Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 514053263 | Muffler Bracket | ||
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 2 | 414913700 | SPRING | 2 |
| 4 | 514053343 | GUIDE | 4 |
| 233481413 | Lock Spring Nut M8 | ||
| 1 | 570039000 | EXHAUST GROMMET Grand Touring 500. Grand Touring 600. | 1 |
| 514053064 | Exhaust Grommet Grand Touring 700. | ||
| 514053326 | Muffler Includes 7 - 12. Grand Touring 500. Grand Touring 600. | ||
| 514053537 | Muffler Grand Touring 700. | ||
| 514053160 | RH Heat Shield Grand Touring 500. Grand Touring 600. | ||
| 514053606 | RH Heat Shield Grand Touring 700. | ||
| 514052733 | LH Heat Shield Grand Touring 500. Grand Touring 600. | ||
| 514053516 | LH HEAT SHIELD Grand Touring 700. | ||
| 514052734 | RH Insulating Wool Grand Touring 500. Grand Touring 600. | ||
| 514053294 | RH Insulating Wool Grand Touring 700. | ||
| 514052844 | LH Insulating Wool Grand Touring 500. Grand Touring 600. | ||
| 514053295 | LH Wooll Insulating Grand Touring 700. | ||
| 10 | 390910000 | Pop Rivet 3/16” | 10 |
| 1 | 514052704 | RUBBER BUMPER | 1 |
| 420973650 | Exhaust Manifold Grand Touring 500. | ||
| 420979543 | Exhaust Manifold Grand Touring 600. | ||
| 420973593 | Exhaust Manifold Grand Touring 700. | ||
| 514053593 | Enveloppe, Exhaust Manifold Grand Touring 500. . | ||
| 2 | 420850552 | Gasket Grand Touring 700. | 2 |
| 2 | 420931610 | Gasket Grand Touring 600. | 2 |
| 420931615 | GASKET Grand Touring 500. | ||
| 2 | 514053643 | Spring Grand Touring 700. | 2 |
| 1 | 514053487 | Exhaust Gasket Grand Touring 700. | 1 |
| 2 | 514053603 | RETAINING STRAP Grand Touring 700. | 2 |
| 8 | 205062044 | Socket Head Screw M6 X 20 Grand Touring 700. | 8 |
| 6 | 205082544 | Socket Head Screw M8 X 25 Grand Touring 500. Grand Touring 600. | 6 |
| 2 | 207182044 | Hex. Screw M8 X 20 Grand Touring 500. Grand Touring 600. | 2 |
| 8 | 234161471 | Lock Washer M6, Black Grand Touring 700. | 8 |
| 8 | 234181401 | Lock Washer 8 mm Grand Touring 500. Grand Touring 600. | 8 |
| 2 | 514053588 | INSULATING WOOL Grand Touring 700. | 2 |
| 514053488 | Tuned Pipe Ass’Y Includes 24 - 38. Grand Touring 500. Grand Touring 600. | ||
| 514053495 | Tuned Pipe Ass’Y Grand Touring 500. Grand Touring 700. | ||
| 514053676 | Tuned Pipe Ass’Y Grand Touring 500. . | ||
| 514053167 | Upper Enveloppe Grand Touring 500. | ||
| 514053192 | Upper Enveloppe Grand Touring 600. | ||
| 514053690 | Upper Enveloppe Grand Touring 700. | ||
| 1 | 514053193 | REAR UPPER ENVELOPE Grand Touring 600. | 1 |
| 1 | 514053313 | REAR UPPER ENVELOPE Grand Touring 700. | 1 |
| 514053360 | Lower Envelope Grand Touring 500. | ||
| 1 | 514053367 | LOWER ENVELOPE Grand Touring 600. | 1 |
| 514053691 | Lower Envelope Grand Touring 700. | ||
| 1 | 514053196 | REAR LOWER ENVELOPE Grand Touring 600. | 1 |
| 1 | 514053314 | REAR LOWER ENVELOPE Grand Touring 700. | 1 |
| 514052716 | Insulating Wool Grand Touring 500. | ||
| 2 | 514053285 | INSULATING WOOL Grand Touring 600. | 2 |
| 514053696 | Insulating Wool Grand Touring 700. | ||
| 1 | 514053499 | Retaining Strap Grand Touring 500. | 1 |
| 1 | 514053494 | RETAINING STRAP Grand Touring 500. | 1 |
| 1 | 514053498 | Retaining Strap Grand Touring 600. | 1 |
| 1 | 514053502 | Retaining Strap Grand Touring 500. | 1 |
| 1 | 514053501 | Retaining Strap Grand Touring 600. | 1 |
| 1 | 514053540 | RETAINING STRAP | 1 |
| 1 | 514053493 | RETAINING STRAP Grand Touring 500. | 1 |
| 1 | 514053491 | RETAINING STRAP Grand Touring 600. | 1 |
| 1 | 514053492 | Retaining Strap Grand Touring 700. | 1 |
| 1 | 514053500 | RETAINING STRAP Grand Touring 600. Grand Touring 700. | 1 |
| 514053512 | RETAINING STRAP Grand Touring 600. Grand Touring 700. | ||
| 514053180 | Rubber Pad Grand Touring 600. | ||
| 4 | 514053643 | Spring | 4 |
| 570044100 | Rubber Pad | ||
| 1 | 514053442 | SUPPORT Grand Touring 700. | 1 |
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 1 | 293800090 | Sealant, Loctite, 80 ml | 1 |
| 7 | 415107100 | Spring Grand Touring 500. Grand Touring 600. | 7 |
| 8 | 415107100 | Spring Grand Touring 700. | 8 |
| 514052718 | Reflective Sheet | ||
| 1 | 514053390 | REFLECTIVE SHEET | 1 |
| 1 | 514053436 | Spring Bracket Grand Touring 500. Grand Touring 600. | 1 |
| 2 | 514053436 | Spring Bracket Grand Touring 700. | 2 |
| 1 | 207151244 | Hex. Screw M5 X 12 | 1 |
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 514053399 | Reflective Sheet | ||
| 514053435 | Reflective Sheet, Black Cab | ||
| 514053446 | Reflective Sheet, Black Cab | ||
| 514053624 | Reflective Sheet | ||
| 514053450 | Reflective Sheet | ||
| 514053391 | Reflective Sheet |
