Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 501027400 | DRIVE AXLE | 1 |
| 504151781 | SPROCKET, 9 TEETH | ||
| 2 | 504151782 | HALF SPROCKET, 9 TEETH | 2 |
| 1 | 504151918 | Oil Seal Ass'y | 1 |
| 371910200 | CIRCLIP | ||
| 1 | 504152009 | Ball Bearing | 1 |
| 1 | 501017400 | BEARING PROTECTOR | 1 |
| 1 | 504151804 | Track 15” X 136” X 0.88” Ass'y Includes 8 - 10. Grand Touring SE 800 SDI. | 1 |
| 1 | 504151802 | Track 15” X 121” X 0.88” Ass'y Legend SE 800 SDI. | 1 |
| 504152028 | Track Ass’Y (15”X136"X 1.250") Includes 8 - 9. Grand Touring SE 800 SDI. | ||
| 48 | 500003400 | Guide Cleat | 48 |
| 36 | 500003400 | Guide Cleat Grand Touring SE 800 SDI. | 36 |
| 48 | 504151828 | Cleat | 48 |
| 1 | 414784800 | CORK | 1 |
| 501025000 | FLANGE | ||
| 1 | 504152173 | FLANGE, SPEEDO | 1 |
| 504152040 | MAGNETIC ADAPTOR | ||
| 219700417 | SYNTHETIC GREASE, 400 G | ||
| 3 | 233281414 | Hex. Flange Elastic Nut M8 | 3 |
| 1 | 501026300 | COUNTER SHAFT | 1 |
| 1 | 504149100 | Spacer | 1 |
| 080044200 | Spacer (Casting) | ||
| 1 | 504152026 | Ball Bearing | 1 |
| 3 | 205482546 | SOCKET HEAD SCREW M8 X 25 | 3 |
| 3 | 232581414 | Hex. Elastic Stop Nut M8 | 3 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 3 | 207108044 | HEX. SCREW M10 X 80 | 3 |
| 504083800 | Spacer | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 6 | 504073700 | WASHER | 6 |
| 504152062 | Chaincase | ||
| 3 | 503183800 | Washer | 3 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 3 | 233201414 | Hex. Flange Elastic Nut M10 | 3 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 504151946 | Adjustment Screw | ||
| 1 | 503189148 | Washer | 1 |
| 504152005 | BALL BEARING | ||
| 504152058 | Shim | ||
| 2 | 504151954 | O-RING | 2 |
| 504151940 | Chain Tensioner | ||
| 1 | 504080200 | SPACER | 1 |
| 2 | 504080300 | WASHER | 2 |
| 1 | 405403000 | NEEDLE BEARING | 1 |
| 414531300 | ROLLER | ||
| 1 | 732601144 | SCREW | 1 |
| 1 | 415049300 | Oil Seal | 1 |
| 507031500 | SPACER | ||
| 371901700 | CIRCLIP | ||
| 414876700 | O-RING | ||
| 1 | 504152006 | Ball Bearing | 1 |
| 1 | 504147200 | SHIM | 1 |
| 1 | 504139700 | SPROCKET, 24 TEETH Grand Touring SE 800 SDI. | 1 |
| 1 | 504085300 | SPROCKET, LARGE, 26 TEETH Legend SE 800 SDI. | 1 |
| 1 | 504151945 | SPRING | 1 |
| 250000012 | HEX. CASTLE NUT M20 X 1.5 | ||
| 2 | 503125900 | HARD WASHER | 2 |
| 371006300 | PIN COTTER | ||
| 504151856 | DRIVE CHAIN LARGE, 76 LINKS | ||
| 504148500 | 43 TEETH SPROCKET, LARGE | ||
| 415064300 | CIRCLIP, INTERIOR | ||
| 1 | 415046400 | O-Ring | 1 |
| 1 | 504152027 | Chaincase Cover | 1 |
| 1 | 207102544 | Hex. Screw M10 X 25 | 1 |
| 234100602 | WASHER-LOCK SPRING DIN.128A-A2 | ||
| 4 | 210263080 | Hex. Flange Screw M6 X 30 | 4 |
| 1 | 504151703 | FILLER CAP ASS'Y | 1 |
| 414969400 | O-RING | ||
| 413803300 | SYNTHETIC CHAINCASE OIL, 12 X 355 ML | ||
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504151921 | Plug 1/8”-27 | 1 |
| 1 | 504152104 | CAP | 1 |
| 1 | 504151860 | BEARING HOUSING | 1 |
