Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 45030000044 | ENGINE CASE CPL. '97 | ||
| 45030039000 | ENGINE CASE GASKET | ||
| 45030023000 | DOWEL PIN | ||
| 0912060403 | AH SCREW DIN0912-M 6X40 | ||
| 3 | 0912060453 | AH SCREW DIN0912-M 6X45 | 3 |
| 0912060503 | AH SCREW DIN0912-M 6X50 | ||
| 2 | 0912060553 | AH SCREW DIN0912-M 6X55 | 2 |
| 45030001000 | CLUTCH COVER | ||
| 45030025000 | GASKET CLUTCH COVER | ||
| 45030002000 | IGNITION COVER | ||
| 45030092000 | RETAINING SPRING | ||
| 45039006000 | IGNITION COIL CPL | ||
| 45039005000 | FLYWHEEL | ||
| 36330030000 | CYL. BASE GASKET | ||
| 45030006500 | CYLINDER HEAD | ||
| 36330036000 | CYL. HEAD GASKET | ||
| 36330042000 | STUD BOLT M6X112 | ||
| 45030079000 | HH-NUT M6 36MM HIGH WS=12 | ||
| 6 | 0125060003 | WASHER DIN0125-A 6,4 | 6 |
| 36330050000 | INTAKE FLANGE FOR DELLORTO | ||
| 45030050000 | INTAKE FLANGE | ||
| 49130438000 | GASKET FOR INTAKE PIPE | ||
| 45030091000 | RUBBER GASKET | ||
| 2 | 0934060003 | hex nut DIN 934 M6 | 2 |
| 45030047000 | SECURING GUIDE | ||
| 15130020000 | OIL LEVEL CONTR. PLUG PVCM14 | ||
| 15130021000 | SEAL RING 14,2X20X1 | ||
| 1 | 0933080103 | HH SCREW DIN0933-M 8X10 | 1 |
| 1 | 45038017000 | SEAL RING 8X14X1 AI | 1 |
| 45030018000 | % CRANKSHAFT STROKE 41,7MM | ||
| 45030015000 | CON.ROD REPAIR KIT | ||
| 45030034000 | NEEDLE CAGE | ||
| 45030074000 | CIRCLIP | ||
| 45030007500 | PISTON CPL. | ||
| 36330031000 | PISTON RING D=39MM | ||
| 0625062031 | BALL BEARING 6203 TN9.C3 | ||
| 15130086000 | RADIAL SEAL RING | ||
| 1 | 0888025030 | WOODRUFF KEY DIN6888-2,5X3 | 1 |
| 16030028000 | NUT | ||
| 45032001500 | CLUTCH HUB 52-Z W.PRIM.15-Z | ||
| 45032002000 | INNER CLUTCH HUB | ||
| 16032011000 | CLUTCH BLOCK | ||
| 45032005500 | CLUTCH SPRING | ||
| 45032008000 | JOINT FOR BLOCKS | ||
| 45032045000 | ROLLER 3X13,8 | ||
| 16032095000 | BUSH | ||
| 45033050000 | STARTING SHAFT | ||
| 45033052000 | KICKST. RATCHET | ||
| 45033056000 | SPRING | ||
| 45032002544 | CLUTCH HUB CPL. | ||
| 16233039000 | STOP SCREW | ||
| 16233040000 | RUBBER | ||
| 45039003000 | GROUND PLATE | ||
| 45033076000 | KICKST. RUBBER | ||
| 0933070253 | HH SCREW DIN0933-M 7X25 | ||
| 45033054000 | SPRING | ||
| 45033051000 | KICKSTARTER SPROCKETS | ||
| 45033077000 | PLASTIC CAP KICKSTARTER | ||
| 0770012020 | O-RING 16X1,75 | ||
| 45033078000 | WASHER | ||
| 45033002000 | COUNTER SHAFT | ||
| 2 | 0625062027 | BALL BEARING 6202 2RS1 C3 | 2 |
| 15133028000 | RADIAL SEAL RING | ||
| 45033029000 | CHAIN SPROCKET 11-Z | ||
| 15133031000 | WASHER 12,2X20X1,8 | ||
| 45039008000 | RUBBER CAP | ||
| 45033022000 | WASHER | ||
| 36330005100 | CYL+ PISTON | ||
| 36333096000 | CIRCLIP 14X1,2 | ||
| 2 | 45033023000 | WASHER 16X25X0,5 | 2 |
| 0471160150 | CIRCLIP DIN0471-16X1 | ||
| 2 | 0125050003 | WASHER DIN0125-A 5,3 | 2 |
| 3 | 45030090000 | SCREW M4X10 | 3 |
| 45039093007 | SPARK PLUG | ||
| 45039090000 | SPARK PLUG CONNECTOR | ||
| 0797050003 | TOOTH LOCK WASH. DIN6797-J 5,3 | ||
| 36330046000 | GASKET | ||
| 1 | 0912050123 | AH SCREW DIN0912-M 5X12 | 1 |
| 45033024000 | CIRCLIP 17,5X1,2 | ||
| 36330032000 | COMP. RING | ||
| 15130033000 | PISTON PIN | ||
| 0912060603 | AH SCREW DIN0921-M 6X60 | ||
| 2 | 0912050203 | AH SCREW DIN0912-M 5X20 | 2 |
| 15133032000 | HH-NUT M12X1,25 6MM HIGH | ||
| 45033070000 | STARTING LEVER | ||
| 16030057000 | STUD BOLT | ||
| 54007062000 | HEX. NUT M6, 25MM HIGH | ||
| 36330056000 | ANTIVIBRATION RUBBER | ||
| 49130454000 | GASKET | ||
| 16030051000 | REED VALVE HOUSING | ||
| 0127060003 | SPRING RING DIN0127-B 6 | ||
| 45030095000 | RUBBER | ||
| 45030099500 | SET OF GASKETS | ||
| 45030099100 | GASKET SET SEAL RINGS |
