Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 518329696 | Black, Frame Package SE & LE | 1 |
| 1 | 518329825 | Module E Includes 2 to 12 | 1 |
| 518329826 | Bottom Plate Not Shown | ||
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 1 | 518326198 | Front Member | 1 |
| 4 | 605636002 | Clinch Nut Hexsert M8 | 4 |
| 5 | 390909100 | Avex Rivet | 5 |
| 2 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 4 | 293150119 | Hemlock Rivet, 6.5 mm | 4 |
| 2 | 505072690 | Leg Bushing | 2 |
| 1 | 518327983 | SUPPORT_EXHAUST | 1 |
| 1 | 293150163 | Rivet Hucklok | 1 |
| 1 | 509000976 | Tunnel Radiator Includes 13 to 13,2 | 1 |
| 1 | 518329083 | Rear Arm Bracket Not Shown | 1 |
| 2 | 518326107 | Fastening rail | 2 |
| 1 | 518328821 | LH Footrest Package SE & LE | 1 |
| 1 | 518328822 | RH Footrest Package SE & LE | 1 |
| 1 | 605355235 | FASTENING BRACKET Package SE & LE | 1 |
| 1 | 518328016 | LH Drive Axle Cover Package SE & LE | 1 |
| 1 | 518328017 | RH Drive Axle Cover Package SE & LE | 1 |
| 518325986 | BATTERY SUPPORT PLATE Package SE & LE | ||
| 2 | 518329164 | SEAT BOX BRACKET | 2 |
| 1 | 518329109 | LH Support Tube Bracket | 1 |
| 1 | 518329110 | RH Support Tube Bracket | 1 |
| 1 | 518326430 | Clinch Nut plate Package SE & LE | 1 |
| 1 | 518325524 | LH Frame Corner Package SE & LE | 1 |
| 1 | 518328024 | RH Frame Corner Package SE & LE | 1 |
| 2 | 518325560 | Adhesive Patch | 2 |
| 1 | 518328748 | Rear Profile Package SE & LE | 1 |
| 6 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 6 |
| 36 | 390909100 | Avex Rivet | 36 |
| 43 | 390909200 | Avex Rivet | 43 |
| 31 | 293150119 | Hemlock Rivet, 6.5 mm | 31 |
| 12 | 293150183 | Rivet | 12 |
| 518326123 | GEARBOX FRONT PLATE | ||
| 1 | 518326124 | Gearbox Rear Plate | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 1 | 518326178 | Engine Support | 1 |
| 1 | 293150174 | Hemlock Rivet, 6.4 mm | 1 |
| 1 | 518326963 | LH Footboard Support Tube Package SE & LE | 1 |
| 7 | 390909100 | Avex Rivet | 7 |
| 1 | 518326964 | RH Footboard Support Tube Package SE & LE | 1 |
| 2 | 207662056 | Hex. Flange Screw M6 x 20 | 2 |
| 2 | 520001208 | Black Rear Footrest | 2 |
| 8 | 293150102 | Rivet 3/16" | 8 |
| 1 | 518327374 | Black, LH Toe Hook Package LE | 1 |
| 1 | 518327375 | TOE HOLD L.H. Package SE | 1 |
| 1 | 518328569 | Black, LH Toe Hook Package SWT | 1 |
| 1 | 390909200 | Avex Rivet Package SE & LE | 1 |
| 1 | 605636003 | Clinch Nut M6 Hexsert | 1 |
| 2 | 414644300 | Black, Dart Package LE | 2 |
| 2 | 605636003 | Clinch Nut M6 Hexsert Package SE | 2 |
| 518328571 | Black, RH Toe Hook Package SWT | ||
| 1 | 518327376 | Black RH Toe Hook Package SE & LE | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 4 | 250000717 | Torx Head Screw M6 X 16 Package SE & LE | 4 |
| 1 | 514054846 | Spring Bracket | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 2 | 390909200 | Avex Rivet | 2 |
| 1 | 518327535 | BRACE ASS'Y Includes 53 to 54 | 1 |
| 2 | 512060295 | Rubber Mount | 2 |
| 1 | 234281474 | Conical Spring Washer M8 | 1 |
| 1 | 518328391 | Cross Member Package LE | 1 |
| 1 | 518328395 | Module S Package SE | 1 |
| 1 | 518327487 | Front Suspension Support | 1 |
| 1 | 207161444 | Hex. Screw M6 X 14 | 1 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 210262050 | Hexagonal Head Screw | 2 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 6 | 293150163 | Rivet Hucklok | 6 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 1 |
| 2 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 2 |
| 1 | 207584044 | Hex. Flange Screw M8 X 40, Scotch Grip | 1 |
| 1 | 518326975 | Front Member | 1 |
| 1 | 518329105 | Upper Support Tube | 1 |
| 2 | 207182044 | Hex. Screw M8 X 20 | 2 |
| 2 | 232581414 | Hex. Elastic Stop Nut M8 | 2 |
| 2 | 518326848 | Upper Column Support | 2 |
| 2 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 1 | 518326355 | Center Column Support | 1 |
| 2 | 207662556 | Hex. Flange Screw M6 X 25 | 2 |
| 4 | 518325560 | Adhesive Patch | 4 |
