Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504153184 | Chaincase Package Sport | 1 |
| 1 | 504153407 | Chaincase Except Package Sport | 1 |
| 1 | 518325816 | Plate | 1 |
| 6 | 233261434 | Flange Elastic Nut M6 | 6 |
| 2 | 250400048 | Dowel Pin | 2 |
| 1 | 293250175 | Oil Seal Engine 600 and 900 ACE | 1 |
| 1 | 415049300 | Oil Seal Engine 1200 ACE | 1 |
| 1 | 293350115 | Ball Bearing | 1 |
| 1 | 504152576 | Circlip | 1 |
| 1 | 504152961 | Sprocket, 24 Teeth | 1 |
| 1 | 504152979 | Coupling | 1 |
| 1 | 293370054 | Circlip | 1 |
| 1 | 504153178 | Spring Release | 1 |
| 1 | 504152960 | Slinding Gear, 27 Teeth | 1 |
| 1 | 293350063 | Needle Bearing | 1 |
| 1 | 504152689 | Washer | 1 |
| 1 | 293370055 | Circlip | 1 |
| 1 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 1 |
| 1 | 504152862 | Washer | 1 |
| 1 | 504083100 | Reverse Shaft | 1 |
| 1 | 250400010 | Rolled Pin M3 X 10 | 1 |
| 1 | 504078700 | Ring | 1 |
| 1 | 581096900 | Sprock Ass'y, 19 Teeth Includes 520 to 520a | 1 |
| 1 | 293350064 | Needle Bearing | 1 |
| 1 | 570048600 | Alignement Rod | 1 |
| 1 | 504152724 | Sprocket, 29 Teeth | 1 |
| 1 | 504077300 | Spacer | 1 |
| 1 | 293200159 | Oil Seal | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504152593 | Sprocket, 45 Teeth Engine 900 ACE | 1 |
| 1 | 504152726 | Sprocket, 43 Teeth Engine 1200 ACE | 1 |
| 1 | 504152971 | Sprocket, 51 Teeth Engine 600 ACE | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 293300122 | O-Ring | 1 |
| 1 | 504152619 | Magnetic Cap | 1 |
| 1 | 504152629 | Drive Chain, 104 Links Engine 900 and 1200 ACE | 1 |
| 1 | 504152631 | Drive Chain, 108 Links Engine 600 ACE | 1 |
| 1 | 232006414 | Hex. Nut M10 X 1.5 | 1 |
| 1 | 504152602 | Adjustment Screw | 1 |
| 1 | 504152636 | Magnetic Plug 1/8 - 27 NPTF Package Sport | 1 |
| 1 | 504152854 | Magnetic Plug 1/8 - 27 NPTF Except Package Sport | 1 |
| 1 | 250500012 | Allen Drive Plug 1/8-27 PTF | 1 |
| 1 | 250200100 | Bonded Washer | 1 |
| 1 | 504153431 | Chaine Tensionner | 1 |
| 1 | 504152739 | Slider Chain | 1 |
| 1 | 504152841 | Tensioner Axle | 1 |
| 1 | 504152282 | Circlip | 1 |
| 1 | 504153122 | Chain Slider | 1 |
| 1 | 205862044 | Socket Head Screw M6 X 20, Scotch Grip | 1 |
| 1 | 504153144 | Chaincase Cover Ass'y Package Sport | 1 |
| 1 | 504153412 | Black Chaincase Cover Ass'y Except Package Sport | 1 |
| 1 | 504152896 | Rotation Sensor | 1 |
| 1 | 293300130 | Tight Seal | 1 |
| 7 | 250000934 | Hex. Flange Screw M6 X 30 Package Sport | 7 |
| 7 | 250000935 | Screw-Forming Hex.HD.FL.BZN Except Package Sport | 7 |
| 504152929 | Cap Ass'y Includes 1740 to 1740d | ||
| 1 | 504152930 | Cap | 1 |
| 1 | 293710035 | Straight Fitting | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 504152900 | Protector Tube | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 414554800 | Spring Clamp | 1 |
| 1 | 504153432 | Fork Ass'y | 1 |
| 1 | 414484400 | O-Ring | 1 |
| 1 | 504152956 | Welded Axle Fork | 1 |
| 2 | 250400045 | Spring Pin M5 X 16 | 2 |
| 1 | 504153427 | Lever | 1 |
| 250000340 | SOCKET HEAD SCREW M8 X 25, SCOTCH GRIP | ||
| 1 | 504152951 | Ball Joint | 1 |
| 1 | 504152710 | Double Ball Joint | 1 |
| 1 | 205562044 | Socket Head Screw M6 X 20, Scotch Grip | 1 |
| 1 | 207562544 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 504153174 | Grip | 1 |
| 1 | 504082900 | Washer | 1 |
| 1 | 207089044 | Hex. Screw M8 X 90 | 1 |
| 1 | 504153426 | Retaining Ring | 1 |
| 1 | 504153187 | Bearing Housing | 1 |
| 1 | 504153418 | Bearing Housing Ass'y | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 293350074 | Ball Bearing | 1 |
| 1 | 504153000 | Countershaft | 1 |
| 1 | 235381646 | Torx Screw M8 X 16, Scotch Grip | 1 |
| 1 | 504153083 | Drive Axle Ass'y | 1 |
| 1 | 504153344 | Track Ass'y 15"X128"X1.25", RIP SAW Track RIP SAW | 1 |
| 1 | 504153345 | Track Ass'y 15"X128"X1.25", ICE RIPPER Track ICE RIPPER | 1 |
| 1 | 504153705 | Track Ass'y 15" X 129" X 1.6" Track ICE COBRA | 1 |
| 30 | 415129528 | Track Guide | 30 |
| 60 | 415129529 | Cleat | 60 |
