570049300 | Rubber Spacer Formula Z 583. Formula Z 670. | ||
| 514045200 | Reinforcement Formula Z 583. Formula Z 670. | ||
| 2 | 390402200 | Pop Rivet 3/16" Formula Z 583. Formula Z 670. | 2 |
| 514044500 | Pipe Support Formula Z 583. Formula Z 670. | ||
| 514052803 | Tuned Pipe Ass'y Includes 49 - 53. Formula Z 583. Formula Z 670. | ||
| 514052808 | Upper Shell Formula Z 583. Formula Z 670. | ||
| 514052809 | Lower Shell Formula Z 583. Formula Z 670. | ||
| 514046503 | Cleat Formula Z 583. Formula Z 670. | ||
| 1 | 514052924 | Norma Clamp Formula Z 583. Formula Z 670. | 1 |
