Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 506151506 | RH Swivel Arm Summit 800. | ||
| 506151507 | LH Swivel Arm Summit 800. | ||
| 506149900 | BUSHING SWIVEL Summit 800. | ||
| 506150100 | PIVOT SWIVEL Summit 800. | ||
| 2 | 207008086 | Hex. Screw M10 X 80 Summit 800. | 2 |
| 4 | 506150000 | Washer 10 mm Summit 800. | 4 |
| 2 | 506151251 | Washer Summit 800. | 2 |
| 2 | 732610084 | Flange Nut M10 Summit 800. | 2 |
| 2 | 207005544 | Hex. Screw M10 X 55 Summit 800. | 2 |
| 2 | 506147300 | BAR PIVOT Summit 800. | 2 |
| 224002251 | FLAT WASHER Summit 800. | ||
| 2 | 233601416 | Elastic Locking Nut M10 X 1.5 Summit 800. | 2 |
| 8 | 503175800 | Washer Summit 800. | 8 |
| 4 | 232501416 | Elastic Flange Nut M10 Summit 800. | 4 |
| 4 | 506150200 | Bushing Swivel Summit 800. | 4 |
| 506147000 | Bar-Swivel Summit 800. | ||
| 2 | 207684044 | Hex. Flange Screw M8 X 40 Summit 800. | 2 |
| 2 | 506151496 | LH BALL JOINT Summit 800. | 2 |
| 2 | 506151252 | Washer Summit 800. | 2 |
| 8 | 233281414 | Hex. Flange Elastic Nut M8 Summit 800. | 8 |
| 3 | 250100016 | LH Threaded Hex. Jam Nut M10 Summit 800. | 3 |
| 506151450 | Tie-Rod Summit 800. | ||
| 3 | 732610010 | RH Threaded Hex. Jam Nut M10 Summit 800. | 3 |
| 2 | 506151491 | Ball Joint Summit 800. | 2 |
| 506151451 | RH Steering Arm Summit 800. | ||
| 506151452 | LH Steering Arm Summit 800. | ||
| 2 | 205083544 | SOCKET HEAD SCREW M8 X 35 Summit 800. | 2 |
| 2 | 570070500 | TIE-ROD CAP Summit 800. | 2 |
| 2 | 506151100 | RETAINER RING Summit 800. | 2 |
| 6 | 390402300 | Pop Rivet 3/16" Summit 800. | 6 |
| 506151492 | RH BALL JOINT Summit 800. | ||
| 506150300 | Inside Tie-Rod Summit 800. | ||
| 506151495 | LH BALL JOINT Summit 800. | ||
| 4 | 506150400 | Housing Half Summit 800. | 4 |
| 4 | 506150500 | Housing Bushing Summit 800. | 4 |
| 4 | 506150600 | Stopper Plate Summit 800. | 4 |
| 4 | 207787044 | Carriage Bolt M8 X 70 Summit 800. | 4 |
| 4 | 506151140 | O-RING Summit 800. | 4 |
| 506151488 | Main Tube Summit 800. | ||
| 860601300 | Extention Handle Bar kit Includes 40 - 41. Summit 800. | ||
| 8 | 250000074 | Hex. Screw With Nylon M8 X 40 Summit 800. | 8 |
| 4 | 414491600 | Steering Support Summit 800. | 4 |
| 4 | 506151196 | Reinforcement Summit 800. | 4 |
| 506151462 | Handlebar Summit 800. | ||
| 506151548 | Handle Grip Summit 800. | ||
| 390403600 | Pop Rivet 3/16 Summit 800. | ||
| 506151518 | Deep Black, J-Hook short 90° Summit 800. | ||
| 506151474 | Steering Pad Ass'y Includes 48 - 50. Summit 800. | ||
| XXXX | Not Available As Spare Part - Foam Summit 800. | ||
| XXXX | Not Available As Spare Part - Cover Summit 800. | ||
| 506151514 | Console Collar Summit 800. | ||
| 2 | 732601210 | HEX. FLANGED SCREW #8 X 3/8 Summit 800. | 2 |
| 1 | 415095500 | Tie-Down Summit 800. | 1 |
| 1 | 415090200 | Grip Summit 800. | 1 |
| 506148200 | Support Plate Summit 800. | ||
| 2 | 207162544 | Hex. Screw M6 X 25 Summit 800. | 2 |
| 8 | 234061410 | Flat Washer 6 mm Summit 800. | 8 |
| 2 | 232561414 | Elastic Stop Nut M6 Summit 800. | 2 |
| 2 | 408200700 | Grease Fitting Summit 800. | 2 |
| 219700417 | SYNTHETIC GREASE, 400 G Summit 800. | ||
| 293800021 | ADHESIVE LOCTITE 495 Summit 800. | ||
| 1 | 415040700 | Horn Summit 800. | 1 |
