Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518316447 | Frame Ass'y Includes 1 - 2. MX Z 440 LC. | ||
| XXXX | Not Available As Spare Part - Frame Ass'y MX Z x 440 LC. | ||
| 518316848 | Tunnel MX Z 440 LC. | ||
| 518316855 | Tunnel MX Z x 440 LC. | ||
| XXXX | Not Available As Spare Part - Front Member MX Z 440 LC. | ||
| 518318040 | Front Member MX Z x 440 LC. | ||
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 518316771 | LH Support MX Z 440 LC. | ||
| 518316770 | RH Support MX Z 440 LC. | ||
| 518316702 | LH Support MX Z x 440 LC. | ||
| 518316703 | RH Support MX Z x 440 LC. | ||
| 518313804 | RH Front Footrest MX Z 440 LC. | ||
| 518313805 | LH Front Footrest MX Z 440 LC. | ||
| 518318117 | RH Upper Front Footrest MX Z x 440 LC. | ||
| 518318119 | RH Lower Front Footrest | ||
| 518318118 | LH Upper Front Footrest MX Z x 440 LC. | ||
| 518318120 | LH Lower Front Footrest | ||
| 518312910 | Front Bracket MX Z 440 LC. | ||
| 518316749 | LH Rear Bracket MX Z 440 LC. | ||
| 518316750 | RH Rear Bracket MX Z 440 LC. | ||
| 518316723 | LH Rear Bracket MX Z x 440 LC. | ||
| 518316724 | RH Rear Bracket MX Z x 440 LC. | ||
| 518310211 | Cap-End MX Z 440 LC. | ||
| 518318102 | Cap-End MX Z x 440 LC. | ||
| 518308727 | Upper Plate L.H MX Z 440 LC. | ||
| 518308728 | Upper Plate R.H MX Z 440 LC. | ||
| 518318121 | Upper Plate L.H MX Z x 440 LC. | ||
| 518318122 | Upper Plate R.H MX Z x 440 LC. | ||
| 518304747 | RH Tank Bracket | ||
| 518304748 | LH Tank Bracket | ||
| 518318115 | Support MX Z x 440 LC. | ||
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 390909100 | Avex Rivet | 1 |
| 415067300 | Radiator Protector MX Z x 440 LC. | ||
| 518309200 | Handle Steering Support MX Z 440 LC. | ||
| 518318400 | Handle Steering Support MX Z x 440 LC. | ||
| 4 | 222064065 | Hex. Screw M6 x 40 | 4 |
| 2 | 222063565 | Hex. Screw M6 x 35 MX Z 440 LC. | 2 |
| 4 | 224061151 | Washer 6 mm | 4 |
| 4 | 228761045 | Elastic Flange Nut M6 | 4 |
| 1 | 518202100 | Belt Guard Bracket | 1 |
| 1 | 518207500 | REINFORCEMENT | 1 |
| 518315100 | Rope Guide MX Z 440 LC. | ||
| 517293500 | Guide Rope MX Z x 440 LC. | ||
| 518304741 | Reinf. Plate MX Z 440 LC. | ||
| 2 | 222082065 | Hex. Screw M8 x 20 MX Z 440 LC. | 2 |
| 2 | 224781140 | Lock Washer 8 mm MX Z 440 LC. | 2 |
| 415068500 | Protector MX Z x 440 LC. | ||
| 1 | 518310400 | AIR INTAKE SUPPORT MX Z 440 LC. | 1 |
| 518318106 | Air Silencer Support MX Z x 440 LC. | ||
| 518310206 | Valve Bracket | ||
| 2 | 517124300 | Washer MX Z x 440 LC. | 2 |
| 2 | 518304746 | FOOTREST REINFORCEMENT MX Z 440 LC. | 2 |
| 518318109 | Reinforcement MX Z x 440 LC. | ||
| 2 | 222051665 | Hex. Screw M5 x 16 | 2 |
| 6 | 228751045 | Elastic Flange Nut M5 | 6 |
| 518316772 | RH Reinf. Plate MX Z 440 LC. | ||
| 518316773 | LH Reinf. Plate MX Z 440 LC. | ||
| 518316709 | RH Reinforcement Plate MX Z x 440 LC. | ||
| 518316710 | LH Reinforcement. Plate MX Z x 440 LC. | ||
| XXXX | Not Available As Spare Part - Seat Bracket MX Z 440 LC. | ||
| 518310208 | Seat Bracket MX Z x 440 LC. | ||
| 2 | 228551045 | Elastic Stop Nut M5 MX Z x 440 LC. | 2 |
| 1 | 413707400 | Loctite 271, 10cc | 1 |
| 1 | 414859400 | CAP MX Z 440 LC. | 1 |
| 518318116 | Frame Member MX Z x 440 LC. | ||
| 518318112 | Frame Protector MX Z x 440 LC. |
